- Page 1 OWNER’S MANUAL SMT9.2HR SMT9.2HRAB Model Name SMT9.2HR/SMT9.2HRAB Serial Number Purchase Date Write down for future reference. treadmillbynet.com Smoothfitness.com SALES: (888) 559-8810 SERVICE: (888) 340-0482 Smooth Fitness Part# 15-0128 Mt. Laurel, NJ...
-
Page 2: Table Of Contents
Table of Contents Information Model Specification Sheet Important Safety Information Before You Start Warm Up Exercises Assembly Instructions Power Requirements Console Functions and General Descriptions Console Layout Program Operating Instructions—Quick Start Manual Mode Program Operating Instructions—Program Mode Program Operating Instructions—Customizing Pre-set Programs Program Operating Instruction—... -
Page 3: Model Specification Sheet
Warranty Residential Labor Warranty Light Institutional Warranty Width x Length in inches User Weight Warranty Frame Model Specification Sheet SMT9.2HR 3.0HP Five Multi-function LED Windows, With green Pace function 0 to 15% .6 to 10 MPH 2-Ply 20” x 56.5”... -
Page 4: Important Safety Information
The treadmills have a user maximum capacity of 400 pounds. The treadmill should only be used on a level surface and is intended for indoor use only. The treadmill should not be placed in a garage, patio, or near water and should never be used while you are wet. -
Page 5: Before You Start
Do not stand on the walking belt while pressing the Power button or Start/Stop button. Always adjust the speed of the treadmill in small increments as this treadmill is capa- ble of high speeds. If you are taking medication, consult your physician to see if the medication will affect your exercise heart rate. -
Page 6: Warm Up Exercises
Warm Up Exercises EXERCISE GUIDELINES WARNING! Before beginning this or any exercise program, you should consult your physician. This is especially important for individuals over the age of 35 or individuals with pre-existing health prob- lems. Warming up prepares the body for the exercise by increasing circulation, supplying more oxygen to the muscles and raising body temperature. -
Page 7: Assembly Instructions
2. Now tighten the buttonhead screws securely from step 1. 3. Install motor hood cover using 5/8” phillips head screws (8 screws). Be sure the treadmill is level to the floor. The rear feet can be adjusted to level the treadmill. Assembly is now complete! -
Page 8: Power Requirements
This treadmill can be seriously damaged by sudden voltage changes in your home’s electrical power. Voltage spikes, surges, and noise interference can result from weather conditions or from other appliances being turned on or off. To reduce the possibility of treadmill damage, always use a surge protector (not included) with your treadmill. -
Page 9: Console Functions And General Descriptions
The Speed Bar allows the user to adjust speed quickly. The Speed Bar works in all manual and program modes. To use the Speed Bar, the belt must already be moving. Press the desired speed (2 through 8), and the treadmill will slowly reach the speed selected. -
Page 10: Console Layout
Console Layout SMT9.2HR and SMT9.2HRAB IMPORTANT! Please note that the Console Overlay used on the SMT9.2HRAB will read SMT9.2HR. The only difference in the two models is the type of walking belt used. The SMT9.2HRAB uses a thick, orthopedic-style belt. To verify the model you have received, review the SERIAL NUMBER LABEL located on the console upright. -
Page 11: Program Operating Instructions-Quick Start Manual Mode
Pre-Set Program Descriptions Rolling Hills Program The Rolling Hills Program is designed to vary treadmill elevation while maintaining a constant walk- ing belt speed. Speed Intervals Program The Speed Intervals Program is designed to vary treadmill speed while maintaining a constant ele- vation. -
Page 12: Program Operating Instructions-Customizing Pre-Set Programs
Program and Operating Instructions PROGRAM MODE continued Customizing Pre-Set Programs Customizing programs in P1 and P2 Mode: Each pre-set program can be customized in the P1 or P2 mode. After making the program selection, the top right window (CALO- RIES / DISTANCE) will read “OP.” ”OP” refers to “original program” and is preset. Press the same program button once more, and the CALORIE / DISTANCE window will read P1. -
Page 13: Program Operating Instructions-Heart Rate Mode
HEART RATE MONITOR MODE The treadmill may at any time be used in the Heart Rate Monitor Mode. If the signal from the chest strap is detected, heart rate BPM will be displayed in the INCLINE window. The incline will only be briefly displayed if manual or program changes are initiated. -
Page 14: Program Instructions Heart Rate Mode
Program Instructions Heart rate Mode TARGET UP WORKOUT TIME CALORIES/DISTANCE START/STOP POWER TARGET DOWN TARGET ARROWS PAUSE ENTER PROGRAM INCLINE WINDOW... -
Page 15: Program Profiles
SPEED INCLINE 1 2 3 4 5 6 7 8 9 1 0 The Speed Intervals Program is designed to vary treadmill speed while maintaining a con- stant elevation. SPEED INCLINE 1 2 3 4 5 6 7 8 9 1 0 The Weight Loss Program is designed to alternate between the programmed speed and incline. -
Page 16: Belt Adjustments And Tension
WALKING BELT IS SHIFTING TO THE LEFT (Diagram 1) First, turn treadmill on to run at 1 mph. Using the hex key provid- ed, turn the left rear roller adjustment bolt ¼ turn in the clockwise direction. -
Page 17: Maintenance Instructions
6” from the front of the treadmill. Apply the silicone spray to the walking board, moving from the front of the treadmill to the rear. Repeat this on the other side of the belt. Spray approximately 4 seconds on each side. -
Page 18: Troubleshooting Guide
(Refer to “Power Requirements” on page 8) 3 Check the circuit breaker located on the front of the treadmill. If the switch protrudes, it has tripped. Wait five minutes and then press the switch back in. -
Page 19: Parts And Exploded View
Parts & Exploded View Left Side Extrusion Rail Right Side Extrusion Rail Treadmill Belt AeroBelt Front Roller Assembly Rear Roller Treadmill Deck Left End Cap Right End Cap Rear Adjustable Foot (2) Main Frame Bottom Motor Pan Part # 05-0045... -
Page 20: Warranty And Registration
