Note: Do not lay alloy road wheels face
down on the ground.
E79153
Note: The Extension Adaptor is only used
for the front jacking points of your vehicle,
do not use for the rear jacking points.
1. Assemble the jack handle.
2. Install the extension adaptor on the
jack and secure with the wing bolt.
Note: Assemble the three handles to jack
the rear of the vehicle.
3. Ensure screwthread on the jack is
adequately lubricated before use.
4. Loosen the wheel nuts.
5. Raise your vehicle until the tire is clear
of the ground.
E134693
Ranger Raptor (TKD) Raptor, Vehicles Built From: 21-05-2018, JB3B 19A285 CKA enPHI, Edition date: 201804, First-Printing
Wheels and Tires
6. Remove the wheel nuts and the road
Installing a Road Wheel
and tire sizes. Using other sizes could
damage your vehicle.
on vehicles that were not originally fitted
with them. See an authorized dealer for
more details about compatibility.
grease or oil on the threads or the surface
between the wheel lugs and nuts. This can
cause the lug nuts to loosen while driving.
checked for tightness and the tire pressure
checked as soon as possible.
wheels using lug nuts designed for use with
steel wheels.
Note: Make sure the wheel and hub contact
surfaces are free from foreign matter.
Note: Make sure that the cones on the
wheel nuts are against the wheel.
1.
2. Install the wheel nuts finger tight.
3. Install the locking wheel nut key.
37
wheel.
WARNING: Use only approved wheel
WARNING: Do not fit run flat tires
WARNING: Make sure there is no
WARNING: Have the lug nuts
WARNING: Do not install alloy
Install the wheel.
