Page 1: Table Of Contents
FrameSaver DSL 9783 Router Overview ® The FrameSaver DSL (Digital Subscriber Line) 9783 Router is a component in the FrameSaver system. This system allows you to perform end-to-end service level management (SLM) across a hybrid FrameSaver DSL/ATM/Frame Relay network. Service providers can isolate and correct problems remotely from their NOC (Network Operations Center).
Page 2 IP router that connects a DSL link to an Ethernet network. The FrameSaver DSL 9783 Router is used for data only and provides corporate LAN access over traditional twisted-pair copper telephone wiring. Copper pairs run from the central office (CO) to the customer premises (CP) to create the local loop.
Page 3: Upgrading A Basic Unit To Slv
DSL 9783 features, and the capabilities provided by each feature set. Upgrading a Basic Unit to SLV A basic FrameSaver DSL 9783 Router can be upgraded to full SLV capability at any time by ordering a FrameSaver SLV Activation Certificate. A certificate can be ordered for a single 9783 router, or for many 9783 routers.
Page 4: Wiring And Cables You May Need
Ethernet wiring: Shielded twisted-pair wiring (CAT5, or better). The CAT5 wiring must meet EIA/TIA-568 specifications with 24 AWG (.5 mm) or 26 AWG (.4 mm). For standard cables, refer to For Paradyne cables, contact your sales representative to order them. Interface Connection Cables...
Page 5: Prior To Installing The Router
Prior to Installing the Router These Installation Instructions assume that the virtual circuits at the DSLAM have already been configured. Provisioning of these circuits can be simplified by using the OpenLane SLM (Service Level Management) system, as indicated in Circuits in OpenLane Provisioning Data Circuits in OpenLane Use the OpenLane SLM system’s Provision Circuit screen to add new circuits that start at the FrameSaver DSL endpoint and traverse the SCM and ATM line card in the Hotwire...
Page 6: Installing The Router
Installing the Router Place the FrameSaver DSL 9783 Router on a flat surface, with clearance for the rear connectors. Procedure 1. Use the supplied 8-pin DSL network cable (for use in the U.S.), or a 6-pin DSL network cable (using connectors similar to RJ11), as applicable, for the DSL connection.
Page 7 — Use a straight-through cable to connect the other end of the cable to an Ethernet hub. Do not connect to the hub’s optional Uplink connection with a straight-through cable; the Uplink connection requires an Ethernet crossover cable. DSL 9783 Router P O W C O M Ethernet...
Page 8 13 Configuration Setup . If connecting an external modem to Connecting an External Modem the COM port, refer to on page 23. DSL 9783 Router Port P O W C O M E T H E R N E T...
Page 9 11 for LED indications requiring action. Wrap Power Jack C O M E T H E R N E T 9783-C 9783 ROUTER System Network System Network System OK – green Alarm – red Test – yellow ATM – green/yellow DSL –...
Page 10: Status Leds
Status LEDs After a successful self-test, the LEDs should appear as indicated in BOLD in the Condition column below. Condition System LEDs TEST Network LEDs ON – Green ON – Yellow Blinking Port LED Status The router has power. An alarm condition exists. No alarms have been detected by the router.
Page 11: Troubleshooting
Troubleshooting LED Symptom All LEDs are on. ALM LED only remains on. ALM and TEST LEDs are blinking. ATM Yellow LED remains on. DSL LED is off. DSL LED continues blinking after the power-on self-test has completed. DSL LED is on, but no data is being transmitted.
Page 12: Configuration Setup
Configuration Setup Once the router is installed, it can be accessed locally through the menu-driven user interface via an asynchronous terminal or PC connection, or remotely via a Telnet session, and the router’s interfaces can be provisioned. The following provisioning can be set up: Frame relay, ATM, and physical layer provisioning –...
Page 13 Ctrl-a to access these functions, Shift-r to access the Router's CLI. If the Main Menu does not appear, recheck the terminal or PC’s settings, or press Enter again. Refer to Troubleshooting in the User’s Guide for other explanations. MAIN MENU Status Test Configuration Control Easy Install 9783-RtrSLV 2/26/2001 00:02 Exit...
Page 14: Menu Navigation
Menu Navigation The router should operate using the default (factory-set) configuration options. Refer to the following table for help in navigating the menus. Press the . . . Esc key Tab key, and Up ( ), Down ( ), Left ( ), Right ( ) Arrow keys Enter or Return key...
Page 15: Verifying That Self-Test Passed
Ethernet Management Options Screen Network 1 DSL Line Rate (Kbps) Network 1 FRF.8 Encapsulation Mod ----------------------------------------------------------------------------- Ctrl-a to access these functions, ESC for previous menu Save System and Test Status EASY INSTALL 9783-RtrSLV 2/26/2001 00:01 Paradyne 000.000.000.000 Clear 000.000.000.000 Clear 0,35...
Page 16: Completing Setup From The Noc
2. If the router will not be connected to a Paradyne DSLAM, change the DSLAM Type. Other selections are Alcatel (NewBridge), PairGain, and Nokia. 3. Enter the Node IP Address and Subnet Mask. 4. Specify TS Access if a Troubleshooting (TS) DLCI or Virtual Circuit (VC) is being set up for remote access by the service provider.
Page 17: Setting Up For In-Band Management
Configuring SNMP Trap Managers and Traps Procedure To enter SNMP managers and configure traps: 1. Select SNMP Traps. Main Menu Configuration SNMP Traps 2. Configure the following: — Enable SNMP Traps. — Identify the total Number of Trap Managers. — Specify the IP address for each NMS Trap Manager to which traps will be sent. —...
Page 18 Procedure 1. Create a DLCI on the router virtual port. Configuration Assign the DLCI number that will be used for management on Serial port 0 (Rtr-S0 – e.g., DLCI 900). 2. Create a management PVC using the DLCI just configured on Serial port 0 to connect the management link to the router.
Page 19 Verifying the End-to-End Management Path After installation of a remote router, run an ATM Ping test from the Hotwire GranDSLAM. Procedure To Ping the router: 1. From the Hotwire ATM Line Card’s Main Menu, select the ATM Ping test. Diagnostics ATM Ping (D-C) 2.
Page 20: Provisioning The Router Interface
Provisioning the Router Interface The FrameSaver DSL 9783 Router defaults to bridge mode. Routing without bridging, and simultaneous routing and bridging, are also options. Use the bridge command from the router’s CLI to configure the bridge and routing attributes.
Page 21: Cables And Connectors
Cables and Connectors Installing the Router Refer to The DSL network interface uses an 8-pin, un-keyed modular plug. Use a standard twisted-pair CAT3, or better, cable. 8-Pin Connector (Similar to RJ48C) Pin # Function 1–3 Not used DSL Ring DSL Tip 6–8 Not used on page 6 for cable installation information.
Page 22 The Ethernet interface connector uses an 8-pin, non-keyed modular plug. Use shielded twisted-pair CAT5, or better, cables. See — To connect the router to an Ethernet hub, use a straight-through connection. 8-Pin Straight-Through Connections Pin # Function 10/100BaseT TX D+ 10/100BaseT TX D–...
Page 23 The communication (COM) port connector uses a 25-position, EIA-232-C connector. Pin # Signal Shield (GND) DCE Transmit Data (TXD) DCE Receive Data (RXD) DCE Request To Send (RTS) DCE Clear To Send (CTS) DCE Data Set Ready (DSR) Signal Ground (GND) DCE Carrier Detect (CD) 9–19 Not used...
Page 24: Dsl Router Technical Specifications
DSL Router Technical Specifications Item Approvals FCC Part 15 Safety Certifications Physical Environment Operating temperature Storage temperature Relative humidity Shock and vibration Power Consumption and Dissipation Height x Width x Depth Weight COM Port Standard Data rates DSL Network (NET) Line Code Service Data rates...
Page 25: Important Safety Instructions
Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered.
Page 26: Emi Notices
The authority to operate this equipment is conditioned by the requirements that no modifications will be made to the equipment unless the changes or modifications are expressly approved by Paradyne Corporation. CANADA – EMI NOTICE: This Class A digital apparatus meets all requirements of the Canadian interference-causing equipment regulations.
Page 27: Government Requirements
Government Requirements Certain governments require that instructions pertaining to connection to the telephone network be included in the installation and operation manual. Specific instructions are listed in the following sections. Notice to Users of the Canadian Telephone Network The Industry Canada label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s).
Page 28: Warranty, Sales, Service, And Training Information
Document Feedback We welcome your comments and suggestions about this document. Please mail them to Technical Publications, Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to userdoc@paradyne.com. Include the number and title of this document in your correspondence. Please include your name and phone number if you are willing to provide additional clarification.
