5
9
15
11
13
42" MODEL R. E. RIDER SERIES 22
8
14
10
12
ITEM
PART NO.
DESCRIPTION
1
5-8951
2
7-3584
3
1-7147
4
1-2234
5
1-2332
6
9-1502
7
3-1732
8
1-1817
9
4-0433
10
2-3895
11
2-3522
12
4-0434
13
1-1201
14
1-1035
15
1-1013
7
13
ASSEMBLY, Rear Tire & Rim (Includes Items 2, 3, & 4)
TIRE, 16 x 6.50-8 (Kenda)
RIM, Ext. Wide, (For 16/7.50 x 8 Tire)
VALVE, Air (Snap-in)
CLAMP, Right Hand
BOLT, 1/2-20 x 3/4" Lug (Grade 5) (6)
BOOT, Right Hand
SEAL, Oil
HUB, Rear Wheel (Right Hand)
CAP, Hub
CAP, Hub (Left Hand)
HUB, Rear Wheel (Left Hand)
NUT, 5/16-24 Hex Center Lock
BOLT, 5/16-24 x 1-5/8" Tapered (Left Hand)
BOLT, 5/16-24 x 2" Tapered (Right Hand)
3
WHEELS - REAR
1
ASSEMBLY
2
6
4
MANUAL No. 06130
3
