• Never place any portion of the model in your mouth as it could cause serious injury or even death. • Never operate your model with low transmitter batteries. • Always keep aircraft in sight and under control. Maule M7...
Box Contents Quick Start Information Transmitter Set up your transmitter using the Setup transmitter setup chart Hi Rate Low Rate 30mm 22mm 25mm 18mm Dual Rates 30mm 20mm 18mm 13mm Landing Takeoff Flaps =40mm =30mm Center of 55 – 70mm back from leading edge of Gravity (CG) wing at the fuselage.
Model Assembly Landing Gear Installation 1. Insert the landing gear assembly into the front mounting location on the bottom of the fuselage as shown. 3 x 16mm 2. Secure the landing gear into place with the four included 3 x 16mm (A) Tapered hex head machine screws and mounting straps.
After binding a transmitter to the aircraft receiver, set the trims and sub-trims to 0, then adjust the clevis to center the control surfaces. • Turn the linkage clockwise or counterclockwise until the control surface is centered. • Attach the linkage to the servo arm or control horn after adjustment. Maule M7...
Scale Accessories Optional Install the non-functional scale antennas on the top of the wing. Insert the tab into the slot in the plastic fi tting and slide it toward the tail to lock the antenna in place. Float Installation Optional Float Assembly The water rudder is mounted on the left fl...
Receiver Access The receiver for the Maule M7 is located inside the fuselage below the cockpit. Slide the hatch latch toward the tail and remove the bottom hatch to gain access to the receiver. Battery Installation and ESC Arming Battery Selection ®...
Transmitter and Receiver Binding / Switching ON and OFF SAFE Select ™ ® ® This product requires an approved Spektrum DSM2 /DSMX compatible Switching ON SAFE Select Binding Sequence transmitter. Visit www.bindnfl y.com for a complete list of approved transmitters. The aircraft has an optional SAFE Select feature, which can be switched ON or OFF easily by binding in a specifi...
3S 2200mAh. Always confi rm the CG is located correctly when changing the battery confi guration. 55 – 70mm +/- 3mm Back from the leading edge of the wing at the fuselage. Maule M7...
AS3X Control Direction Test ® This test ensures that the AS3X control system is functioning properly. Aircraft movement AS3X Reaction Assemble the aircraft and bind your transmitter to the receiver before performing this test. 1. Raise the throttle just above 25%, then lower the throttle to activate AS3X technology.
PNP Receiver Selection and Installation The Spektrum AR636 receiver is recommended for this airplane. Other receiver selections should be at least 6-channels and offer full range. Refer to the receiver AR636 Port manual for correct installation and operation instructions. Assignments CAUTION: When using a Futaba ®...
Aircraft bound to different model memory Select correct model memory on transmitter transmitter (ModelMatch radios only) Flight battery/Transmitter battery charge is too low Replace/recharge batteries Transmitter may have been bound to a different air- Bind aircraft to transmitter craft using different DSM protocol Maule M7...
Troubleshooting Guide (Continued) Problem Possible Cause Solution Control surface, control horn, linkage or servo damage Replace or repair damaged parts and adjust controls Wire damaged or connections loose Do a check of wires and connections, connect or replace as needed Control surface does Transmitter is not bound correctly or the incorrect Re-bind or select correct airplanes in transmitter...
United States 4105 Fieldstone Rd (Product Technical Assistance) of America 877-504-0233 Champaign, Illinois, 61822 USA websales@horizonhobby.com Sales 800-338-4639 Horizon Technischer Service service@horizonhobby.eu Hanskampring 9 European Union D 22885 Barsbüttel, Germany Sales: Horizon Hobby GmbH +49 (0) 4121 2655 100 Maule M7...
FCC Information FCC ID: BRWDASRX15 This equipment has been tested and found to comply with the limits for Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
