INSTALLATION AND OPERATION
INSTRUCTIONS
MODEL: ATS-AU-D
AUSTRALIAN GAS ASSOCIATION APPROVED
AGA Approval Number 5543
THIS MANUAL MUST BE USED FOR INSTALLATION AND RETAINED
BY HOMEOWNER FOR OPERATION AND MAINTENANCE.
HEAT & GLO, a brand of Hearth Technologies Inc.
20802 Kensington Boulevard, Lakeville, MN 55044, USA (952) 985-6000
This product may be covered by one or more of the following patents: (United States) 4593510, 4686807, 4766876, 4793322, 4811534, 5000162, 5016609, 5076254, 5113843, 5191877, 5218953,
5263471, 5328356, 5341794, 5347983, 5429495, 5452708, 5542407, 5601073, 5613487, 5647340, 5688568, 5762062, 5775408, 5890485, 5931661, 5941237, 5947112, 5996575, 6006743,
6019099, 6048195, 6053165, 6145502, 6170481, 6237588, 6296474, 6374822, 6413079, 6439226, 6484712, 6543698, 6550687, 6601579, 6672860, 6688302B2, 6715724B2, 6729551, 6736133,
6748940, 6748942, 6769426, 6774802, 6796302, 6840261, 6848441, 6863064, 6866205, 6869278, 6875012, 6880275, 6908039, 6919884, D320652, D445174, D462436; (Canada) 1297749,
2195264, 2225408, 2313972; (Australia) 780250, 780403, 1418504 or other U.S. and foreign patents pending.
Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06
1
Advertisement
Table of Contents
Related Manuals for Heat & Glo ATS-AU-D
Summary of Contents for Heat & Glo ATS-AU-D
-
Page 1: Installation And Operation
6748940, 6748942, 6769426, 6774802, 6796302, 6840261, 6848441, 6863064, 6866205, 6869278, 6875012, 6880275, 6908039, 6919884, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408, 2313972; (Australia) 780250, 780403, 1418504 or other U.S. and foreign patents pending. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... - Page 2 Save this Manual for future reference. Copyright 2006 Heat & Glo, a brand of Hearth Technologies, 20802 Kensington Blvd., Lakeville, MN 55044 Printed in U.S.A. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06...
-
Page 3: Table Of Contents
3.3 Parts Replacement .................. 19 3.4 Adjustments and Replacement Parts ............19 3.5 Troubleshooting ..................20 4.0 Replacement Parts ..................24 Limited Warranty .................... 27 = Contains updated information. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... - Page 4 ASSEMBLY LOWER GRILLE GAS LINE ACCESS CONTROL EXHAUST FLUE VALVE COLLAR DATA BADGE & LABELS INLET FLUE COLLAR ON/OFF SWITCH ELECTRICAL LOW VOLTAGE JUNCTION BOX WIRES ACCESS FIGURE 1 Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06...
-
Page 5: Minimum Fireplace Opening
NOTE: If exhaust collar on insert and fireplace damper do not line up, add 4 inches (102mm) to minimum fireplace opening height to accommodate 32 1/8 [816MM] bends in vent pipe. FIGURE 2 Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... - Page 6 THE INLET AIR PIPE MUST ONLY BE CONNECTED TO THE INLET AIR COLLAR OF THE UNIT AND ATTACHED TO THE INLET AIR COLLAR OF THE TERMINATION CAP. INLET AIR FLUE PIPE FIGURE 3 Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06...
- Page 7 TERMINATION INLET AIR EXHAUST COLLAR COLLAR INLET AIR STARTING COLLAR EXHAUST STARTING COLLAR FIGURE 4 Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06...
-
Page 8: Installation Instructions
Kit Instructions to ensure that a proper flue installation of 3.3 inch (84mm) flexible flue pipe for the exhaust, is completed. one (1) LINK-DV30B Vertical Termination Kit. Consult your local Building Codes before beginning the installation. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... -
Page 9: Connecting The Flue Pipe
DO NOT USE AN OPEN FLAME. NOTE: THE GAS SUPPLY LINE SHOULD BE PURGED OF ANY TRAPPED AIR PRIOR TO THE FIGURE 6 FIRST FIRING OF THE UNIT. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... -
Page 10: Fan
- it will be retained in the hole. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... - Page 11 Place log #1 in the back of the heater, locating it's slot on the right over the protruding tab. The left end of the log is positioned by the two bend up tabs shown in Photo A. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06...
- Page 12 The slot on the right side of log #3 fits over the bar grate. LOG #4 (SRV327-704): Place the bottom left corner of log #4 behind log #2 and rest its top right corner on log #1. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06...
- Page 13 Rest log #5 in the cutouts on both log #1 and log #2 as shown. LOG #6 (SRV438-724): Position the "Y" end of log #6 into the cutout on log #4 and its opposite end into the groove on log #2. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06...
-
Page 14: Finishing
(Figure 9). TOP OF UNIT FIGURE 9 FIGURE 8 Proper gas log positioning is shown on pages 11-13. Follow Section 3.5 TROUBLESHOOTING for adjust- ing the appliance to operate properly. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... -
Page 15: Operating Instructions
THE UNIT AND TO REPLACE ANY PART OF THE glass occasionally as required. Never scrape or rub CONTROL SYSTEM AND ANY GAS CONTROL glass with any abrasive materials or cleaners. WHICH HAS BEEN UNDERWATER. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... -
Page 16: Safety And Lighting Information
• Do not touch any electric switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... -
Page 17: Lighting Instructions
3. Turn the valve control knob clockwise to the "Pilot" position, then depress knob and 2. Open the bottom grille. continue turning to "OFF" position. 4. Close the bottom grille. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... -
Page 18: Fan Operation
ONLY WHEN COOL. B. IMPORTANT: TURN OFF GAS BEFORE SERVIC- ING APPLIANCE. IT IS RECOMMENDED THAT A COMPETENT SERVICE TECHNICIAN PERFORM SERVICE CHECK-UPS AT THE BEGINNING OF EACH HEATING SEASON. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... -
Page 19: Removal Of Covers For Servicing
A can now removed. wiring diagram for the appliance is shown in SECTION 2.0 OPERATING INSTRUCTIONS. A replacement part table is shown in SECTION 4.0 of this manual. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... -
Page 20: Troubleshooting
Clean and/ or instructions. adjust pilot for maximum flame impingement. 2. Ensure that the thermocouple connection at the gas valve is fully inserted and tight (hand tight plus 1/4 turn). Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... - Page 21 ON/OFF switch in the OFF position. Re- place the faulty thermopile if the reading is below the specified minimum. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06...
- Page 22 1. Clean and adjust pilot flame for low, or blowing (high), causing pilot problem. maximum flame impingement on safety to drop out. the thermocouple. Follow lighting instruction carefully. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06...
- Page 23 2. Check to make sure that no material has been placed at the burner base. 3. Be sure glass is tightened properly on unit, particularly on top corners. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06...
-
Page 24: Replacement Parts
ATS-AU-D Service Parts Beginning Manufacturing Date: 3/05 (NG, LP) Exploded Parts Diagram Ending Manufacturing Date: ______ Log set assembly Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06... - Page 25 Log #5 SRV327-705 Log #6 SRV438-724 Pilot Orifice NG 060-517 Pilot Orifice LP 060-505 Temp Sensor 046-530 Mineral Wool 050-721 Dress Guard DF-ATS-D Glass Latch Assembly 386-122A Touch-Up Paint TUP-GBK-12 Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06...
- Page 26 Flexible Gas Connector 477-301A Orifice Bracke 438-223 Flex Ball Valve Assembly 302-320A Valve Bracket 571-152 Pilot Assembly NG 485-510A Pilot Assembly LP 485-511A Pilot Bracket 571-164 Wire Assembly 2020-059 Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06...
-
Page 27: Limited Warranty
HEAT & GLO reserves the right to make changes at any time, without notice, in design, material, specifications and prices. It also reserves the right to discontinue styles and products. Heat & Glo • ATS-AU-D • 327-900 Rev. D • 2/06...
