TouchMix Series
Quick Start Guide
Setting up TouchMix-30 Pro with a computer: Windows driver installation, iOS Core Audio configuration, iTunes playback, and DAW setup
This quick start guide is to help you set up a computer with the QSC TouchMix-30 Pro digital mixer—for example, to use it as a digital audio workstation (DAW).
If your computer runs on the Windows 7, Windows 8, Windows 8.1, or Windows 10 operating systems, you must first install the Windows driver before using the mixer
and computer together, including setting up the DAW. If your computer is a Mac, you may proceed and set up the DAW.
Non-DAW audio playback from computer
Stereo audio from Windows comes into the mixer on the stereo channel 2-Trk PB (audio channels 31 and 32).
TouchMix-30 Pro settings
To receive audio from the computer, press the mixer's Rec/Play button, touch Record Mode, and select Multitrack DAW. Audio from input channels 1 through 30
and from the 2-Trk Record output (channels 31 and 32) is always sent to the computer regardless of the mixer's Record Mode setting.
Installing the Windows Driver
The TouchMix-30Pro Windows Driver creates an interface between a TouchMix-30 Pro mixer and a computer running the Windows 7, Windows 8, Windows 8.1, or
Windows 10 operating system (recommended). The program supports up to 32 × 32 channels of digital audio between the mixer and the computer.
— Figure 1 —–
— Figure 2 —–
Installation
1. Extract the compressed folder to a new location.
2. Open the new uncompressed folder and run Setup.
3. The Windows operating system will ask if you want to allow the program to
make changes to your device. Click Yes.
4. The Setup Welcome window (Figure 1) will appear. Click Next > to
continue.
5. Accept the default location for the driver folder or browse to another location
(Figure 2). Click Install.
1
Advertisement
Related Manuals for QSC TouchMix Series
Summary of Contents for QSC TouchMix Series
-
Page 1: Quick Start Guide
Setting up TouchMix-30 Pro with a computer: Windows driver installation, iOS Core Audio configuration, iTunes playback, and DAW setup This quick start guide is to help you set up a computer with the QSC TouchMix-30 Pro digital mixer—for example, to use it as a digital audio workstation (DAW). - Page 2 — Figure 5 —– Configuring Apple iTunes Playback 1. In the list of audio output devices, select QSC TM30 Pro device in the Audio MIDI Setup list. Then right click on it and select Use this device for sound output. See Figure 6.
- Page 3 1. Open Logic Pro X. 2. To select the TouchMix-30 Pro as the audio device, go to Preferences > Audio. Click Devices. At Output Devices, select QSC TM30 Pro (Figure 4). Do the same at Input Devices (Figure 4). 3. Close Preferences.
- Page 4 Windows 1. Open Cubase. 2. To select TouchMix-30 Pro as the audio device, go to Devices > Device Setup… > VST Audio System. At ASIO Driver, select QSC TM30 Pro (Figure 10). 3. Click OK. 4. To assign TouchMix-30 Pro inputs to the Cubase buses, go to Devices > VST Connections >...
- Page 5 3. The Setup MIDI Audio Devices window will open (Figure 17). Select Pro Tools Aggregate I/O and select the QSC TM30 Pro. Set the sample rate to match the mixer’s sample rate (the TouchMix sample rate is configured in its Rec/Play screen).
- Page 6 © 2018 QSC, LLC. All rights reserved. TouchMix is a trademark, and QSC and the QSC logo are registered trademarks, of QSC, LLC in the U.S. Patent and Trademark office and other countries. Windows is a trademark of Microsoft Inc. iTunes, macOS, Logic Pro, and GarageBand are registered trademarks of Apple Inc. Cubase is a trademark of Steinberg Media Technologies GmbH.
