Welcome to a
Set up the bike
CAUTION In case of emergency, firmly press down on the
resistance knob to stop the flywheel.
Seat Height
Reduce your risk of injury and enjoy a more comfortable ride
by adjusting the seat height so that there is a slight bend
(25-35 degrees) in your knee at the bottom of a pedal stroke.
To adjust the seat height:
1.
Dismount the bike. Turn and pull the seat adjustment
pop-pin
counterclockwise (-) to loosen and release it
from the seat post.
2. Raise or lower the seat to the desired height. Turn the pop-pin
clockwise (+) and secure it in a preset hole.
GETTING STARTED GUIDE
personalized fitness experience
Part
Seat adjustment pop-pin
Seat slider knob
SPINNER® RALLY
Handlebar Height
The handlebar should be approximately the same height as the
seat, or higher if you feel back discomfort.
To adjust the handlebar height:
1.
Turn the handlebar adjustment pop-pin
counterclockwise (-) to loosen and release it from the post.
2. Raise or lower the handlebars to the desired height, then
secure the pop-pin in a preset hole.
3.
Turn the handlebar adjustment pop-pin clockwise (+) to fully
tighten it.
To adjust the fore/aft handlebar position:
1.
Turn the fore/aft handlebar knob
to loosen it.
2. Slide the handlebar assembly to the desired position and
then fully tighten the fore/aft handlebar knob.
for your members
Part
Handlebar adjustment pop-pin
Fore/aft handlebar knob
Resistance knob
counterclockwise (-)
Advertisement
Table of Contents
Related Manuals for Precor Spinner Shift
Summary of Contents for Precor Spinner Shift
- Page 1 SPINNER® RALLY GETTING STARTED GUIDE Welcome to a personalized fitness experience for your members Part Part Handlebar adjustment pop-pin Seat adjustment pop-pin Seat slider knob Fore/aft handlebar knob Resistance knob Set up the bike CAUTION In case of emergency, firmly press down on the Handlebar Height resistance knob to stop the flywheel.
- Page 2 (+) to put tension on the flywheel so that the pedals do not rotate freely. • When the bike is not in use, always keep some resistance on the flywheel. Spinner® Rally Getting Started • P/N 305005-101 rev A, ENU ©2015 Precor Incorporated • October 2015...
-
Page 3: Assembly Guide
Remove the following parts from the packaging: handlebar assembly, handlebar post, hardware kit, product documentation, seat assembly, seat post, and spare parts. Figure 2 CAUTION Damage to the bike during assembly is not covered by the Precor Limited Warranty. During assembly, you must protect the handlebar and seat adjustment pop-pin threaded stems from damage. - Page 4 Once testing is complete, tip the bike forward using the handlebars and roll it on a smooth surface to its final use location. Turn the adjustable feet to level the bike. Spinner® Rally and Spinner® Shift Assembly Guide | P/N 305002-103 rev C, ENU ©2016 Precor Incorporated | January 2016...
- Page 5 Important It is the duty of the owner to maintain equipment in accordance with the instructions in this material and any accompanying material. Always purchase replacement parts and hardware from Precor. If you use parts not approved by Precor, you could void the Precor Limited Warranty. Use of parts not approved by Precor may cause injury.
- Page 6 Daily Maintenance Tasks Note Raise seat and handlebar posts to their highest setting to expose moisture. • If your facility allows members to interchange pedals, check all pedals after each class to ensure pedals are properly secured to prevent damage, which may lead to injuries.
-
Page 7: Replacement Parts
• Clean and seal the bike frame. Sweat can corrode the bike frame. Precor recommends that you seal the bike frame at least once a month. To seal the bike frame: Wipe the bike frame using a clean lint-free cloth dampened with 30 parts water to 1 part non-abrasive detergent. - Page 8 Figure 6 Replace the Brake Pad Your bike comes with a spare brake pad. To order more pads, contact Precor Customer Support. To replace the brake pad: Remove tension from the brake pad by turning the resistance knob counterclockwise (-) until completely loose.
- Page 9 Parts repaired or replaced under the terms of this warranty will be warranted for the remainder of the original warranty period only. To claim under this warranty, the buyer must notify Precor or your authorized Precor Distributor within 30 days after the date of discovery of any nonconformity and make the affected product available for inspection by Precor or its service representative.
- Page 10 To the extent the original purchaser purchases a limited extended warranty for Spinner Bike Line products as set forth in a signed Product Quote that has been accepted by Precor, then such limited extended warranty (i) shall only apply to Mechanical and Electrical parts and Product Labor, if applicable, (ii)
- Page 11 Internet service provider (ISP), and also to hardware related to Internet connectivity, such as Ethernet cabling, routers, servers and switches. 4. Precor is not responsible for the quality of television, video, audio, or other media supplied to its products. This restriction applies to services, such as those provided by a cable or satellite television provider;...
- Page 12 Spinner Bike Line Limited Warranty 7. Except in Canada, Precor does not pay labor outside the United States. Equipment limited warranty is void when equipment is installed in a country other than where sold. 8. Moving parts bolted to the structural frame are not included in the “Structural Frame”...
- Page 13 Exclusive Remedies. For any product described above that fails to conform to its warranty, Precor will provide, at its sole discretion, one of the following: (1) repair; (2) replacement; or (3) refund of the purchase price. Precor Limited Warranty service may be obtained by contacting the authorized Precor office or Distributor from whom you purchased the item.
- Page 14 Spinner Bike Line Limited Warranty EXCLUSION OF CONSEQUENTIAL AND INCIDENTAL DAMAGES. PRECOR AND/OR ITS SUPPLIERS SHALL HAVE NO OBLIGATION OR LIABILITY, WHETHER ARISING IN CONTRACT (INCLUDING WARRANTY), TORT (INCLUDING ACTIVE, PASSIVE, OR IMPUTED NEGLIGENCE AND STRICT LIABILITY), OR OTHERWISE, FOR DAMAGE TO THE EQUIPMENT,...
- Page 15 EXCLUSION OF CONSEQUENTIAL AND INCIDENTAL DAMAGES. Complete this portion and keep for your records. Purchased from: Example: Distributor or store name. Phone number: Example: Distributor or store telephone number. Product/model: Example: Spinner Rally. Serial number: The serial number is found on the shipping container.
- Page 16 Spinner Bike Line Limited Warranty Precor Incorporated Effective 01 January 2016 20031 142nd Ave NE, P.O. Box 7202, Woodinville, WA 98072-4002, USA P/N 304227-101 rev A, ENU 1-800-347-4404 • www.precor.com © 2016 Precor Incorporated...
