• All the equipment must only be used for the purpose it was designed for. Comelit Group S.p.A. declines any responsibility for improper use of the apparatus, for any alterations made by others for any reason or for the use of non-original accessories or materials.
Page 3
IKall module Art. 33410 - 33411 - 33412 for audio/video units .........................14 IKall series audio unit for VIP system Art. 1682 ............................14 IKall series colour audio/video unit for VIP system Art. 4682C .........................15 IKall call button module Art. 33433 - 33434 - 33436 ..........................15 IKall series digital call module for VIP system Art.
Page 4
7Stelle monitor Art. 6501 ..................................62 Accessing the installer menu ................................62 Configuring buttons ....................................62 Configuring functions ..................................62 Intercom function ..................................62 Self-ignition function ..................................62 Alarm function ....................................63 Lock-release function ...................................63 Actuator function ..................................63 Activate output function ................................63 Configuring the monitor ..................................64 VIP address ....................................64 About ......................................64 Reset configuration ..................................64 Special Settings ....................................64...
Chapter 1: Introduction to the VIP system What is the VIP system? The VIP system is the new IP video entry phone system combining powerful performance with ease of installation. The VIP network, based on a connection via Ethernet cable, connects an infinite number of users in simultaneous conversations and with no distance restrictions. It integrates a video entry phone system, burglar alarm, video surveillance, home automation and access control functions into a single system.
Power supply units and system connection accessories VIP system riser power supply unit 120 W Art. 1441A Power supply unit Art. 1441A, to power all accessories connected to the riser (not including external units). Terminal blocks for connection +V +V -V -V: Riser power supply terminals.
10 Mb extension Ethernet port. Used for the connection of distributors, such as repeaters, switches, internal units etc. + -: External power supply terminals. Connection of power supply unit Art. 1441 or Art. 1441A For correct operation of the system protecting Art. 1440, the riser must be connected with input on port IN1 and...
VIP system riser signal repeater module Art. 1447 The repeater module Art. 1447 is used to extend networks, making it possible to connect a VIP device at a greater distance than would be possible using a single section of point-to-point Ethernet and, if necessary, to connect two risers to each other. Technical characteristics Absorption Min.
Internal units Planux backplate Art. 6231 and Planux monitor Art. 6202 Technical characteristics Min. 0.7 W Max. 2.6 W (value for Absorption complete backplate + monitor product) Power supply 36/57 Vdc 3A Max. Dimensions H: 6.2 cm W: 7.2 cm D: 9 cm 1.
Easycom door-entry phone Art. 6203 Technical characteristics Absorption Min. 0.7 W Max. 2.6 W Power supply 36/57 Vdc 3A Max. Dimensions H: 16 cm W: 9.1 cm D: 2.7 cm The Easycom door-entry phone Art. 6203 manages up to 3 slave devices, not 4 as with other internal units. 1.
Powercom series external units Powercom module Art. 3331/0 - 1 - 2 for audio/video units Module designed for audio/video speaker units. Requires audio/video unit Art. 4662C to complete installation. Versions with 0, 1 and 2 buttons are available. Powercom series colour audio/video unit for VIP system Art. 4662C VIP system audio-video unit with terminal block, complete with spherical lens adjustable colour camera.
Powercom series backlit indication module Art. 3327 Backlit module with LEDs for various indications and additional 10 A relay. Technical characteristics Power supply 12 Vac 3A Temperature thresholds -30 / +55°C Dimensions H: 8.9 cm W: 11.2 cm D: 4 cm For wiring details, see page 29.
IKall series external units IKall module Art. 33400 - 33401 - 33402 for audio units Module with facility for audio porter units. Requires audio unit Art. 1682 to complete installation. Versions with 0, 1 and 2 buttons are available. IKall module Art. 33410 - 33411 - 33412 for audio/video units Module preset for audio/video speaker units.
IKall series colour audio/video unit for VIP system Art. 4682C VIP system audio-video unit with terminal block, complete with mini lens adjustable colour camera. 1. 8-pole cable connector Door lock connection terminals Technical characteristics NC / NO: Normally closed and normally open output terminals COM: Common terminal Power supply...
Vandalcom series external units Vandalcom series digital call module for VIP system Art. 3270, for Powercom external unit Art. 4662C Digital call module complete with electronic directory with graphic LCD display. Also functions as a coded electronic key module. The user code can be entered directly to make a call.
Vandalcom series digital call module for VIP system Art. 3272, for Powercom external unit Art. 4662C Digital call module complete with electronic directory with graphic LCD display. Name scrolling is carried out using two search buttons. Once the right name has been found, press the call button. Technical characteristics Power supply 12 Vac...
Module Art. 3268I/0 -1 - 2 designed for a/v units, iKall series Module designed for audio/video porter units. Requires audio/video unit Art. 4682C to complete installation. Versions with 0, 1 and 2 buttons are available. For wiring details, see page 33. Module Art.
VIP system accessories Remote camera module Art. 1445 Remote camera module Art. 1445 transmits the video signals received from 4 cameras. Video signal from cameras input terminals Input terminal for composite video signal from camera 1 Camera 1 shield terminal Input terminal for composite video signal from camera 2 Camera 2 shield terminal Input terminal for composite video signal from camera 3...
VIP system actuator relay module Art. 1443 IO module Art. 1443 can be used to control 1 relay on board the device itself or on board any expansion units Art. SK9071 connected to it. Terminal block for on-board relay inputs and output Earth terminal Input terminal 1 Input terminal 2...
PAL / NTSC video output module Art. 1446 Module Art. 1446 provides an outgoing video signal from the system in PAL or NTSC format. Terminal block for video outputs Technical characteristics Absorption Min. 0.7 W Max. 2.6 W Power supply 36/57 Vdc 3A Max.
Connection distances from Switch Art. 1440 / Repeater Art. 1447 to door-entry phones / door entry monitors Art. 1440 Art. 1447 250 m Connection distances from Switch Art. 1440 / Repeater Art. 1447 to switchboard Art. 1952 The connection distance varies depending on the port used on Switch Art. 1440. Art.
Guide to fi tting a UTP / STP RJ45 Direct network cable The recommended cables are: • UTP (Unshielded Twisted Pair): not protected from electromagnetic interference, maximum length 100 metres. We recommend the use of a Panduit cable code NUL5C04BU-CE. •...
Page 25
Fitting procedure 1. Most crimping pliers have two pairs of blades, one pair on one side to strip the wires and another pair on the other side to cut the wires. If the pliers do not allow you to cut the cable sheath, you should use a blade and cut the sheath with it, removing a length of about three centimetres. Be especially careful not to cut or scratch the wires inside the sheath;...
Page 26
6. Insert the wires into the RJ45 connector, still holding them tightly between your fingers. The connector tab should be facing downwards and not visible. The insulating sheath should just reach the edge of the connector. 7. Make sure the wires are fully inserted by inspecting the side of the transparent connector. Next, insert the connector into the crimping pliers and, using both hands, crimp the connector so as to secure the wires.
Chapter 4: Mounting external units and internal units During the installation of various products, we recommend a document is compiled to keep track of the location of the device within the system. An example of how to compile such a document is provided below: Mac Address VIP Address Description...
Mounting Vandalcom series external units Connecting audio-video unit Art. 4662C for use with buttons on Vandalcom external unit Art. 3269/1 - 2 Only applies to Art. 4662C Art. 2G60000616 Art. 2G60000120 included in Art. 4662C package 4662C blue 4662C 4662C 4662C 4662C 4662C...
Connecting audio unit 1682 or audio-video unit Art. 4682C for use with buttons on Vandalcom orange 1682 external unit Art. 3262I/1 - 2 and Art. 3268I/1 - 2 4682C 4682C white 4682C 1682 1682 4682C 4682C 4682C 4682C 4682C 4682C green 4682C white...
Art. 4662C Art. 3270 Art. 3272 Mounting digital directories Art. 3270 - 3272 with Powercom external unit Art. 4662C Vandalcom digital directories Art. 3270 and Art. 3272 can only be connected with Powercom external unit Art. 4662C Art. 4662C Art. 4662C Art.
Art. 4682C Art. 3070B Art. 3072B Mounting digital directories Art. 3070B - 3072B with IKall external unit Art. 4682C Art. 4682C 4682C Art. 3070B Vandalcom digital directories Art. 3070B and Art. 3072B can be connected with both IKall external unit Art. 4682C and Powercom external unit Art.
Mounting internal units 14,5 cm Mounting Planux monitor Art. 6202 with flush-mounted box Art. 6117 ALTO HAUT OBEN 4,5 cm 14,5 cm ALTO HAUT OBEN ALTO HAUT OBEN ALTO HAUT OBEN...
9 cm 9 cm 9 cm 9 cm 9 cm 9 cm Mounting Easycom monitor Art. 6203 16 cm 9 cm 16 cm 16 cm 16 cm 16 cm 16 cm 16 cm 2,8 cm 2,8 cm 2,8 cm 2,8 cm 2,8 cm 2,8 cm 2,8 cm...
Mounting Smart monitor Art. 6304 with wall bracket Art. 6320 13,8 cm 13,8 cm 13,8 cm 13,8 cm = 6,5 cm = 6,5 cm = 6,5 cm = 7 cm = 7 cm = 7 cm = 6,5 cm = 6,5 cm = 7 cm = 7 cm = 6,5 cm...
Mounting Smart monitor Art. 6304 with flush-mounted box Art. 6117 13,8 cm ALTO HAUT OBEN 13,8 cm ALTO ALTO HAUT HAUT OBEN OBEN = 6 cm = 6 cm = 10 cm = 10 cm = 6 cm ALTO = 10 cm HAUT OBEN = 6 cm...
Chapter 5: Installation programming Mac Address Every VIP product is identified by the factory with a unique code called the Mac address. The Mac address for the product is indicated by a label on the packaging box and another label applied directly to the product itself. VIP code Each system device must be programmed with a different code, called the VIP address.
Page 45
Dip switch programming table Codice / Codice / Codice / Codice / Dip switch ON Nome / Name Dip switch ON Nome / Name Dip switch ON Nome / Name Dip switch ON Nome / Name Code Code Code Code 1,7,8 2,7,8 1,2,7...
Manually programming buttons on external unit Art. 4662C The following procedure can be used to program buttons with VIP codes in the range between 1 and 255 only. To program higher VIP addresses, use VIP Manager software Art. 1449. 1. Perform the wiring for the external unit. 2.
Manually programming buttons on external unit Art. 4682C The following procedure can be used to program buttons with VIP codes in the range between 1 and 255 only. To program higher VIP addresses, use VIP Manager software Art. 1449. 1. Perform the wiring for the external unit. 2.
Assigning module index to additional button products Art. 3337/3 - 4 - 6 Follow the procedure below for each module Art. 3337 connected to the system. This procedure is used to assign an index to modules Art. 3337. The module index must then be used with the VIP Manager software to complete module programming (see manual for VIP Manager software Art.
Assigning module index to additional button products Art. 33433 - 33434 - 33436 Follow the procedure below for each module Art. 3343 connected to the system. This procedure is used to assign an index to modules Art. 3343. The module index must then be used with the VIP Manager software to complete module programming (see manual for VIP Manager software Art.
Programming internal units We recommend using VIP Manager software Art. 1459 to program the internal units. However, the main parameters of some internal units (Planux, 7Stelle, Smart and CPS) can be set directly on the product itself, where necessary. Planux monitor Art. 6202 and Smart monitor Art. 6304 (only with optional buttons Art.
• Programming the VIP code for main • Programming the VIP code for secondary Planux monitors Planux monitors 1. Access the installer menu. 1. Access the installer menu. 2. Select the Confi gure monitor menu using buttons 2. Select the Confi gure monitor menu using buttons INSTALLER MENU INSTALLER MENU Configure monitor...
• Confi guring 1 - 2 or Self-ignition buttons If the Self-ignition function is selected: 1. Press the button. 1 - 2 and Self-ignition buttons are programmed in the same way and can perform the same functions. The programming procedure, which CONFIGURE SELF-IGNITION applies to all 3 buttons, is described below.
• Confi guring the key button If the Lock-release function is selected: 1. Select the mode for which you wish to change the function using 1. Access the installer menu. and press to confi rm. 2. Select the Confi gure buttons menu by pressing and press CONFIGURE RELAY to access it.
• Confi guring the Privacy / Doctor button • Confi guring the intercom directory The Privacy function disables the ringtone for calls from the external unit 1. Access the installer menu. and intercom. The Doctor function, as well as disabling the door-entry phone 2.
• Confi guring the self-ignition directory 7. Enter the desired name using buttons to change the letters, to move right or left and to delete. 1. Access the installer menu. 2. Select the Special Settings menu by pressing and press EDIT ENTRY to access it.
• Confi guring the Actuator Directory 7. Enter the desired name using buttons to change the letters, to move right or left and to delete. 1. Access the installer menu. 2. Select the Special Settings menu by pressing and press EDIT ENTRY to access it.
• Setting the Door Open function 7. Press button to return to the previous menu. The function can be used to monitor the input of an external unit CONFIGURE DIRECTORY programmed with the Door Open function. When the input is opened or closed the key LED on the monitor lights up to indicate that the door is open.
• Setting the Alarm function • Setting the ringtone repetition This menu can be used to set the VIP address which will be contacted 1. Access the installer menu. when a priority call is sent. The procedure applies for all 4 call types; the 2.
• Setting call times • Setting automatic answer Within this menu, the time can be set for various functions. The Reply If the Automatic answer function is enabled, the audio will be activated wait time setting is shown below, as an example which also applies for automatically on receipt of a call from the external unit, internal unit or the other functions.
• Video memory records always • Activate output Planux monitors are equipped with an NC/NO output which can be If activated, this function can be used to record images and audio (10 programmed as monostable or bistable. This output can be controlled sec.) from the external unit, even if the call is answered.
• Call divert • Reset confi guration 1. Access the installer menu. This function can be used to restore the factory set values of the monitor, deleting all confi gurations applied in the meantime. 2. Select the Special Settings menu by pressing and press 1.
7Stelle monitor Art. 6501 • Configuring functions • Accessing the installer menu Press the name of the function to access the corresponding configuration menu. 1. Press PROGRAMMER to access the INSTALLER MENU. 2. Enter the password. 3. Press to confirm the password and access the INSTALLER ◊...
◊ Alarm function ◊ Actuator function This function can be used to link an alarm call to the button. This function is used to activate the relay output of an IO actuator module or that of an expansion device connected to it. ALARMS ACTUATOR Alarm...
◊ Reset confi guration • Confi guring the monitor This function can be used to restore the factory set values of the monitor, deleting all confi gurations applied in the meantime. ◊ VIP address This menu can be used to confi gure the VIP address of the internal unit. CONFIGURE MONITOR CONFIGURE MONITOR ViP address...
◊ Camera Directory CONFIGURE INTERCOM This menu can be used to manage the directory of cameras connected to the system. Configure Name CAMERAS DIRECTORY Configure ViP Address CAMERA 1 Master Slave 2. Access the Configure Name menu to set the name which will appear in the directory.
◊ Call divert ◊ Activate output This menu can be used to set the call divert function. This menu can be used to set the operating mode of the relay on board the monitor. CALL DIVERT ACTIVATE OUTPUT Configure ViP Address Normally open Wait time Normally closed...
• Programming the self-ignition key This function can be used to view the images transmitted by the camera for one or more devices connected to the system. Advanced Settings Advanced Settings Advanced Settings Camera ViP address Camera ViP address ViP address ViP address ViP address About...
Setting the call times Advanced Settings Set call times Expressed as min:sec Lock-release key 01:00 Awaiting reply (in) 00:30 OFF key disabled Awaiting ans.serv.act. 01:30 Conversation Call times 01:30 PQRS WXYZ Pause Call divert 00:30 Awaiting reply (out) ◊ Awaiting reply (in): wait time in which a call is ended if it is not answered.
Connecting Art. 3064/C with audio-video unit 4682C or audio unit Art. 1682 1595 120-230 V Use the cable included in Art. 3262I, Art. 3268I NC NO 4682C + 3268I 3064/C 1682 + 3262I Remove jumper 3064/C...
VIP/FM7 7Stelle output and input variant FIRE ALARM ALARM 6501 LED FUNCTION 12 Vdc 12 Vdc 100mA MAX 1441 1440 OUTOUT VIP/FMS Smart output and input variant ALARM PANIC 6304 LED FUNCTION 12 Vdc 100mA MAX 1441 1440 OUTOUT...
VIP/FME Easycom output and input variant ALARM 6203W/ 6203B 1441 1440 OUTOUT Connection of Vandalcom nameplate lighting lamp with audio unit Art. 1682 or audio-video unit Art. 4682C (Ikall) 1595 120-230 V NC NO 2G60001021 1682+3262I 4682C+3268I 16Vdc 12Vdc 2G60000653 MAX N°...
