- Page 1 Products Solutions Services BA01288G/00/EN/03.16 71329703 Valid as of software version: 3.1.0 and 4.0.0 Operating Instructions Tankvision Multi Scan NXA83B Local display Operation manual...
-
Page 2: Table Of Contents
Tankvision Multi Scan NXA83B Table of Contents Document information ....3 Target audience for this manual ....3 Version history . -
Page 3: Document Information
Tankvision Multi Scan NXA83B Document information Document information Target audience for this manual This manual should support the operating personal working on a regular basis with the Tank Gauging System understanding the possible tasks they have to perform and should serve as encyclopedia for those tasks. -
Page 4: Documentation
Document information Tankvision Multi Scan NXA83B Result of a sequence of actions A0018373 Symbols in graphics Symbol Meaning 1, 2, 3 ... Item numbers ... Series of steps A, B, C ... Views Hazardous area Indicates a hazardous area. A0011187... -
Page 5: Basic Safety Instructions
IT security measures in line with operators' security standards and designed to provide additional protection for the device and device data transfer must be implemented by the operators themselves. Endress+Hauser can be contacted to provide support in performing this task. Designated use 2.3.1... -
Page 6: Workplace Safety
The device complies with the applicable standards and regulations as listed in the EC declaration of conformity and thus complies with the statutory requirements of the EG directives. Endress+Hauser confirms the successful testing of the device by affixing to it the CE mark. -
Page 7: Identification
Tankvision Multi Scan NXA83B Identification Identification Product identification The following options are available for identification of the device: • Nameplate specifications • Order code with breakdown of the device features on the delivery note • Enter serial numbers from nameplates in W@M Device Viewer (www.endress.com/deviceviewer): All information about the device is displayed. -
Page 8: Order Code And Device Version
Identification Tankvision Multi Scan NXA83B Order code and device version To find out the version of your device, enter the order code indicated on the nameplate in the search screen at the following address: www.products.endress.com/order-ident Registered trademarks ® ® ®... -
Page 9: Introduction
Tankvision Multi Scan NXA83B Introduction Introduction The Multi Scan NXA83B is a configurable system designed for tank gauging and tank inventory management systems. It has been designed to fulfill a number of requirements some of which are listed below: • Act as a foreign device gateway allowing old legacy equipment and devices with proprietary interfaces to interface with modern devices using OPC and Ethernet Technology. -
Page 10: Multi Scan Nxa83B Model History
Introduction Tankvision Multi Scan NXA83B Multi Scan NXA83B model history There are currently two models of the Multi Scan: • Multi Scan NXA83B with 8 Channels, the current base production model with 8 serial ports. • Multi Scan NXA83B with 20 Channels, enhanced version for larger systems , with 2... -
Page 11: Operation
This will take approximately 2 minutes, during which time a number of windows boot messages will be displayed before automatically logging into the user account, at which point the Endress+Hauser wait message will be displayed. NXA83_E+H_Wait_Message Depending on the firmware version of the Multi Scan NXA83B, the top line of the splash screen will display a range of information, including: •... -
Page 12: Status Bar
Operation Tankvision Multi Scan NXA83B NXA83_Display_Grid-View It is perfectly safe to switch off the power without shutting down the operating system. The Multi Scan NXA83B contains an Enhanced Write Filter which protects the system from being corrupted due to a loss of power (see configuration document for description). - Page 13 Tankvision Multi Scan NXA83B Operation NXA83_Display_Grid-View_Both-Menus Each drop down list will display up to five items. Clicking on the button will display the next five items, if any more are available. The right hand list allows user to select a different display. Clicking on one of the items will display a pop-up menu with all displays of that type that have been configured for the Multi Scan NXA83B.
- Page 14 Operation Tankvision Multi Scan NXA83B NXA83_Display_Grid-View_Single-Tank-Overview-Menus Click on the buttons to select more display items. Click on the item in the pop-up menu to change the main display. NXA83_Display_Single-Tank The left hand drop down list displays all tanks in the database, and allows the user to select a tank to show in the single tank display.
-
Page 15: Grid View
Tankvision Multi Scan NXA83B Operation NXA83_Display_Single-Tank_Tank-Menu Grid View The GridView screens display data in a tabular format. The layout of the grid is fully configurable using the Tankvision Multi Scan Configurator tool, but cannot be changed by the user during normal operation. -
Page 16: Single Tank
Operation Tankvision Multi Scan NXA83B NXA83_Display_Grid-View A single tank display can be selected by clicking on the row for that tank in the grid. This will immediately display the single tank details for the selected tank. The GridView may be optionally set to display any moving tanks with a different background colour. - Page 17 The default formatting in the screens as shipped from Endress+Hauser is as follows: • Invalid Data: The appropriate diagnostic number will be shown preceded by "DN" and will be displayed with a red background.
- Page 18 Operation Tankvision Multi Scan NXA83B NXA83_Display_Alarm-Summary Any alarms that are active will be ticked and be displayed in red. Click on the Exit button to close the screen. 5.5.1 Commands Certain data fields may be configured so that clicking on the displayed value will show the gauge commands pop-up menu.
- Page 19 Tankvision Multi Scan NXA83B Operation NXA83_Display_Single-Tank_Displacer-Position 5.5.2 Manual Data Certain data fields may be configured so that they are in manual mode (i.e. displayed with the green colour). Clicking on the displayed value will reveal the manual entry window. NXA83_Display_Manual-Entry-Window This allows a new value to be entered via the touchscreen.
- Page 20 Operation Tankvision Multi Scan NXA83B 5.5.3 Multi-Element Display In the default configuration there is a second Single Tank screen available, called "Multi Elements", which can be used to view multi-element temperatures from gauges that support that function. NXA83_Display_Grid-View_Single-Tank-Overview-Menus_Multi-Elements NXA83_Display_Multi-Element-Temperature-View Endress+Hauser...
-
Page 21: Reports
Tankvision Multi Scan NXA83B Operation Reports A range of reports may be configured using the Tankvision Multi Scan Configurator tool, which are then available to be viewed or printed on demand by a user during normal operation. The reports are fully configurable using the same layout as gridviews, refer to the Multi Scan NXA83B Configuration Manual (BA01291G) for details. -
Page 22: Alarms
Operation Tankvision Multi Scan NXA83B NXA83_Display_Print-Preview Reports may also be configured to be printed automatically (→ ä 23). Alarms When an alarm occurs in the system a pop-up window will be displayed. Where multiple alarms are active they are displayed in order of severity, Critical first then High and finally Low level alarms. -
Page 23: Scheduling
Tankvision Multi Scan NXA83B Operation 5.7.1 Event Log A historical log of all alarms and events is saved on disk. To view these events click on the arrow on the right hand Screens menu, then click on the icon. Select a date, those days in bold contain historical alarms/events. -
Page 24: Security
Operation Tankvision Multi Scan NXA83B Scheduled gauge commands and report are configured using the Tankvision Multi Scan Configurator tool, refer to Multi Scan NXA83B Configuration Manual (BA01291G) for details. Security If security has been enabled in the Multi Scan NXA83B database (by default it is disabled) the user may be required to login to perform certain actions, such as gauge commands or manual data entry. - Page 25 Tankvision Multi Scan NXA83B Operation Enter the correct password using the onscreen keyboard and click OK. The current login account will be displayed on the status bar at the bottom of the screen. NXA83_Display_Single-Tank_Logout Select the button from the screens menu to log out.
-
Page 26: Return
The device must be returned if repairs or a factory calibration are required, or if the wrong device has been ordered or delivered. According to legal regulations, Endress+Hauser, as an ISO-certified company, is required to follow certain procedures when handling returned products that are in contact with medium. -
Page 27: Index
Tankvision Multi Scan NXA83B Index Alarms......... 22 Commands . - Page 28 71329703 www.addresses.endress.com...
