Sport - For aggressive on-road
driving. Sport mode increases
E270070
throttle response, provides a
sportier steering feel, along with quicker
shifting. The transmission also holds gears
longer, helping your vehicle accelerate
faster.
Off-Road Modes
Note: Off-Road Modes are to be used only
for off-road terrains.
Grass/Gravel/Snow - For less
than ideal road conditions, such
E266359
as snow or ice covered roads.
This mode inspires confidence without
taking away from driving pleasure. This
mode prompts you to put your vehicle in
4H and engages the electronic locking
differential to lower throttle response and
optimize shifting for slippery surfaces.
Mud/Sand - For navigating tight
trails and over obstacles.
E270073
Mud/Sand mode prompts you
to put your vehicle in 4H and engages the
electronic locking differential for improved
off-road capability, and provides a
comfortable steering feel.
Baja - For high speed off-road
driving. Baja mode prompts you
E270074
to put your vehicle in 4H and
optimizes the throttle control for better
response and torque delivery.
Rock - For optimum
rock-climbing ability. Rock mode
prompts you to put your vehicle
E270075
in 4x4 Low and engages the electronic
locking differential. Rock mode optimizes
the throttle and transmission response to
provide you additional control of your
vehicle.
Ranger Raptor (TKD) Raptor, Vehicles Built From: 21-05-2018, JB3B 19A285 CKA enPHI, Edition date: 201804, First-Printing
Terrain Control
Note: If you select the Mud and Sand, Baja
or Rock mode, the traction and stability
control performance degrades and the
warning indicator illuminates in the
instrument cluster.
Note: The Terrain Control System has
diagnostic checks that continuously monitor
the system for proper operation. Certain
drive modes are not available based on gear
shifter position. If a mode is unavailable due
to a system fault, the mode defaults to
Normal.
Terrain Control Mode
Configurations
Normal
4X2.
4X4 High.
4X4 Low.
Traction Control
System (TCS).
Electronic Stability
Control (ESC).
Electronic Locking
Rear Differential
(ELRD).
Steering Effort.
20
System
Configuration
Available.
Available.
Available.
Normal.
On.
Available below
30 km/h if switched
on.
Automatically
disengages above
40 km/h.
Normal.
