Snapper 421622BVE Parts Manual page 11

ITEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
--
--
NOTE: See Pages 12 &13 For Illustration Of Brake Lever Assembly And Related Parts.
42" MODEL R. E. RIDER SERIES 22
PART NO. DESCRIPTION
5-2683 ASSEMBLY, Chain Case (Includes Items 2 Thru 13,
& 15, 16, 31, 30)
4-1136 CASE, Sprocket (Weldment)
2-8761 GASKET, Case Cover
1-1121 WASHER, Belleville
1-0756 BEARING, Ball (2)
1-8963 SPROCKET & SHAFT
1-0614 KEY, 1/8 x 5/8" Woodruff
3-9778 COVER, Chain Case
1-0942 BEARING, Needle (2)
1-1086 WASHER, Nylon Thrust (2)
4-0355 HUB & SPROCKET (Weldment)
1-0941 CHAIN
9-0307 SCREW, #10-24 x 5/8" Hex Washer Self-Tap (10)
1-1024 PLUG, Oil Fill & Check
2-2785 ROLLER
1-0776 RING, 1/2" External Retaining
5-9183 ASSEMBLY, Left Hand Fender (Includes items 18 & 19)
3-7285 FENDER, Left Hand
5-2827 ASSEMBLY, Axle Bearing (Incl. items 20 thru 23)
7-4184 BEARING, Left Hand Fender
1-3324 FITTING, Lube (for 3/16" diameter hole)
7-4500 SEAL, Dust/Grease Axle
7-4182 BEARING, 3/4" I. D. DX (2)
1-2271 WASHER, Shim (As Required)
1-1070 ROD, Cross-Tie
1-2332 CLAMP, Boot (2)
1-7084 BOOT, Oil Seal
1-1071 WASHER, Thrust Nylon
1-1072 WASHER, Thrust
9-1505 NUT, 5/8-18 Hex Nyloc
1-0969 NUT, 5/16-24 Hex Flange Lock
1-9260 O-RING (2)
2-7981 WASHER, Wave
6-1017 GREASE , SNAPPER Transmission (4 oz. Required)
5-1451 ASSEMBLY, Left Hand Fender (Includes Left Hand Fender
P.N. 3-7958 & Ball Bearing P.N. 1-4624)
CHAIN CASE, L. H. FENDER
11
