- Page 1 OWNER’S MANUAL Model No. 200.71201 1.5 AMP MANUAL BATTERY CHARGER CAUTION: Read and Follow All Safety Rules and Operating Instructions Before Every Use of this Product. Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
-
Page 2: Table Of Contents
If, within two years from the date of purchase, this battery charger fails due to a defect in materials or workmanship, simply RETURN IT TO THE NEAREST SEARS STORE IN THE UNITED STATES, and Sears will repair or replace it, free of charge. -
Page 3: Important Safety Instructions
If this occurs, flush eyes immediately with running cold water for at least ten minutes. Then immediately get medical attention. Sears 201- Sch 506 1/9/98 – SAVE THESE INSTRUCTIONS – To reduce the risk of explosion, explosive gases, or injury while using your battery charger, follow the precautions listed below: •Do not disassemble charger. -
Page 4: Parts
Parts This section shows an illustration of your battery charger. Use it to become familiar with where all the parts are located, and what they look like. Replacement Parts List Sears 71201 Item Description Case Top Case Bottom AC Linecord... -
Page 5: Before Using Your Battery Charger
• Check that the extension cord is properly wired and in good electrical condition. Sears 201- Sch 506 1/9/98 • Make sure that the wire size is large enough for its length and for the AC ampere rating as specified in the accompanying chart. -
Page 6: Preparing Your Battery To Be Charged
A spark may be caused if all accessories in the vehicle are not completely turned off. NOTE: A marine battery installed in a boat must be removed and charged on shore. Sears 201- Sch 506 1/9/98... -
Page 7: Using Your Battery Charger
Using Your Battery Charger For best results from your battery charger, learn to use it properly. This section tells how to set the controls and how to charge a battery in or out of the vehicle. Setting the Controls SELECTOR SWTICH: A 2-way switch is used to set the charger for a 6 VOLT or 12 VOLT battery. - Page 8 (1) from the chassis connection and, (2) from the battery post or terminal. 11. Clean and store the battery charger in a dry location. Charging your battery outside the vehicle: 1. Remove the battery from vehicle, making sure to disconnect grounded terminal first with all accessories and lights turned off in the vehicle.
-
Page 9: Calculating Charge Time
To convert Reserve Capacity to Amp Hours, divide Reserve Capacity by 2, and add 16: Amp Hours = Reserve Capacity + 16 Sears 201- Sch 506 1/9/98 To calculate time needed for a charge: • Find the percent of charge needed. (A battery at 50 percent charge that will be charged to 100 percent needs another 50 percent (.50). -
Page 10: Maintenance And Care
This will help prevent acci- dental damage to the cords and charger. 3. Occasional cleaning of the case with a soft cloth will keep the finish shiny and help prevent corro- sion. Sears 201- Sch 506 1/9/98... -
Page 11: Troubleshooting
Unplug charger. Reconnect clips then plug in again and continue charging. Separate the clamps. Circuit breaker cycles when current draw is too high. Have a Sears technician test the battery. Correct connections. Continue charging. Buzz is not abnormal. Have charger tested by qualified technician. - Page 12 For the repair or replacement parts you need Call 7 am - 7 pm, 7 days a week 1-800-366-PART (1-800-366-7278) For the location of a Sears Repair Service Center in your area Call 24 hours a day, 7 days a week 1-800-488-1222...
