IX Series
IP network-compatible intercom
Multi-purpose Adapter IXW-MA
Web Setting Manual
Software version 2.00 or later
Important
• Before configuring and using the system, read Web Setting Manual (this document) carefully.
• For the installation and connection of each device, refer to "Installation Manual."
• Begin installation after reading and understanding the procedures for system configuration.
• The system settings file is required for post-installation maintenance and service. The setting file must be given to the customer.
• The illustrations used in this manual may differ from the actual product.
