- Page 1 TECHNICAL MANUAL SBTOP riser branch module Art.1414 Passion.Technology. Design.
- Page 2 Warning Intended use This Comelit product was designed for use in the creation of audio and video communication systems in residential, commercial or industrial settings and in public buildings or buildings used by the public. Installation All activities connected to the installation of Comelit products must be carried out by qualified technical personnel, with careful observation of the indications provided in the Manuals / Instruction sheets supplied with those products.
-
Page 3: Technical Features
Description Art. 1414 is used to branch a second riser from the outgoing BUS line from the mixer. It can also act as line protection (only for SBTOP systems). The device can be used with Building kit and SBTOP systems and, as it is powered by the 2-wire bus, it does not need any additional power supply. -
Page 4: Operation And Programming
Connection BRANCH RISER OUTPUT TERMINALS 1414 BUS LINE OUTPUT BUS LINE INPUT / 4888C / 1210 Operation and Programming Line protection function In Building Kit systems, it is only compatible for the “riser branch” function (not “line protection”). f Jumpers JP1 and JP4 must be removed in order to activate this function. -
Page 5: System Performance And Layouts
Max. distance between Mixer and furthest internal unit. Table 1 Position of jumper JP3 Comelit Art. 4577/4579 1 mm² (Ø 1,2 mm AWG 17) 200 m (650 feet) Pos A 1,5 mm² (Ø 1,4 mm AWG 15) 150 m (495 feet) Pos A 1 mm²... - Page 6 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
