  • Page 1 Owner’s Manual Model No. 16011709000 CT900 ENT - Assembly - Operation - Adjustments - Parts - Warranty CAUTION: Read and understand this manual before operating unit Retain For Future Reference...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Product Registration ..................3 Important Safety Instructions ................5 Important Electrical Informations ..............6 Important Operation Instructions ..............7 Assembly Instructions ..................9 Operation of Your New Treadmill ..............16 Programmable Features ................25 Using a Heart Rate Transmitter ..............36 System Maintenance Suite ................

  • Page 3: Product Registration

    CONGRATULATIONS ON YOUR NEW TREADMILL AND WELCOME TO THE SPIRIT FAMILY! Thank you for your purchase of this quality treadmill from Dyaco Canada Inc. Your new treadmill was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available.
  • Page 4 BEFORE YOU BEGIN Thank you for choosing the SPIRIT CT900 ENT Treadmill. We take great pride in producing this quality product and hope it will provide many hours of quality exercise to make you feel better, look better, and enjoy life to its fullest. It's a proven fact that a regular exercise program can improve your physical and mental health.

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING - Read all instructions before using this equipment. DANGER - To reduce the risk of electric shock, always unplug this treadmill from the electrical outlet prior to cleaning and/or service work. WARNING - To reduce the risk of burns, fire, electric shock, or injury to persons, install the treadmill on a flat level surface with access to a 120-volt, 20-amp grounded outlet.

  • Page 6: Important Electrical Informations

    IMPORTANT ELECTRICAL INFORMATIONS WARNING! NEVER use a RCD - Residual Current Device (U.S. ver.= GFCI) - wall outlet with this treadmill. As with any equipment with a large motor, the RCD/GFCI will trip often. Route the power mains cord away from any moving part of the treadmill including the elevation mechanism and transport wheels.

  • Page 7: Important Operation Instructions

    IMPORTANT OPERATION INSTRUCTIONS NEVER operate this treadmill without reading and completely understanding the results of any ● operational change you request from the computer console. Understand that changes in speed and incline do not occur immediately. Set your desired ● speed on the computer console and release the adjustment key.
  • Page 8 WARNING DECAL REPLACEMENT The decal shown below has been placed on the treadmill. If the decal is missing or illegible, please call our Customer Service Department toll-free at 1-888-707-1880 to order a replacement decal. Dyaco Canada Inc. 2018                                                                                                                                    customerservice@dyaco.ca                            ...

  • Page 9: Assembly Instructions

    ASSEMBLY INSTRUCTIONS UNPACKING 1. Cut the straps and open box. 2. Locate the hardware package. The hardware is separated into four steps. Remove the tools first. Remove the hardware for each step as needed to avoid confusion. The numbers in the instructions that are in parenthesis (#) are the item number from the assembly drawing for reference.
  • Page 10 STEP1 #79 - Ø10 × 2T #65 - M10 × 60mm Spring Washer Socket Head Cap Bolt (10pcs) (10pcs) STEP2 #74 - Ø3/8" × 25 × 3T Flat #79 - Ø10 × 2T #63 - M10 × 35mm Socket Washer Spring Washer Head Cap Bolt (6pcs)
  • Page 11 STEP 1 1. Loosen the 8 screws holding the MOTOR COVER (37) in place and remove the cover. 2. Uncoil the wires and run the wires through the RIGHT UPRIGHT (7). 3. Use 5 BOLTS (65) and 5 LOCK WASHERS (79) to attach the RIGHT UPRIGHT (7) to the MAIN FRAME (1).
  • Page 12 STEP 2 1. Install CONSOLE MOUNTING BRACKET (3) onto the uprights using 6 BOLTS (63), 6 LOCK WASHERS (79) and 6 FLAT WASHERS (74). 2. Attach the wires to a wire puller. Run the wires through the CONSOLE MOUNTING BRACKET (3) as shown in the illustration in circle. 3.
  • Page 13 STEP 3 1. Wires should be away from the console mounting bracket. 2. Install the CONSOLE (54) using 4 SCREWS (134). 3. Connect wires to CONSOLE (54). Note: Ensure the green ground wires are attached. 4. Attach CONSOLE COVER (50) to MAIN PANEL using 4 SCREWS (68). Dyaco Canada Inc. 2018 ...
  • Page 14 STEP 4 1. Attach LEFT OUTER HANDRAIL COVER (48) to the CONSOLE MOUNTING BRACKET using 2 SCREWS (83) and 2 FLAT WASHERS (75). Dyaco Canada Inc. 2018                                                                                                                                    customerservice@dyaco.ca                            ...
  • Page 15 STEP 4 2. Attach LEFT INNER HANDRAIL COVER (47) to the CONSOLE MOUNTING BRACKET using 5 SCREWS (83). 3. Attach LEFT FRAME BASE COVER (40) to MAIN FRAME (1) using 2 SCREWS (83), 2 FLAT WASHERS (75), and 1 long SCREW (69). 4.

  • Page 16: Operation Of Your New Treadmill

    OPERATION OF YOUR TREADMILL Getting familiar with the control panel Console Starting the operation: • Plug in the power cord and switch on the main power switch located at the front, under the motor hood of the treadmill and make sure that the safety key is put on as the treadmill is unable to operate without the safety key.
  • Page 17 Main Home page: Begin operation by touching the icons. Quick operating buttons are convenient for basic treadmill functions. Quick start operation: • Press Start button and the belt runs with 0.8 km/h (0.5 MPH). • Press Speed Up/Down buttons further to adjust the speed. •...
  • Page 18 Pause/Stop: • Press Stop button once or first page button on the screen, the belt will slow down gradually till fully stopped and keep values of time, distance and calorie on the screen. The screen will reset after 5 minutes of counting down then return to the previous status. •...
  • Page 19 Below is the instruction for touch screen operation: First page HOME There are four items to be selected. Generally the Language would be the first item to select. Language When you press Language button on the first page HOME, it enters the menu with all language selections.
  • Page 20 When TV button on the first page HOME is pressed, it directly enters TV interface. Now you can enjoy TV programs. If you want to enjoy TV while exercising, press “START” button at front of the treadmill. You can change the TV channel by using Up/Down buttons on the TV channel or the channel control panel buttons at the right side of the screen for quick channel switching.
  • Page 21 Internet When the Internet button on the Home page is pressed, it directly enters Internet interface. There are 6 internet connections to choose for you to go on the internet while you are exercising (internet cable connection or WIFI connection is required). Press “START” button of the treadmill to start it.
  • Page 22 MANUAL Press Profile button to enter the Profile interface. If this program is unwanted, just press Home icon at left top to return to the first page, or return icon at right top to return to the previous page to continue the last operation. If other profile is wanted, touch left or right arrow button to choose the wanted program.
  • Page 23 This image is for setting program time, user’s age and weight. Press “ENTER” button after entering parameters to confirm. Then press “START” button to start the Manual Program. If not, just press HOME icon at left top to return to the first page, or return icon at right top to return to the previous page to continue the last operation.
  • Page 24 Track The operating is similar only with different interface. The image shows the track with number of laps and other values. Dashboard The operating is similar with a different interface only. You can choose one of three interfaces on the bottom with your own preference. Dyaco Canada Inc. 2018 ...

  • Page 25: Programmable Features

    STOP BUTTON When using the first page button or Stop button to end the program, it enters the summary image. On the summary image, all accumulating values concerning the workout are displayed. You can touch the Home button at left top or press Stop button to return to the first page image. PROGRAMMABLE FEATURES The console offers twelve preset programs, HILL, FAT BURN, CARDIO, STRENGTH, CALORIE, INTERVAL, 5K RUN, 10K RUN, HR , CUSTOM, a Gerkin protocol based Fitness Test and one...
  • Page 26 To choose and start preset program: 1. Select a program then press the Enter key to begin customizing the program with your personal data, or just press the Start key to begin the program with the default settings. 2. After selecting a program and pressing enter to set your personal data, the Time window will be darken with the default value of 20 minutes.
  • Page 27 Preset programs speed and incline settings The preset program speed and incline levels are shown in the chart below. The Speed numbers shown in the chart indicate a percentage of the top speed of the program. For instance, the first Speed setting for program HILL shows the number 20.
  • Page 28 5 Km and 10Km Run: This program automatically sets a 5K or 10K (5 or 10 kilometer) distance as your goal. The track display will show one lap that is the equivalent of 5 or 10 kilometers and the Distance window will also show 5K or 10K to start.
  • Page 29 Army Navy Air Force Dyaco Canada Inc. 2018                                                                                                                                    customerservice@dyaco.ca                            ...
  • Page 30 Marines Physical Efficiency Battery (PEB) For U.S. Federal Law Enforcement US Coast Guard Dyaco Canada Inc. 2018                                                                                                                                    customerservice@dyaco.ca                            ...
  • Page 31 Before the test:  Make sure you are in good health; check with your physician before performing any exercise if you are over the age of 35 or persons with pre-existing health conditions.  Make sure you have warmed up and stretched before taking the test. ...
  • Page 32 What your score means: VO2max for male and fitted female 18-25 26-35 36-45 46-55 56-65 years years years years years years excellent >60 >56 >51 >45 >41 >37 good 52-60 49-56 43-51 39-45 36-41 33-37 above average 47-51 43-48 39-42 35-38 32-35 29-32...
  • Page 33 HEART RATE CONTROL PROGRAM How the Heart Rate Control Programs Work： Heart Rate Control (HRC) uses your treadmill’s incline system to control your heart rate. Increases and decreases in elevation affect heart rate much more efficiently than changes in speed alone. The HRC program automatically changes elevation gradually to achieve the programmed target heart rate.
  • Page 34 TARGET HEART RATE The old motto, “no pain, no gain”, is a myth that has been overpowered by the benefits of exercising comfortably. A great deal of this success has been promoted by the use of heart rate monitors. With the proper use of a heart rate monitor, many people find that their choice of exercise intensity is either too high or too low and exercise is much more enjoyable by maintaining their heart rate in the desired benefit range.
  • Page 35 RATE OF PERCEIVED EXERTION Heart rate is important but listening to your body also has a lot of advantages. There are more variables involved in how hard you should workout than just heart rate. Your stress level, physical health, emotional health, temperature, humidity, the time of day, the last time you ate and what you ate, all contribute to the intensity at which you should workout.

  • Page 36: Using A Heart Rate Transmitter

    USING A HEART RATE TRANSMITTER (OPTIONAL) How to wear your wireless chest strap transmitter: Attach the transmitter to the elastic strap using the locking parts. Adjust the strap as tightly as possible as long as the strap is not too tight to remain comfortable.

  • Page 37: System Maintenance Suite

    The two most commonly used menus for setting up the exercise machine are described below: the TV Setup and Maintenance menus. For information on other sections of the Maintenance suite refer to the technical service manual or call Spirit service. TV Setup 1. Begin by selecting either TV or HDMI as the tuner source.
  • Page 38  Machine Setup allows you to select whether the Csafe port is used for Csafe or CAB TV Tuner. This menu also allows you to set the screen brightness.  FTP Settings is the Spirit FTP site address where Error logs and remote troubleshooting can be managed.
  • Page 39 Wifi /Ethernet Setup  Press the desired button for setting up Wifi or Ethernet. Wifi Setup  Turn Wifi on and press scan for available Wifi connections. Press desired connection and follow the on-screen directions. Ethernet Setup - Press Ethernet Configuration to set up - Select DHCP to search for connection or a new connection.

  • Page 40: Exploded View Diagram

    EXPLODED VIEW DIAGRAM Dyaco Canada Inc. 2018                                                                                                                                    customerservice@dyaco.ca                            ...

  • Page 41: Parts List

    PARTS LIST KEY NO. PART NO. DESCRIPTION Q'TY 7090001E Main Frame Incline Bracket 7090002E 7090003E Console Mounting Bracket 7090004E Hand pulse Assembly 7090005E Handrail (R) 7090006E Handrail (L) 7090007E Right Upright 7090008E Left Upright 7090009E Idler Wheel Assembly 7090010E AC Motor 7090011E Front Roller W/Pulley 7090012E...
  • Page 42 KEY NO. PART NO. DESCRIPTION Q'TY 7090046E Handrail Cover Outer (R) 7090047E Handrail Cover Inner (L) 7090048E Handrail Cover Outer (L) 7090049E TFT Console Cover (Front) 7090050E TFT Console Cover (Rear) 7090051E M3 × 5m/m_Phillips Head Screw 7090052E Safety Key 7090053E Step Rail Rear Support Plate 7090054E...
  • Page 43 KEY NO. PART NO. DESCRIPTION Q'TY 7090094E Ø10 × Ø25 × 2.5T_Nylon Washer 7090095E M8 × 7T_Nyloc Nut 7090096E Rod End Sleeve 7090097E 450m/m_Connecting Wire (White) 7090098E 300m/m_Ground Wire 7090099E 800m/m_Handpulse Wire(SMP3) 70900100E 800m/m_Handpulse Wire(SMR4) 70900101E 500m/m_Connecting Wire 70900102E 350m/m_Connecting Wire(XHP-7) 70900103E 350m/m_Connecting Wire(XHP-8) 70900104E...

  • Page 44: General Maintenance

    GENERAL MAINTENANCE Belt and Deck - Your treadmill uses a very high-efficient low-friction deck. Performance is maximized when the deck is kept as clean as possible. Use a soft, damp cloth or paper towel to wipe the edge of the belt and the area between the belt edge and frame. Also reach as far as practical directly under the belt edge.
  • Page 45 ATTENTION: DAMAGE TO THE RUNNING BELT RESULTING FROM IMPROPER TRACKING / TENSION ADJUSTMENTS IS NOT COVERED UNDER THE SPIRIT WARRANTY. Unplug treadmill before performing any maintenance. Dyaco Canada Inc. 2018                                                                                                                                    customerservice@dyaco.ca                            ...

  • Page 46: Service Checklist - Diagnosis Guide

    SERVICE CHECKLIST - DIAGNOSIS GUIDE Before contacting your dealer for aid, please review the following information. It may save you both time and expense. This list includes common problems that may not be covered under the treadmill’s warranty. PROBLEM SOLUTION/CAUSE 1) Tether cord not in position.
  • Page 47 TRAINING GUIDELINES EXERCISE Exercise is one of the most important factors in the overall health of an individual. Listed among its benefits are:  Increased capacity for physical work (strength endurance)  Increased cardiovascular (heart and arteries/veins) and respiratory efficiency ...
  • Page 48 Progression As your become fitter, a higher intensity of exercise is required to create an overload and therefore provide continued improvement Overload This is where you exercise at a level above that which can be carried out comfortably. The intensity, duration and frequency of exercise should be above the training threshold and should be gradually increased as the body adapts to the increasing demands.
  • Page 49 The following table is a guide to those who are “starting fitness”. Target heart Rate 10 Second Count Beats per Minute 132 126 120 Pulse Count The pulse count (on your wrist or carotid artery in the neck, taken with two index fingers) is done for ten seconds, taken a few seconds after you stop exercising.
  • Page 50 Patronization This is the term used to vary your exercise program for both physiological and psychological benefits. In your overall program, you should vary the workload, frequency and intensity. The body responds better to variety and so do you. In addition, when you feel yourself getting “stale’, bring in periods of lighter exercise to allow the body to recuperate and restore its reserves.
  • Page 51 STRETCHING Stretching should be included in both your warm up and cool down, and should be performed after 3-5 minutes of low intensity aerobic activity or callisthenic type exercise. Movements should be performed slowly and smoothly, with no bouncing or jerking. Move into the stretch until slight tension, not pain, is felt in the muscle and hold for 20-30 seconds.
  • Page 52 TOUCHES INNER THIGH STRETCH Slowly bend forward from your waist, Sit with the soles of your feet together letting your back and shoulders relax as with your knees pointing outward. Pull you stretch toward your toes. Reach your feet as close into your groin as down as far as you can and hold for 15 possible.

  • Page 53: Manufacturer's Limited Warranty

    MANUFACTURER’S LIMITED WARRANTY Dyaco Canada Inc. warrants all its Spirit treadmill for a period of time listed below, from the date of retail sale, as determined by a sales receipt. Dyaco Canada Inc.’s responsibilities include providing new or remanufactured parts, at Dyaco Canada Inc.’s option, and technical support to our independent dealers and servicing organizations.
  • Page 54 Please visit us online for information about our other brands and products manufactured and distributed by Dyaco Canada Inc. www.dyaco.ca www.dyaco.ca www.dyaco.ca www.dyaco.ca www.spiritfitnesscanada.ca www.spiritfitnesscanada.ca www.dyaco.ca www.dyaco.ca www.solefitness.ca www.trainorsports.ca www.dyaco.ca www.dyaco.ca www.xterrafitness.ca www.dyaco.ca Dyaco Canada Inc. 2018                                                                                                                                    customerservice@dyaco.ca                            ...
