INSTALLER/CONSUMER
SAFETY INFORMATION
PLEASE READ THIS MANUAL
BEFORE INSTALLING AND
USING APPLIANCE
WARNING!
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING
PROPERTY DAMAGE, PER-
SONAL INJURY OR LOSS OF
LIFE.
FOR YOUR SAFETY
Installation and service must
be performed by a qualified
installer, service agency or
the gas supplier.
WHAT TO DO IF YOU SMELL
GAS:
Do not try to light any
appliance.
Do not touch any electric
switch; do not use any phone in
your building.
Immediately call your gas
supplier from your neighbor's
phone. Follow the gas suppliers
instructions.
If you cannot reach your gas
supplier call the fire
department.
DO NOT STORE OR USE
GASOLINE OR OTHER
FLAMMABLE VAPORS AND
LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER
APPLIANCE.
INSTALLER: DO NOT DISCARD THIS MANUAL - LEAVE FOR HOMEOWNER
Builder Rear Vent
Direct Vent
Models: 33BDVR, 36BDVR
39BDVR, 43BDVR
Installation Instructions and
Homeowner's Manual
CFM Specialty Home Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
www.majesticproducts.com • www.vermontcastings.com
C E RT I F I E D
10003357 12/04 Rev. 8

Advertisement

Table of Contents
loading

Summary of Contents for Majestic 33BDVR

  • Page 1 Builder Rear Vent SION MAY RESULT CAUSING PROPERTY DAMAGE, PER- Direct Vent SONAL INJURY OR LOSS OF LIFE. Models: 33BDVR, 36BDVR FOR YOUR SAFETY 39BDVR, 43BDVR Installation and service must be performed by a qualified installer, service agency or the gas supplier.
  • Page 2: Table Of Contents

    BDVR Series Direct Vent Gas Fireplace Table of Contents PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING APPLIANCE. Thank you and congratulations on your purchase of a CFM Specialty Home Products fireplace. IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions fully may result in a possible fire hazard and will void the warranty.
  • Page 3: Installation & Operating Instructions

    BDVR Series Direct Vent Gas Fireplace Installation & Operating Instructions This gas appliance should be installed by a qualified This appliance may be installed in an aftermarket installer in accordance with local building codes and with permanently located, manufactured home or mobile current CSA-B149.1 Installation codes for Gas Burning home, where not prohibited by local codes.
  • Page 4: Fireplace Dimensions

    Centerline of Opening 7" Collar Height Electrical Access Gas Line Voltage Access Electrical Access Gas Line Access Fig. 2 Fireplace specifications and framing dimensions. Ref. 33BDVR 36BDVR 39BDVR 43BDVR 33” (838mm) 36” (914mm) 39” (991mm) 43” (1092mm) 28⁷⁄₈” (733mm) 34¹⁄₄” (870mm) 34¹⁄₄”...
  • Page 5: Clearance To Combustibles

    Mantel Shelf Mantel from Top insulation codes. Ref. or Breast Plate Ref. of Combustion Chamber Depth 36/39/43 BDVR 33BDVR 10” (254mm) 19” (483mm) 17” (432mm) 8” (203mm) 17” (432mm) 15” (381mm) 6” (152mm) 15” (381mm) 13”...
  • Page 6: Framing And Finishing

    BDVR Series Direct Vent Gas Fireplace Framing and Finishing 33BDVR / 36BDVR / 39BDVR / 43BDVR Certified To 1. Choose the unit location. 2. Place the unit into position and secure it to the floor ANSI Z21.88-2002 / CSA 2.33-2002 with 1¹⁄₂”...
  • Page 7: Gas Line Installation

    BDVR Series Direct Vent Gas Fireplace Gas Line Installation Remote ON/OFF Switch Installation When purging the gas lines, the front window frame assembly must be re- 1. Thread the wiring through the holes on the end moved. panels of the fireplace. Take care not to cut the wire or insulation on metal edges.
  • Page 8: Eb-1 Electrical Box

    BDVR Series Direct Vent Gas Fireplace EB-1 Electrical Box Electronic Gas Control Valve The fireplace, when installed, must be This appliance may be fitted with a Honeywell electrically connected and grounded in ignition module. accordance with local codes or, in the Installation of the remote on/off starter switch on absence of local codes, with the current electronic ignition units.
  • Page 9: General Venting Information

    BDVR Series Direct Vent Gas Fireplace General Venting Your fireplace is approved to be vented either through Do not locate termination hood where excessive snow the side wall, or vertically through the roof. or ice build up may occur. Be sure to check vent termination area after snow falls, and clear to prevent •...
  • Page 10: General Venting Information-Termination Location

    BDVR Series Direct Vent Gas Fireplace General Venting Information - Termination Location INSIDE CORNER DETAIL Fixed Fixed Closed Closed Fixed Operable Closed AREA WHERE TERMINAL IS NOT PERMITTED VENT TERMINATION AIR SUPPLY INLET CFM145a Canadian Installations US Installations A = Clearance above grade, veranda, porch, 12”...
  • Page 11: General Information Assembling Vent Pipes

    BDVR Series Direct Vent Gas Fireplace Termination Clearances Termination clearances for buildings with combustible and noncombustible exteriors. Inside Corner Recessed Location Outside Corner Combustible 6"(152mm) Combustible 6"(152mm) Noncombustible 2"(50mm) Noncombustible 2"(50mm) Balcony - Balcony - with no side wall with perpendicular side wall C = Maximum depth of 48"...
  • Page 12: How To Use The Vent Graph

    BDVR Series Direct Vent Gas Fireplace How to Use the Vent Graph Rear Wall Venting Applications When installed as a rear vent unit this appliance may The vent chart should be read in conjunction with the be vented directly to a termination located on the rear following vent installation instructions to determine the wall behind the appliance.
  • Page 13 BDVR Series Direct Vent Gas Fireplace Rear Wall Installations Max. Length Adjustable Zero 12” (305mm) Clearance STEP 1 Sleeve Locate vent opening on the wall. To locate hole center #8 Screws (2) consult with appropriate fireplace dimensions, Page 4. Frame as shown below. #8 Screws Combustible Walls (Fig.
  • Page 14: Vertical Sidewall Applications & Installation

    BDVR Series Direct Vent Gas Fireplace Maximum Vertical Dimension 20 ft. (6.1m) 7¹⁄₂ft. Minimum 48" When Horizontal 12" (1.2m) Finished Wall Run is 20ft. (305mm) 15 ft. Vent (4572mm) Termination 7.5’ (2.3m) 7TDVRT90 Elbow CFM141 Fig. 18 Maximum number of 90° elbows is three (3). •...
  • Page 15 BDVR Series Direct Vent Gas Fireplace •IMPORTANT• Minimum clearance between vent pipes 7 ft. (2134 mm) and combustible materials is one (1”) inch (25 mm) on bottom, sides and top. 10 ft. (3048 mm) Twist Lock Vent Starter Kit 7TDVSK, plus 90°...
  • Page 16 BDVR Series Direct Vent Gas Fireplace STEP 2 STEP 4 Measure wall thickness and cut adjustable zero clear- Measure the horizontal length requirement including a ance sleeve parts to proper length (MAXIMUM 12”/ 2” (50mm) overlap, i.e. from the elbow to the outside 305mm).
  • Page 17: Below Grade Installation

    BDVR Series Direct Vent Gas Fireplace STEP 6 1. Establish vent hole through the wall. (Fig. 23) Apply high temperature sealant to 4” (102mm) and 7” 2. Remove soil to a depth of approximately 16" (178mm) collars or the termination one inch away from (406mm) below base of snorkel.
  • Page 18: Vertical Through-The-Roof Applications & Installation

    BDVR Series Direct Vent Gas Fireplace If the foundation is recessed, use recess brackets (not supplied) for securing lower portion of the snorkel. Fasten brackets to wall first, then secure to snorkel with self drilling #8 x 1/2 sheet metal screws. It will be Max.
  • Page 19 BDVR Series Direct Vent Gas Fireplace Attic Insulation Vent Shield Termination Roof Storm Collar 2’ Min. Roof Flashing Roof Support Joist Attic Insulation 40’ Shield (12m) Attic Insulation Joists Joists Ceiling 11" Installation Upper Floor 11" Joist Firestop Spacer FP1022 Nails (4) Fig.
  • Page 20: Twist Lock Venting Components

    BDVR Series Direct Vent Gas Fireplace Twist Lock Venting Components 7TDVRVT - Through the wall Rear Vent Termination Starter Kit-Model 7TDVSK-Sidewall Venting Starter Kit-Model 7TDVSKV-Vertical Venting for 7TDVSKV-A order 1/12 to 6/12 roof pitch for 7TDVSKV-B order 7/12 to 12/12 roof pitch for 7TDVSKV-F order flat roof Starter Kit - Model 7TDVSKS - Snorkel Kit Snorkel Termination - 7TDVSNORK...
  • Page 21: Operating Instructions

    BDVR Series Direct Vent Gas Fireplace Operating Instructions Glass Information Only glass approved by CFM Specialty Home Products should be used on this fireplace. • The use of any non-approved replacement glass will void all product warranties. • Care must be taken to avoid breakage of the glass. •...
  • Page 22: Installation Of Logs, Lava Rock & Ember Material

    Log Identification Chart 33BDVR Embers LG268 Location 33BDVR 36BDVR 39BDVR 43BDVR Front Left BB11 BC11 BD12 Fig. 38 33BDVR log placement. Front Right BB12 BD14 36BDVR Rear BB13 BD11 Refer to Figure 39 Top Right BC12 1. Remove the top louvre assembly.
  • Page 23 BDVR Series Direct Vent Gas Fireplace 39BDVR 43BDVR Refer to Figure 40 Refer to Figure 41 1. Remove the top louvre assembly. 1. Remove the top louvre assembly. 2. Remove the window frame assembly. 2. Remove the window frame assembly. 3.
  • Page 24: Flame & Temperature Adjustment

    (Figs. 42 & 43) Honeywell Valve Turn LG271 counterclockwise Turn clockwise Fig. 45 Correct burner flame appearance for 33BDVR. to decrease to increase flame height flame height Fig. 42 Flame adjustment knob for Honeywell valve. SIT 820 Valve...
  • Page 25: Lighting And Operating Instructions

    BDVR Series Direct Vent Gas Fireplace Lighting and Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit Follow the gas supplier's instructions.
  • Page 26 BDVR Series Direct Vent Gas Fireplace Lighting and Operating Instructions For Fireplaces equipped with SIT822 Gas Valve (EN or EP) Warning: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury and loss of life. FOR YOUR SAFETY READ THE FOLLOWING WARNINGS BEFORE LIGHTING THE APPLIANCE Follow the gas suppliers instructions.
  • Page 27: Troubleshooting

    BDVR Series Direct Vent Gas Fireplace Troubleshooting - Honeywell Millivolt Valve Remove Window Frame Assembly Before Service Work START CHECK • Supply Line Hooked Up Gas Supply On • Shutoff Valve Open • Lockout Has Engaged. Wait 60 Seconds And Try Again. •...
  • Page 28 BDVR Series Direct Vent Gas Fireplace Troubleshooting the Gas Control System SIT NOVA 820 MILLIVOLT VALVE NOTE: Before trouble shooting the gas control system, be sure external gas shut off is in the “On” position. WARNING: BEFORE DOING ANY GAS CONTROL SERVICE WORK, REMOVE GLASS FRONT. SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION...
  • Page 29 BDVR Series Direct Vent Gas Fireplace Troubleshooting the Gas Control System SIT 822 Valve with a Honeywell Electronic Ignitor Remove Window Frame Assembly Before Service Work START •TURN GAS SUPPLY OFF CHECK: • LINE VOLTAGE (120VAC) • LOW VOLTAGE TRANSFORMER •...
  • Page 30: Fuel Conversion Instructions

    BDVR Series Direct Vent Gas Fireplace not over-tighten the screw, it must be finger tight. Fuel Conversion Instructions d. Refit the regulator cap. The conversion of this appliance from one e. Mount conversion label supplied with conver- gas to another must be carried out by an sion screw to valve in a visible position.
  • Page 31: Maintenance

    BDVR Series Direct Vent Gas Fireplace Maintenance Burner and Burner Compartment To obtain proper operation, it is imperative that the pilot and burner’s flame characteristics are steady, not It is important to keep the burner and the burner lifting or floating. compartment clean.
  • Page 32: Replacement Parts

    BDVR Series Direct Vent Gas Fireplace 4a/b 3a/b 33BDVR 12a/b 14a/b 36BDVR 13a/b 39BDVR 2a/b 3357 43BDVR CFM Specialty Home Products reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice.
  • Page 33 BDVR Series Direct Vent Gas Fireplace BDVR (continued) (Items marked “*” are not shown) Ref. Description 33BDVR 36BDVR 39BDVR 43BDVR Log Set (complete) 10003685 10003353 100003354 10003696 Log - Front left BB11 BC11 BD12 Log - Front right BB12 BD14...
  • Page 34 BDVR Series Direct Vent Gas Fireplace BDVR (continued) (Items marked “*” are not shown) Ref.Description 33BDVR 36BDVR 39BDVR 43BDVR Fan speed control, (FK24 option) 51738 51738 51738 51738 Knob, fan speed control, (FK24 option) 51882 51882 51882 51882 Fan assembly, with bracket (FK12 option)
  • Page 35: Optional Accessories

    BDVR Series Direct Vent Gas Fireplace Optional Accessories Available Fan Kits Thermal Sensor FK24 Fan Assembly This auxiliary fan system increases the efficiency of the circulation of the heated air. The FK24 fan kit allows variable speed control of the circulation fan and also incorporates a heat sensor in Valve the circuit.
  • Page 36: Ceramic Refractory Lining

    Firebox Back Panel Rear Panel Ceramic refractory panels are available in kit form for Support the BDV series appliances Brackets Appliance Model Kit Name 33BDVT AT1TBT 33BDVR AT1CBB Rear Log Support 36BDVT BT2CBB 39BDVT CT2CBB FP1233 43BDVT DT2CBB Take care when handling the refractory Fig.
  • Page 37: Decorative Bay Window & Screen

    Fig. 56 Bay window isntallation. Assembly Bay Window Screen Bay window Screen kits are available for the 33BDVT/ 33BDVR & 36BDVT/36BDVR model appliances. Do not remove existing window frame assembly! Remove all plastic from brass trims. 1. Let the fireplace cool down if it has been operating.
  • Page 38: Warranty

    LIMITED LIFETIME WARRANTY PRODUCT COVERED BY THIS WARRANTY All Vermont Castings gas stoves, gas inserts, and gas fireplaces, and all Majestic or Northern Flame brand gas fireplaces equipped with an Insta-Flame Ceramic Burner, or standard steel tube burner. BASIC WARRANTY •...
  • Page 39 BDVR Series Direct Vent Gas Fireplace 10003357...
  • Page 40: Energuide

    Efficiency Ratings Model EnerGuide Ratings Steady State (%) D.O.E. Fireplace Efficiency (%) Fan-OFF Fan-ON (AFUE%) 33BDVRRN 48.4 33BDVRRP 48.4 33BDVREN 48.4 33BDVREP 48.4 36BDVRRN 48.9 36BDVRRP 48.9 36BDVREN 48.9 36BDVREP 48.9 39BDVRRN 56.5 39BDVRRP 56.5 39BDVREN 56.5 39BDVREP 56.5 43BDVRRN 52.9 43BDVRRP 52.9...
