- Page 1 OWNER’S MANUAL Model No. 47003 10/2/50 AMP MANUAL BATTERY CHARGER ENGINE STARTER CAUTION: Read and Follow All Safety Rules and Operating Instructions Before Every Use of this Product. Sears Canada, Inc., 222 Jarvis St., Toronto, Ontario, Canada M5B 2B8...
-
Page 2: Table Of Contents
If, within two years from the date of purchase this battery charger fails due to a defect in materials or work- manship, simply RETURN IT TO THE NEAREST SEARS STORE IN CANADA, and Sears will replace it, free of charge. -
Page 3: Important Safety Instructions
If this occurs, flush eyes immediately with running cold water for at least 10 minutes. Then immediately get medical attention. Sears 003 - Sch 549 11/2/95 – SAVE THESE INSTRUCTIONS – To reduce the risk of explosion, explosive gases, or injury while using your battery charger, follow the precautions listed below: •Do not disassemble charger. -
Page 4: Parts
Parts This section shows an illustration of your battery charger. Use it to become familiar with where all the parts are located, and what they look like. Replacement Parts List Sears 47003 Item Description Cover Heatsink/Diode Assembly Base AC Power Cord... -
Page 5: Before Using Your Battery Charger
•Check that the extension cord is properly wired and in good electrical condition. Sears 003 - Sch 549 11/2/95 • Make sure that the wire size is large enough for its length and for the AC ampere rating as specified in the accompanying chart. -
Page 6: Preparing Your Battery To Be Charged
A spark may be caused if all accessories in the vehicle are not completely turned off. NOTE: A marine battery installed in a boat must be removed and charged on shore. Sears 003 - Sch 549 11/2/95... -
Page 7: Using Your Battery Charger
Battery Charger our Battery Charger For best results from your battery charger, learn to use it properly. This section tells how to set the controls and how to charge a battery in or out of the vehicle. Setting the Controls... - Page 8 (1) from the chassis connection and, (2) from the battery post or terminal. 12. Clean and store the battery charger in a dry location. Charging your battery outside the vehicle: 1. Remove the battery from vehicle, making sure to disconnect grounded terminal first with all accessories and lights turned off in the vehicle.
-
Page 9: Calculating Charge Time
To convert Reserve Capacity to Amp Hours, divide Reserve Capacity by 2, and add 16: Amp Hours = Reserve Capacity + 16 Sears 003 - Sch 549 11/2/95 • Marine, or deep-cycle batteries are usually rated in Reserve Capacity (RC). -
Page 10: Using The Engine Start Feature
This will help prevent accidental damage to the cords and charger. 3. Occasional cleaning of the case of the charger with a soft cloth will keep the finish shiny and help prevent corrosion. Sears 003 - Sch 549 11/2/95... -
Page 11: Troubleshooting
Separate the clamps. Circuit breaker cycles when current draw is too high. Check for worn cables and replace if needed. Have a Sears technician test the battery. Correct connections. Use shorter or heavier extension cord. Sulfated battery will eventually take a normal charge if left connected. - Page 12 OWNER’S MANUAL Model No. 200.47003 When requesting service or ordering parts, always provide the following information: •Product Type •Model Number •Part Number •Part Description 0000000549-1195 10/2/50 AMP MANUAL BATTERY CHARGER ENGINE STARTER For information about troubleshooting Call toll-free from anywhere in the U.S.A. or Canada...
