March 2018
First Printing
Litho in USA
JB3B 19A285 CKA
3421708_18a_Ranger_Raptor_Supplement_032218.indd 1
This supplement is not intended
to replace your vehicle Owner's
Manual, which contains more
detailed information concerning the
features of your vehicle as well as
important safety warnings designed
to help reduce the risk of injury to
you and your passengers. Please
read your entire Owner's Manual
carefully as you begin learning
about your new vehicle and refer
to the appropriate sections when
questions arise.
All information contained in this
supplement was accurate at the time
of publication. We reserve the right
to change features, operation
and/or functionality of any vehicle
specification at any time. Your Ford
dealer is the best source for the most
current information. For detailed
operating and safety information,
please consult your Owner's Manual.
F O R D R A N G E R R A P T O R
S U P P L E M E N T
3/22/18 10:14 AM

Advertisement

Table of Contents
loading

Related Manuals for Ford Ranger Raptor 2018

Summary of Contents for Ford Ranger Raptor 2018

  • Page 1 We reserve the right to change features, operation and/or functionality of any vehicle specification at any time. Your Ford dealer is the best source for the most current information. For detailed operating and safety information, please consult your Owner’s Manual.
  • Page 2 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2018 All rights reserved. Part Number: JB3B 19A285 CKA 201804 20180427214116...

  • Page 4: Table Of Contents

    Table of Contents Introduction Roadside Emergencies About This Supplement ........3 Towing Points ..........28 Ford Performance ..........3 Vehicle Care At a Glance Cleaning the Exterior ........29 Instrument Panel Overview ......4 Wheels and Tires Unique Features ..........5 Wheels ..............30 Steering Wheel Tire Care ............30 Information Display Control ......7...
  • Page 5 Ranger Raptor (TKD) Raptor, Vehicles Built From: 21-05-2018, JB3B 19A285 CKA enPHI, Edition date: 201804, First-Printing...

  • Page 6: Introduction

    Thank you for choosing Ford Performance. to you on your vehicle. If you have owned or leased a Ford Performance vehicle before, welcome back. If this is your first Ford Performance FORD PERFORMANCE vehicle, welcome to the family.

  • Page 7: At A Glance

    At a Glance INSTRUMENT PANEL OVERVIEW Right-hand Drive E266449 Paddle Shifter. Air vents. Direction indicators. Multi-function display. Lighting control. Windshield wipers. Hood release lever. Paddle Shifter. Steering wheel adjustment lever. Audio control. Voice control. Horn. Instrument cluster. Push button ignition switch. Cruise control switches.

  • Page 8: Unique Features

    At a Glance Left-hand Drive E266448 Horn. Air vents. Climate control. Multi-function display. Direction indicators. UNIQUE FEATURES Paddle Shifter. Cruise control switches. Powertrain Instrument cluster. • 2.0L BiTurbo Diesel. Audio control. Voice control. • 10-speed automatic transmission. Paddle Shifter. • Unique transmission calibration.
  • Page 9 At a Glance • Fox Racing 2.5 inch, internal bypass front shocks. • Fox Racing 2.5 inch, internal bypass, remote reservoir rear shocks. • Long travel coil spring front and rear suspension. • Unique brake system with front and rear vented disc brakes. •...

  • Page 10: Steering Wheel

    Steering Wheel INFORMATION DISPLAY CONTROL Terrain Control Right-hand Drive E266175 Left-hand Drive E266226 See Terrain Control (page 19). Ranger Raptor (TKD) Raptor, Vehicles Built From: 21-05-2018, JB3B 19A285 CKA enPHI, Edition date: 201804, First-Printing...

  • Page 11: Information Displays

    Information Displays GENERAL INFORMATION Average Speed (If Equipped) Your Ford Performance vehicle tracks your average driven speed. Average Speed is available on your Tripcomp./fuel menu. Press and hold the OK button to reset your average speed. INFORMATION MESSAGES E205893 Note: Depending on your vehicle options...

  • Page 12: Unique Driving Characteristics

    Unique Driving Characteristics Enabling Auto-Start-Stop AUTO-START-STOP (If Equipped) The system is automatically enabled every The system helps reduce fuel consumption time you start your vehicle if the following by automatically shutting off and restarting conditions are met: the engine while your vehicle is stopped. •...
  • Page 13 Unique Driving Characteristics Disabling Auto-Start-Stop Automatic Engine Restart Any of the following conditions will result in an automatic restart of the engine: • Your foot is removed from the brake pedal. • You press the accelerator pedal. • You press the accelerator and the brake pedal at the same time.

  • Page 14: Transmission

    Transmission Press the button (1) on the transmission AUTOMATIC TRANSMISSION selector lever (2) to select reverse (R) or drive (D). After the transmission is in drive (D), you can then press the button (1) on WARNING: Always fully apply the the transmission selector lever (2) again parking brake.
  • Page 15 Transmission E269194 To exit SelectShift mode, return the transmission selector lever to drive (D). When your vehicle is stationary, you can only select the 1st and 2nd gears. Manual shifting is sequential, therefore gears cannot be skipped. Live in Drive (LID) - Functionality With the transmission selector lever in drive (D), use the (+) or (-) paddles to temporarily change a gear up or down for...

  • Page 16: Four-Wheel Drive

    Four-Wheel Drive Use for off-road driving. PRINCIPLE OF OPERATION Note: Do not use on paved or sealed roads. The four-wheel drive system in your vehicle We recommend that you frequently is a part-time system activated using the inspect your vehicle's chassis components rotary switch mounted in the centre if your vehicle is subject to off-road use.
  • Page 17 Four-Wheel Drive 2. Place the transmission in neutral (N). If Your Vehicle leaves the Road 3. Turn the transfer shift switch from 2H If your vehicle leaves the road, reduce your to 4L or 4L to 2H. vehicle speed and avoid severe braking. When your vehicle speed has been reduced During the shift the indicator lamp will ease your vehicle back onto the road.
  • Page 18 Four-Wheel Drive Sand When driving through water, determine the depth and avoid water higher than the When driving over sand, try to keep all four bottom of the wheel rims. If the ignition wheels on the most solid area of the trail. system gets wet, your vehicle may stall.
  • Page 19 Four-Wheel Drive Four-wheel drive vehicles have advantages over two-wheel drive vehicles in snow and ice but can skid like any other vehicle. Should you start to slide while driving on snowy or icy roads, turn the steering wheel in the direction of the slide until you regain control.
  • Page 20 Four-Wheel Drive Maintenance and Modifications The suspension and steering systems on your vehicle have been designed and tested to provide predictable performance whether loaded or empty. For this reason, we strongly recommend that you do not make modifications such as adding or removing parts (i.e.

  • Page 21: Rear Axle

    Rear Axle Note: The system can be used in any drive ELECTRONIC LOCKING mode (2H, 4H or 4L). DIFFERENTIAL If the system is selected when driving above 40 km/h, the request is stored and Note: Do not operate the system on sealed will be engaged when the vehicle speed roads.

  • Page 22: Terrain Control

    Terrain Control Use the control on the steering wheel to PRINCIPLE OF OPERATION access the system and to select a mode. The system delivers a driving experience After you move to the desired mode, through a suite of sophisticated electronic remain on that mode to select it.
  • Page 23 Terrain Control Sport - For aggressive on-road Note: If you select the Mud and Sand, Baja driving. Sport mode increases or Rock mode, the traction and stability E270070 throttle response, provides a control performance degrades and the sportier steering feel, along with quicker warning indicator illuminates in the shifting.
  • Page 24 Terrain Control Sport Mud/Sand System Configuration System Configuration 4X2. Available. 4X2. Not available. 4X4 High. Not available. 4X4 High. Available. 4X4 Low. Not available. 4X4 Low. Available. Traction Control Normal. Traction Control Mud Ruts. System (TCS). System (TCS). Electronic Stability Electronic Stability Control (ESC).
  • Page 25 Terrain Control Rock System Configuration 4X2. Not available. 4X4 High. Not available. 4X4 Low. Available. Traction Control Off. System (TCS). Electronic Stability Off. Control (ESC). Available below 30 km/h if switched Electronic Locking Rear Differential Automatically (ELRD). disengages above 40 km/h. Steering Effort.

  • Page 26: Towing

    Towing RECOMMENDED TOWING WEIGHTS Towing Capacities Gross Max Tow Max Tow Variant Transmission Drive Combination Without With Trailer Mass Trailer Brake Brake 10-Speed Four- 2.0L TDCi Automatic wheel 3.73 5,350 kg 750 kg 2,500 kg Diesel Transmission drive Ranger Raptor (TKD) Raptor, Vehicles Built From: 21-05-2018, JB3B 19A285 CKA enPHI, Edition date: 201804, First-Printing...

  • Page 27: Driving Hints

    Even if your local law controlled manner. Sudden inputs to does not prohibit alcohol use while the controls can cause loss of traction driving off-road, Ford strongly or upset the vehicle, especially while recommends against drinking if you on sloped terrain or while crossing plan to off-road.

  • Page 28: Ranger Raptor (Tkd) Raptor, Vehicles Built From: 21-05-2018, Jb3B 19A285 Cka Enphi, Edition Date: 201804, First-Printing

    Driving Hints Crossing Obstacles Water Wading • Review the path ahead before Your vehicle is designed to operate in water attempting to cross any obstacle. It is depths up to 850 mm. However, as the best if the obstacle is reviewed from water depth increases, vehicle speed must outside the vehicle so that there is a be reduced to avoid potential vehicle...

  • Page 29: Ranger Raptor (Tkd) Raptor, Vehicles Built From: 21-05-2018, Jb3B 19A285 Cka Enphi, Edition Date: 201804, First-Printing

    Driving Hints High Speed Off-Roading It is important that you take the time to become familiar with the controls and The off-road driving discussed thus far dynamics of your vehicle before focuses on the type of events typically attempting higher speed off-roading. encountered during slow speed off-road Some points to consider: driving conditions.

  • Page 30: Ranger Raptor (Tkd) Raptor, Vehicles Built From: 21-05-2018, Jb3B 19A285 Cka Enphi, Edition Date: 201804, First-Printing

    Driving Hints After Off-Road Driving • As speed increases, it is wise to look farther ahead of the vehicle so that It is important to complete a full vehicle there is time to react to oncoming inspection after off-road driving. Some obstacles.

  • Page 31: Roadside Emergencies

    Roadside Emergencies TOWING POINTS The towing points on your vehicle are enthusiast rated. E266677 Recovery Rating Hook Front (A) 4,635 kg Rear (B) 3,863 kg Ranger Raptor (TKD) Raptor, Vehicles Built From: 21-05-2018, JB3B 19A285 CKA enPHI, Edition date: 201804, First-Printing...

  • Page 32: Vehicle Care

    Vehicle Care CLEANING THE EXTERIOR Note: Do not use front bumper openings as a step. This could cause damage to your vehicle. Do not drive your vehicle through an automated, commercial car wash due to the vehicle s tire width and track. Wash your vehicle by hand, or by using a touchless commercial wash with no mechanical tracks on the floor.

  • Page 33: Wheels And Tires

    In the event that you encounter an provide the performance you expect in a abnormally harsh impact, inspect the Ford Performance vehicle. These tires are outside tire wall of your wheels, both optimized for both on and off-road inside and out, for damage.

  • Page 34: Using Snow Chains

    Wheels and Tires • Do not overload your vehicle. Note: Uneven tread depth between the Maximum vehicle and axle weights are front and rear tires may lead to degradation listed on the tire information placard. in 4WD engagement and disengagement performance, additional noise from the •...

  • Page 35: Changing A Road Wheel

    Wheels and Tires Vehicle Tire Approved Chain Model Only Raptor LT 285/70R17 Konig Polar 296 4.35mm 15mm chain link with 4.35mm wire thickness Note: The anti-lock brake system continues to operate normally. WARNING: It is recommended that the wheels of the vehicle be chocked, and Vehicles with Stability Control that no person should remain in a vehicle When stability control is on, your vehicle...
  • Page 36 Wheels and Tires Vehicle Jack Assembly E263487 Do not use the jack if it is visibly damaged Wheel Brace. or does not operate freely. Replace the damaged jack with a jack specified for use Jack Handle and Extensions. on your vehicle if you detect these Vehicle Jack.
  • Page 37 Wheels and Tires 4. Remove the locking strap. 5. Remove the jack and tools. Spare Wheel Note: If the spare wheel is not the same type and size as your vehicle road wheel, drive the shortest distance possible. Note: Do not fit more than one spare wheel on your vehicle at any one time.
  • Page 38 Wheels and Tires E269303 E269304 2. Insert the jack handle into the guide 3. Pass the bracket and cable through the hole. Turn counterclockwise until the wheel opening. wheel rests on the ground, and there is Jacking and Lifting Points slack in the cable.
  • Page 39 Wheels and Tires E266725 A. Emergency use only. Removing a Road Wheel B. Maintenance. WARNING: Park your vehicle in such a position that neither the traffic nor you are hindered or endangered. WARNING: Make sure that the wheels are pointing straight ahead. WARNING: If your vehicle has a manual transmission, shift into first or reverse gear.
  • Page 40 Wheels and Tires Note: Do not lay alloy road wheels face 6. Remove the wheel nuts and the road down on the ground. wheel. Installing a Road Wheel WARNING: Use only approved wheel and tire sizes. Using other sizes could damage your vehicle.

  • Page 41: Technical Specifications

    Wheels and Tires Note: If the spare wheel is different in size or construction to the road wheels, replace it as soon as possible. Stowing the Flat Tire Note: Do not use power tools on the spare wheel winch input drive. Place the wheel flat on the ground, with the outer face of the wheel facing 2.

  • Page 42: Capacities And Specifications

    Capacities and Specifications VEHICLE DIMENSIONS E266558 Item Dimension Specification Maximum length 5,398 mm Overall width excluding 2,028 mm exterior mirrors Overall height 1,873 mm Ranger Raptor (TKD) Raptor, Vehicles Built From: 21-05-2018, JB3B 19A285 CKA enPHI, Edition date: 201804, First-Printing...
  • Page 43 Capacities and Specifications Item Dimension Specification Wheelbase 3,220 mm Front Track 1,710 mm Rear Track 1,710 mm Ranger Raptor (TKD) Raptor, Vehicles Built From: 21-05-2018, JB3B 19A285 CKA enPHI, Edition date: 201804, First-Printing...
  • Page 44 Water Wading............25 Electronic Locking Differential....18 Puncture See: Changing a Road Wheel......32 Flat Tire See: Changing a Road Wheel......32 Ford Performance..........3 Four-Wheel Drive..........13 Rear Axle............18 Recommended Towing Weights....23 Principle of Operation..........13 Roadside Emergencies........28 Ranger Raptor (TKD) Raptor, Vehicles Built From: 21-05-2018, JB3B 19A285 CKA enPHI, Edition date: 201804, First-Printing...
  • Page 45 Index Snow Chains Washers See: Using Snow Chains........31 See: Cleaning the Exterior.........29 Spare Wheel Wheel Nuts See: Changing a Road Wheel......32 See: Changing a Road Wheel......32 Steering Wheel...........7 Wheels and Tires...........30 Technical Specifications........38 Wheels...............30 Technical Specifications See: Capacities and Specifications....39 Terrain Control..........19 Principle of Operation.........19 Tire Care............30...
