Majestic ECHEL36IN Owner's Manual

Echelon ii series
Hide thumbs Also See for ECHEL36IN:

Advertisement

INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
Pour demander un exemplaire en français de ce Manuel
du propriétaire, visitez www.majesticproducts.com.
NOTICE: DO NOT discard this manual!
ECHELON II
SERIES
Models:
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner's Manual • 2406-971 Rev. D • 10/17
Owner's Manual
Care and Operation
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fitter.
See appliance installation manual for additional
Commonwealth of Massachusetts requirements.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1

Advertisement

Table of Contents
loading

Summary of Contents for Majestic ECHEL36IN

  • Page 1 See appliance installation manual for additional Commonwealth of Massachusetts requirements. gases, unless a certified kit is used. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 2: Welcome

    MIN. MIN. INPUT INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 Serial Serial XXXXXXXX XXXXXXXX ORIFICE ORIFICE SIZE: SIZE: #XXXXX #XXXXX #XXXXX #XXXXX (Serie): (Serie): Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 3: Table Of Contents

    C. Contact Information ......31  = Contains updated information. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 4: Limited Lifetime Warranty

    Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645H 10/15 Page 1 of 2 Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 5 SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645H 10/15 Page 2 of 2 Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 6: Product Specific Information

    This appliance is equipped with 5 mm ceramic glass. Re- place glass only with 5 mm ceramic glass. Please contact your dealer for replacement glass. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 7: Important Safety And Operating Information

    • Install a switch lock or a wall/remote control with child are contacting the top of the firebox. Call a qualified service protection lockout feature. technician to service the appliance. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 8: General Operating Parts

    WARNING! Risk of Fire! Comply with all minimum more depending on the thermometer settings and material clearances to combustibles as specified in the installation characteristics being measured. instructions. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 9 Increase “C” and “E” dimension, however, increasing “B” dimension beyond maximum recommended typically results in higher temperatures.  Figure 3.5. Good Faith TV Guidelines Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 10: Before Lighting Appliance

    WARNING! Risk of Fire or Asphyxiation! DO NOT op- erate fireplace with fixed glass assembly removed. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 11: Lighting Instructions (Ipi)

    Propane Installation code, CSA B149.1. tions accompanying appliance. For additional information on operating your 593-913i Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 12: Appliance Break-In

    NOTICE! Open windows for air circulation during fire- place break-in. • Some people may be sensitive to smoke and odors. • Smoke detectors may activate. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 13: Operation During A Power Outage

    110-120 VAC power. 3.6 Control Cavity Location BATTERY TRAY 3.7 Battery Tray Location - Top View Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 14: Detailed Component Operating Instructions - Intellifireā„¢ Plus

    IntelliFire™ Plus remote control. Follow in- structions included with the installed control. MODULE SELECTOR SWITCH FLAME HI/LOW STATUS NG/LP GAS-TYPE SWITCH INDICATOR LED SELECTOR SWITCH Figure 3.8 Control Module Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 15: Maintenance And Service

    CAUTION! Risk of Burns! The fireplace should be 4. Reinstall bottom glass shield. turned off and cooled before servicing. 5. Reinstall decorative front. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 16 • Inspect draft shield to verify it is not damaged or missing. • Check that louvers are not blocked. • Vacuum and dust surfaces. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 17: Maintenance Tasks: Qualified Service Technician

    • Remove all foreign objects. • Verify unobstructed air circulation. Figure 4.2 IPI Pilot Flame Patterns Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 18: Frequently Asked Questions And Troubleshooting

    Contact your dealer for additional information regarding operation and troubleshooting. Visit www.majesticproducts.com to locate a dealer. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 19: Troubleshooting

    Verify that 1.5 to 1.8 VDC is supplied to pilot solenoid from module. If below 1.5 volts, replace module. If 1.5 volts or greater, replace valve. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 20 Verify continuity with a multi-meter with ohms set at lowest range. Replace pilot if any damage is detected. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 21: Reference Materials

    After a qualified service technician has installed the Heat-Zone or Heat-Duct Kit, follow the instruction sup- ® plied with the kit for operation. See your dealer if you have questions. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 22: Service Parts

    LED Light Assembly ALK-36 13.1 LED 12V Power Supply 2273-308 13.2 Cord Assembly 2101-084 13.3 AUX RC300 2166-335 Additional service part numbers on following page. 9/17 Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 23 LED Light Assembly ALK-36 13.1 LED 12V Power Supply 2273-308 13.2 Cord Assembly 2101-084 13.3 AUX RC300 2166-335 Additional service part numbers on following page. 9/17 Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 24 LED Light Assembly ALK-48 13.1 LED 12V Power Supply 2273-308 13.2 Cord Assembly 2101-084 13.3 AUX RC300 2166-335 Additional service part numbers on following page. 9/17 Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 25 LED Light Assembly ALK-48 13.1 LED 12V Power Supply 2273-308 13.2 Cord Assembly 2101-084 13.3 AUX RC300 2166-335 Additional service part numbers on following page. 9/17 Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 26 LED Light Assembly ALK-60 13.1 LED 12V Power Supply 2273-308 13.2 Cord Assembly 2101-084 13.3 AUX RC300 2166-335 Additional service part numbers on following page. 9/17 Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 27 LED Light Assembly ALK-72 13.1 LED 12V Power Supply 2273-308 13.2 Cord Assembly 2101-084 13.3 AUX RC300 2166-335 Additional service part numbers on following page. 9/17 Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 28 **Fuse for battery pack can be sourced locally, not a warranty item. Specs are 250v, 1A fuse, 3/4” long Additional service part numbers on following page. Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 29 Black Glass Kit (Includes Manual Bag Assembly for kit BGK-60 ECHEL60IN and Refractory Assembly) BGK-72 ECHEL72IN See Throughs BGK-LINEARST Remote RC300-MAJF 2397-330 Touch Up Paint TUP-GBK-12 Vinyl Siding Shield TRAP-VSS Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 30 ECHEL48IN/ECHEL48STIN Conversion Kit LP LPK-ECHEL60 ECHEL60IN LPK-ECHEL72 ECHEL72IN Pilot Ori ce, NG 593-528 Pilot Ori ce, LP 593-527 Regulator, NG NGK-DXV-50 Regulator, LP LPK-DXV-50 Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
  • Page 31: Contact Information

    5941237, 6006743, 6019099, 6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7098269, 7258116, 7470729, 8147240 or other U.S. and foreign patents pending. 2000-945C Printed in U.S.A. - Copyright 2017 Majestic • ECHEL36IN, ECHEL36STIN, ECHEL48IN, ECHEL48STIN, ECHEL60IN, ECHEL72IN Owner’s Manual • 2406-971 Rev. D • 10/17...
