Ricoh Pro L5130 Rip Settings Manual

Hide thumbs Also See for Pro L5130:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Maintenance and Care
RIP Settings Guide
Installing RIPCenter/PosterShop
Functions for RICOH Pro L5130/L5160
Restrictions on Using RIPCenter/PosterShop
Appendix
For information not in this manual, refer to
the PDF files on the supplied CD.
For safe and correct use, be sure to read the Safety Information in
Read This First before using the machine.

Advertisement

Table of Contents
loading

Related Manuals for Ricoh Pro L5130

Summary of Contents for Ricoh Pro L5130

  • Page 1 RIP Settings Guide Installing RIPCenter/PosterShop Functions for RICOH Pro L5130/L5160 Restrictions on Using RIPCenter/PosterShop Appendix For information not in this manual, refer to the PDF files on the supplied CD. For safe and correct use, be sure to read the Safety Information in...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Getting Started..............................3 Software Described in This Manual......................3 About this Manual............................3 Disclaimer................................3 Notes................................3 1. Installing RIPCenter/PosterShop Checking the Operating Environment.......................5 Installation Setup..............................7 Establishing a Network Connection between Printer and Computer............7 Computer Setup..............................7 Preparing the Media for Installation......................8 Installing the Software............................
  • Page 4 4. Appendix Trademarks............................... 39...

  • Page 5: Getting Started

    About this Manual This manual describes the following: • How to install RIPCenter/PosterShop • RIPCenter/PosterShop functions customized for RICOH Pro L5130/L5160 • Restrictions on using RIPCenter/PosterShop Disclaimer To the maximum extent permitted by applicable laws, in no event will the manufacturer be liable for any damages whatsoever arising out of failures of this product, losses of documents or data, or the use or non-use of this product and operation manuals provided with it.

  • Page 7: Installing Ripcenter/Postershop

    1. Installing RIPCenter/PosterShop This section explains how to install RIPCenter and, optionally, PosterShop on the computer. The installation procedure is the same in both cases. Checking the Operating Environment To use RIPCenter/PosterShop, the following environment is required: Configuration Desktop computer Operating system •...
  • Page 8 1. Installing RIPCenter/PosterShop Screen resolution 1280 × 1024 or greater...

  • Page 9: Installation Setup

    Installation Setup Installation Setup Establishing a Network Connection between Printer and Computer Connect the printer and computer to the network. The supported interface is 1000BASE-T/100BASE-TX. For information about the connection procedure, see "Connecting the Cable" and "Ethernet Configuration", Operating Instructions. Internet 1000BASE-T/ 1000BASE-T/...

  • Page 10: Preparing The Media For Installation

    1. Installing RIPCenter/PosterShop EDP004 Preparing the Media for Installation Prepare the media required for installation as follows: DWT811 1. USB flash drive The programs to be installed are on this. 2. USB hardware key To install and use RIPCenter/PosterShop, plug it into the computer.

  • Page 11: Installing The Software

    Installing the Software Installing the Software Plug the USB hardware key ("hardware key") into one of the computer’s USB ports. Plug the USB flash drive into another of the computer’s USB ports. If the Auto Play dialog box appears, select the folder. In Explorer, open the USB flash drive and double-click "Install_ONYX.exe"...
  • Page 12 1. Installing RIPCenter/PosterShop...

  • Page 13: Functions For L5130/L5160

    2. Functions for L5130/L5160 This section explains the RIPCenter/PosterShop functions customized for RICOH Pro L5130/L5160. For information about other functions and operations, see the RIPCenter/PosterShop manuals. • When using RIPCenter/PosterShop, keep the USB hardware key connected to the computer. Functions on the Main Menu...

  • Page 14: Printer Area

    2. Functions for L5130/L5160 Printer Area For details about the displayed location of the printer area, see page 11 "Functions on the Main Menu". DWU808 1. Printer Displays the printer model name. Jobs Ready to Print Area/Buffered Jobs Area For details about the displayed location of the Jobs Ready to Print area and Buffered Jobs area, see page 11 "Functions on the Main Menu".
  • Page 15 Functions on the Main Menu The information retrieved from the printer is listed. You can also print the nozzle check pattern and recovery check pattern. DWU803 1. Detailed model name Displays the printer model name in detail. 2. Printer status Displays the printer status.

  • Page 16: Preview Area

    2. Functions for L5130/L5160 9. Level in other supplies Vertically displays the level in the waste ink bottle, cleaning cartridge, and flushing cartridge using a bar chart and displays the value indicated by each bar when you hover over it. Preview Area For details about the displayed location of the Preview area, see page 11 "Functions on the Main Menu".
  • Page 17 Functions on the Main Menu 1. Job status Displays the print job status. 2. Suspend Click this to suspend the ongoing job. 3. Resume Click this to resume the suspended job. 4. Cancel Click this to cancel the ongoing or suspended job.

  • Page 18: Changing Printer Settings

    2. Functions for L5130/L5160 Changing Printer Settings You can change the printer settings configured by the profile. Also, using Media Manager, you can change the printer settings when creating or editing the profile. When using Media Manager, the optional PosterShop is required. Opening the Printer Settings Dialog Box You can change the printer settings by any of the following means: •...
  • Page 19 Changing Printer Settings Select [Media Type:] and the media profile, and then click [Mode Options...]. DWU815 Select the mode, and then click [Options...]. The printer settings dialog box is displayed. See page 20 "Printer Settings Dialog Box". Profile (changing via Media Manager) When editing the media profile via Media Manager, change the printer settings.

  • Page 20: Print Job

    2. Functions for L5130/L5160 In "Basic Print Mode Settings", click No. 4 [Mode Options]. DWU821 The printer settings dialog box is displayed. See page 20 "Printer Settings Dialog Box". Print job Change the printer settings for each print job. Right-click on the job, point to [Edit], and then select [Printer Settings]. The printer settings dialog box is displayed.
  • Page 21 Changing Printer Settings Select the printer, and then click [Configure Printer]. DWU814 After the confirmation dialog box appears, click [Yes]. Click the [Quick Sets] tab. Select a Quick Sets setting and then click [Edit...].

  • Page 22: Printer Settings Dialog Box

    2. Functions for L5130/L5160 Uncheck [Get Media and Page Size From Printer]. DWU816 Click [Print Options...]. DWU817 The printer settings dialog box is displayed. See page 20 "Printer Settings Dialog Box". • You can also change this setting with [Edit Quick Sets] on the toolbar. Printer Settings Dialog Box The initial value of each printer setting varies depending on the profile.
  • Page 23 Changing Printer Settings Setting items Items Selectable values Description Passes 600×450: 6 scans The pass number depends on the resolution. 600×600: 8 scans 600×900: 12 scans 600×1200: 16 scans 1200×1200: 32 scans Printing Direction Unidirectional To improve the image quality, select [Unidirectional].
  • Page 24 2. Functions for L5130/L5160 Items Selectable values Description Pre-Heater On/Off Specify the heater settings. 20–70°C (68–158°F) Specify these settings according to the type and properties of the media Print-Heater On/Off being used. 20–70°C (68–158°F) After decreasing the heater temperature to secure sufficient Post-Heater On/Off drying time, change the printer...

  • Page 25: Other Functions

    Other Functions Other Functions Updating the Media Width Information Automatically This automatically updates the information of the media width to the current one retrieved from the printer. In the Information area, click the [Print Setup] tab. Click the gear icon next to "Current Media and Page Size". DWU813 Check "Automatically update page sizes", and then click [OK].
  • Page 26 2. Functions for L5130/L5160 Normally, you do not need to change this setting. Only if this setting differs from the machine setting, adjust it to match the machine setting. Checking the machine setting Connect to the printer with the web browser and log in in administrator mode. For details, see "Using Web Image Monitor", Operating Instructions.
  • Page 27 Other Functions Select the printer, and then click [Features...]. Select "Printer Settings", and then click [Configure...]. Check the community name. If it differs from the SNMP community name on the printer, change it to match it with the machine setting. Click [OK].

  • Page 28: Functions Usable With Postershop

    2. Functions for L5130/L5160 Functions Usable with PosterShop This section explains the functions usable with the optional PosterShop. Specifying Resolution Specify the resolution for the media profile. You can apply the solution to the print job by using the media profile. Launch Media Manager, and then open the media profile edit menu (ICC Workflow).

  • Page 29: Specifying Multilayer Printing

    Functions Usable with PosterShop • 1200×1200 • The resolution applied to the print job appears in the job list. For details, see page 12 "Jobs Ready to Print Area/Buffered Jobs Area". Specifying Multilayer Printing Specify the multilayer printing setting for the media profile. You can apply the multilayer printing to the print job by using the media profile.

  • Page 30: Setting Menu

    2. Functions for L5130/L5160 Setting Menu Configure Layers Items Description Print Order Displays the layer of ink to be printed in ascending order. The layer directly on the media is 1, and the last number is the printed surface. [Add] Add a layer.
  • Page 31 Functions Usable with PosterShop Edit Layer Items Description Layer Name Specify the layer's name. Colors For the process color layer, check CMYK. For the spot color layer, check the corresponding spot color. Printing Select the layer printing method. Method • Print Selected Channels: Print as is. •...
  • Page 32 2. Functions for L5130/L5160...

  • Page 33: Restrictions On Using Ripcenter/Postershop

    3. Restrictions on Using RIPCenter/ PosterShop This section explains the notes on using RIPCenter/PosterShop. Restrictions on RIP-Queue Overview Details Solution [Modify Printer] does not Even if you right-click on the You can open the same menu by operate. printer registered to RIP-Queue selecting the gear icon on and select [Modify Printer] on the "Current Media and Page Size"...
  • Page 34 3. Restrictions on Using RIPCenter/PosterShop Overview Details Solution A warning message does not Even if an unsupported file is The file will not be selected, so it appear even if a file not selected in [Open], a warning does not cause any problem. supported by RIP-Queue is message does not appear.
  • Page 35 Restrictions on RIP-Queue Overview Details Solution Ripping an image with a very Ripping fails in the following If falling under these conditions, large height fails. conditions. take note of the image height. - Device configuration without white ink - Using PDF with spot colors. - Image with large height (Example) Resolution: 600×600, Height:...

  • Page 36: Restrictions On Job Editor

    3. Restrictions on Using RIPCenter/PosterShop Restrictions on Job Editor Overview Details Solution Cannot print 1,000 copies or Even if you select the [Print] tab Specify the number of copies more when printing files other on Job Editor "Print Options" within 999. than PDF.
  • Page 37 Restrictions on Job Editor Overview Details Solution When using the "Apply the If you check "Apply the settings Change the settings manually. settings from the most recently from the most recently submitted submitted job to the new job" job to the new job" in the [Open] function, the number of copies menu, open a file and display and magnification change...

  • Page 38: Restrictions On The Virtual Printer

    3. Restrictions on Using RIPCenter/PosterShop Restrictions on the Virtual Printer Overview Details Solution There are multiple ways to Specify the Quick Sets setting for Specify the Quick Sets settings specify the Quick Sets setting the virtual printer as follows. for the virtual printer as shown on for the virtual printer and your Otherwise, the setting will not be the left.

  • Page 39: Restrictions On Media Manager

    Restrictions on Media Manager Restrictions on Media Manager These restrictions are applied when using optional PosterShop. Overview Details Solution If colorimetry fails, Media With "X-Rite i1 iSis", Media - Save the media profile before Manager is terminated Manager is terminated forcibly if performing colorimetry.
  • Page 40 3. Restrictions on Using RIPCenter/PosterShop...
  • Page 41 4. Appendix Trademarks "ONYX," the ONYX logo and "ONYX PosterShop" are registered trademarks, and "ONYX RIPCenter" is trademark, of ONYX Graphics, Inc. Intel Core is a trademark of Intel Corporation or its subsidiaries in the U.S. and/or other countries. Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
