Alert Icons - BENDIX SmarTire Operator's Manual

A I
LERT CONS
–
Triangle When displayed on the individual axle screen, this icon indicates a
First Level Alert (FAL) is active.
Tire with Exclamation Point - This icon is shown on the individual axle
screen and indicates a Second Level Alert (SAL)/Critical Low Pressure Alert
is active.
Thermometer – This icon is shown on the individual axle screen and
indicates a High Temperature Alert is active.
Low Battery – This icon is shown on the individual axle screen and indicates
a sensor with a low battery.
BW8002

Alert Icons

First Level Alert (FAL)
Second Level Pressure Alert (SAL)
High Temperature Alert
Sensor Low Battery
Page 16
