WHEELS - FRONT
10
7
4
11
MANUAL No. 06130
5
9
12
ITEM
PART NO.
1
5-8943
2
7-3563
3
1-7146
4
1-1807
5
1-2234
6
1-4669
7
1-0935
8
1-1022
9
1-1032
10
3-1038
11
9-1516
12
1-0821
6
DESCRIPTION
ASSEMBLY, Front Tire & Rim (11.0") (Includes Items 2 Thru 6)
TIRE, Pneumatic 11 x 4.00-4 (Kenda)
RIM (For 11.0 x 4.0 x 4 Tire)
BEARING, Ball
VALVE, Air (Snap-In)
FITTING Lube
WASHER (3)
CAP, Hub
SEAL, Felt
CAP, Dust
COTTER-PIN, 5/32 x 1"
TUBE, Inner (For 4.10/3.50 x 4 Tire)
2
1
ASSEMBLY
2
3
4
7
42" MODEL R. E. RIDER SERIES 22
8
