How To Check Tire P Deviation; Ressure , Temperature And - BENDIX SmarTire Operator's Manual

H C
OW TO HECK
D
EVIATION
You can navigate through the SmarTire display by following the steps below.
1. Starting from
Ready Screen, press the right
button once and the display
will show the first axle screen
starting at the front of the
vehicle with left tire position
highlighted.
temperature
deviation
displayed for the selected tire.
2. To move to the next wheel on
the axle, press the right button
once. Each time the right button is pushed, the next tire in sequence will
be selected and its information displayed. Pressing the right button when
the last tire on the axle is selected will re-select the first tire on that axle.
3. To move to the next axle on the vehicle, press the left button once. Once
again, pressing the right button will scroll the display to the next tire on
that axle. Each time the left button is pressed the display will show the
next axle on the vehicle. When the left button is pressed from the last
axle screen, the first axle will once again be shown. To exit back to the
"TPMS Ready" screen, press the center button once.
BW8002
T P
IRE RESSURE
the TPMS
The pressure,
and pressure
values are then
, T
EMPERATURE AND
P
RESSURE
LED for Alerts
Screen
Right Button
Center Button
Left Button
Page 18
