FrameSaver DSL 9783
Installation Instructions
Document Number 9783-A2-GN10-10
September 2000
Product Documentation on the World Wide Web
We provide complete product documentation online. This lets you search the
documentation for specific topics and print only what you need, reducing the waste
of surplus printing. It also helps us maintain competitive prices for our products.
Complete documentation for this product is available at www.paradyne.com.
Select Library
Select the following documents:
Document Number
9000-A2-GB20
9783-A2-GB20
9783-A2-GL10
To order a paper copy of a Paradyne document:
Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396)
Outside the U.S.A., call 1-727-530-8623

Upgrading a Basic Unit to SLV

Full SLV capability can be activated in basic FrameSaver DSL models at any time.
This is an optional feature that adds real-time and historical network performance
monitoring and SLA (Service Level Agreement) reporting capabilities to your
FrameSaver unit(s) and network. Simply order an Activation Certificate, providing the
model to be activated (9783), your OpenLane
the number of FrameSaver units whose SLV capability is to be activated.
The OpenLane SLM system, Release 5.3 or later, is required to schedule the activation
of the SLV feature and to manage the number of activations remaining on the
certificate. OpenLane also provides a Certificate Summary Report to assist you in the
management of the certificate.
Technical Manuals
Document Title
Configuring Frame Relay Service Over DSL
FrameSaver DSL 9783 User's Guide
FrameSaver DSL 9783 Quick Reference
FrameSaver Frame Relay Devices.
SLM system license key number, and
1

Advertisement

Table of Contents
loading

Summary of Contents for Paradyne FrameSaver DSL 9783

  • Page 1: Upgrading A Basic Unit To Slv

    We provide complete product documentation online. This lets you search the documentation for specific topics and print only what you need, reducing the waste of surplus printing. It also helps us maintain competitive prices for our products. Complete documentation for this product is available at www.paradyne.com. Select Library Technical Manuals FrameSaver Frame Relay Devices.
  • Page 2: Package Checklist

    Power cord with a wall-mount 120 VAC power transformer Tie wrap for power cord strain relief DSL network access cable with 6-pin connector FrameSaver DSL 9783 Quick Reference (Document No. 9783-A2-GL10) Be sure to register your warranty at www.paradyne.com/warranty. Before You Install the FrameSaver DSL Unit...
  • Page 3: Cables You May Need To Order

    See the User’s Guide for additional information on: Configuration Options Troubleshooting Technical Specifications Connectors, Cables, and Pin Assignments Cables You May Need to Order Feature Part If connecting to . . . Order a . . . Number Number Asynchronous Standard EIA-232 3100-F2-540 035-0314-1431 terminal or PC with...
  • Page 4: Installing The Power Supply

    Installing the Power Supply Procedure 1. Insert the supplied power cord’s plug into the POWER jack. Grounded Power Outlet Tie Wrap P O W C O M E T H E R N E T N E T 9783-C FrameSaver ®...
  • Page 5: Connecting To An Asynchronous Terminal Or Pc

    Connecting to an Asynchronous Terminal or PC A VT100-compatible asynchronous terminal or a PC providing VT100 terminal emulation must be used to set up access to and management of the unit. Procedure 1. Configure the terminal or PC so it is compatible with the FrameSaver unit: –...
  • Page 6: Verifying That Self-Test Passed

    Verifying that Self-Test Passed To verify that the unit passed its self-test, go to the System and Test Status screen. Main Menu Status System and Test Status The results of the self-test appear directly under the screen title. If any failure messages appear, reset the unit by disconnecting, then reconnecting the power cord.
  • Page 7: Framesaver Dsl Installation

    Procedure To save a configuration option change: 1. Press Ctrl-a to switch to the function keys area at the bottom of the screen. 2. Type s or S (Save) and press Enter. The Save Configuration To menu appears. 3. Press Enter again to save your changes to the Current Configuration. 4.
  • Page 8 2. Enter the Node IP Address and Node Subnet Mask. 3. Select Create a Dedicated Network Management Link, and enter a DLCI, VPI, and VCI at the ensuing prompts. The Management Link that is created will be used by the NOC to access the unit. 4.
  • Page 9 Completing Setup of the Unit From the NOC Procedure 1. Access the remote FrameSaver unit on the TS Management Link that was set up at the remote site. 2. Ping the FrameSaver unit five times within five seconds. The unit automatically provisions the TS Access VC.
  • Page 10: Connecting To The Network

    Connecting to the Network Now that the FrameSaver unit is set up, the unit can be connected to the network. Procedure 1. Use the supplied 6-pin cable for the DSL connection. Insert one end of the cable into the DSL network interface. 2.
  • Page 11: Connecting To The Ethernet

    Connecting to the Ethernet Procedure 1. Insert one 8-pin connector of the Ethernet cable into the Ethernet port. 2. Insert the other end of the cable into the Ethernet interface of the LAN where the NMS resides. P O W C O M E T H E R N E T...
  • Page 12: Connecting To The Dte (Router Or Frad)

    Connecting to the DTE (Router or FRAD) Procedure 1. Connect one end of the DTE’s cable to the user data port. 2. Plug the other end of the cable into the DTE. 3. Tighten the screws on each side of the connector to secure the cable. P O W C O M E T H E...
  • Page 13: Configuring Snmp Trap Managers And Traps

    Configuring SNMP Trap Managers and Traps Once the FrameSaver unit is connected to the network, SNMP trap managers and SNMP traps can be configured. Procedure To enter SNMP managers and configure traps: 1. Select SNMP Traps. Main Menu Configuration Management and Communication SNMP Traps 2.
  • Page 14: Provisioning The Customer Data Circuits

    Provisioning the Customer Data Circuits Use the OpenLane Provision Circuit screen to add new circuits that start at the FrameSaver DSL endpoint and traverse the SCM and ATM line card in the Hotwire GranDSLAM. In addition the default VC sets (from 1 to 4), there is a group of 250 VCs allocated to each line card that can be assigned to any port on the card.
  • Page 15: Checking That Data Is Being Received

    Checking That Data is Being Received Procedure 1. From the FrameSaver DSL 9783 Main Menu, select Performance Statistics, and select either interface’s frame relay statistics. Main Menu Status Performance Statistics Frame Relay Net1-FR1 2. Repeatedly Refresh the screen to verify that the Frames Received and Characters Received counts under the Frame Relay Link statistics are increasing.
  • Page 16: Important Safety Instructions

    Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered.
  • Page 17 Canada Notice to Users of the Canadian Telephone Network The following notice applies to units that have been CS-03 certified and bear the Industry Canada certification label. The Industry Canada label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s).
  • Page 18 The authority to operate this equipment is conditioned by the requirements that no modifications will be made to the equipment unless the changes or modifications are expressly approved by Paradyne Corporation. CANADA – EMI NOTICE To Users of Digital Apparatus in Canada: This Class A digital apparatus meets all requirements of the Canadian interference-causing equipment regulations.
  • Page 19: Warranty, Sales, Service, And Training Information

    Document Feedback We welcome your comments and suggestions about this document. Please mail them to Technical Publications, Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to userdoc@paradyne.com. Include the number and title of this document in your correspondence. Please include your name and phone number if you are willing to provide additional clarification.
