Panasonic KX-TS520MX Operating Instructions

1 Getting Started
1-A Controls
Operating Instructions

Integrated Telephone System

KX-TS520MX
Model No. 



Accessory information
 Handset . . . . . . . . . . . . . . . . . one
 Handset cord . . . . . . . . . . . . . one
 Telephone line cord . . . . . . . . one
Please read these operating instructions before
using the unit and save them for future reference.
1-B Connections
LINE DATA 1
Connect the handset cord () to the handset
For your future reference
and the unit. Connect the telephone line
We recommend keeping a record of the following
cord until it clicks into the unit and telephone
information to assist with any repair under warranty. Handset
line jack (). After line connection, lift the
Serial No.
handset to check for a dial tone.
(found on the bottom of the unit)
2
Set the DIALING MODE selector to TONE.
Date of purchase  If you cannot dial,
Telephone
set to PULSE.
line cord
Name and address of dealer
To single-line Handset cord
3
Set the RINGER selector to HIGH, LOW or OFF.
telephone jack
(Example : "HIGH" is selected.)
 When set to OFF, the unit
Attach your purchase receipt here.
will not ring but the ringer
indicator will still fl ashing.
Connecting a communication device
1-62, 4-chome, Minoshima, Hakata-ku,
Fukuoka 812-8531, Japan
If you connect a communication device (computer, modem, fax, answering machine, etc.) to
the telephone line, you can connect it through this unit using the DATA jack. After connecting
the handset and telephone line cord, connect the communication device telephone line cord to
the DATA jack.
 Make sure the communication device is not in use before using this unit (making calls, storing phone
numbers in memory etc.) or the communication device may not operate properly.
PNQX1078ZA FM0908SS0
2 Making/Answering Calls
2-A Making calls
1 To redial the last number dialed
Memory sticker  DIALING MODE Lift the handset and dial the phone number.
Lift the handset
selector 2
When you fi nish talking, place the handset
 {REDIAL} will dial the last number you called
Ringer indicator  RINGER selector on the cradle.
manually, not a One-Touch Dialer number (3-B).
Auto dial {M1},  {REDIAL}
To adjust the receiver volume (6 levels)
{M2}, {M3}
Press {}
VOLUME {}, {FLASH}

 After hanging up, the volume level will be saved.
{}
{PAUSE} {PROGRAM}

2-B Answering calls
{*} {TONE}
 The ringer indicator will fl ash when
When a call is being received, the unit rings,
 a telephone number is dialed in PULSE mode,
the ringer indicator fl ashes quickly. You can
or
answer the call by simply lifting the handset.
 someone picks up or hangs up another phone
connected to the same phone line.
This is normal.
3 One-Touch Dialer
3-A Storing phone numbers in memory
You can store up to 3 phone numbers in the
If you misprogram
one-touch auto dial buttons {M1}, {M2} or
Hang up
{M3}. Do not press any one-touch auto dial
To erase a stored number
buttons before storing to prevent misoperation.
Lift the handset
1  Press {PROGRAM}.
Lift the handset
the one-touch auto dial button {M1}, {M2}

2 Press the one-touch auto dial button {M1}, or {M3} of the phone number to be erased
TONE PULSE {M2} or {M3}.  {PAUSE}
DIALING MODE
3
Enter a phone number up to 21 digits. Memory sticker
Use the memory sticker as a name or
4 Press {PROGRAM}.
phone number index for the stored numbers.
5
When fi nished, hang up.
RINGER
 If a pause is required for dialing, press
HIGH OFF
{PAUSE} in step 3. A pause stored in a phone
LOW
number counts as one digit (4-C).
3 One-Touch Dialer
3-B Dialing a stored number
1
Lift the handset.
Press {REDIAL}.

2
Press the one-touch auto dial button {M1}, {M2} or {M3}.
 {REDIAL} does not work for One-Touch Dialer.
To dial the number again, hang up and repeat steps 1 and 2.
 If the telephone line cord is disconnected more than 3 days, the stored numbers may be erased.
or {} repeatedly while talking.
Store phone numbers again, if necessary.
4 Special Features
4-A For call waiting service users
To use call waiting, you must fi rst subscribe to the call waiting service of your service provider/
telephone company. This feature allows you to receive calls while you are already talking on the
phone. If you receive a call while on the phone, you will hear a call waiting tone.
1 Press {FLASH} to answer the 2nd call.
2 To switch between calls, press {FLASH}.
Note:
 Please contact your service provider/telephone company for details and availability of this service in your
area.
 4-B Temporary tone dialing (for rotary/pulse service users)
Restart from step 1.
Press {PROGRAM} You can temporarily switch the dialing mode to tone when you need to access touch-tone
 
services (for example, answering services, telephone banking services, etc.). Press {*} {TONE}
before entering access numbers which require tone dialing.

 {PROGRAM} 
Hang up.
4-C Pause
(for PBX/long distance service users)
A pause is sometimes required when making calls using a PBX or long distance service.
Example: If you need to dial the line access number "9" when making outside calls with a PBX:
1
Lift the handset to start calling.
2 {9}  {PAUSE}
3
Dial the phone number.
Note:
 A 2.1 second pause is inserted each time {PAUSE} is pressed. Repeat as needed to create longer
pauses.
5 Things You Should Know 5 Things You Should Know
5-A Wall mounting 5-C For your safety
1 3 To prevent severe injury and lost of life/
Press the tabs in the direction of the arrows Drive screws (not included) into the wall
property, read this section carefully before
(), then remove the wall mounting adaptor using the wall template below. Connect the
using the product to ensure proper and safe
telephone line cord. Mount the unit and then
().
operation of your product.
slide it down.
LINE
Screws WARNING
DATA
 To prevent the risk of fi re or electrical shock, do
not expose the product to rain or any type of
moisture.
8.3 cm
 Do not disassemble the product.
 Do not spill liquids (detergents, cleansers, etc.)
2
Tuck the telephone line cord inside the onto the telephone line cord plug, or allow it
Hooks to become wet at all. This may cause a fi re.
wall mounting adaptor, and push it in the To single-line
If the telephone line cord plug becomes wet,
telephone jack
direction of the arrow.
immediately pull it from the telephone wall jack,
(LINE)
 The word "UP WALL" should face upward.
and do not use.
To communication
CAUTION
device (DATA)
 Never install telephone wiring during an electrical
storm.
 Never install telephone line jacks in wet locations
To temporarily set the
unless the jack is specifi cally designed for wet
handset down during a
locations.
conversation, place it as
 Never touch uninsulated telephone wires or
shown here.
terminals unless the telephone line has been
disconnected at the network interface.
 Use caution when installing or modifying
telephone lines.
5-B Troubleshooting
Important safety instructions
When using your product, basic safety precautions
Problem Cause/solution
should always be followed to reduce the risk of fi re,
electric shock and injury to persons, including the
The unit does not work.  Check the connections (1-B).
following :
 Check whether the DIALING MODE selector setting is correct or not
The call cannot be connected
even if you dialed correctly. (1-B).
The unit does not ring.  The RINGER selector is set to OFF. Set to HIGH or LOW (1-B).
5-D Specifi cations
You cannot store a phone  Confi rm the handset is off the cradle.
number in memory.  Do not enter a phone number more than 21 digits long, or the
Power Source:
entered number and the previously stored number will be cleared.
Dimensions (H x W x D):
 {PROGRAM} was pressed during the conversation. Press {PROGRAM}
The other party suddenly
Mass (Weight):
cannot hear your voice during
again.
Operating conditions:
a conversation.
You cannot redial by pressing  If the last number dialed was more than 31 digits long, the number
Note:
{REDIAL}.
will not be redialed.  Design and specifi cations are subject to change without notice.
 The illustrations in these instructions may vary slightly from the actual product.
Liquid or other form of  Disconnect the telephone line cord from the unit. Leave to dry for
moisture has entered the unit. at least 3 days. After the unit are completely dry, reconnect the
Copyright:
telephone line cord.
This material is copyrighted by Panasonic Communications (Malaysia) Sdn. Bhd., and may be
reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without
Wall Template
the written consent of Panasonic Communications (Malaysia) Sdn. Bhd.
8.3 cm
© 2008 Panasonic Communications (Malaysia) Sdn. Bhd. All Rights Reserved.
1. Do not use this product near water, for example,
near bathtub, washbowl, kitchen sink or laundry
tub, in a wet basement or near a swimming pool.
2. Avoid using a telephone (other than a cordless
type) during an electrical storm. There may be a
remote risk of electric shock from lightning.
3. Do not use the telephone to report a gas leak in
the vicinity of the leak.
SAVE THESE INSTRUCTIONS
Environment
 The product should be kept free from excessive
smoke, dust, high temperature, and vibration.
 The product should not be exposed to direct
sunlight.
 Do not place heavy objects on top of the product.
 The product should be kept away from heat
sources such as radiators, cookers, etc. It should
not be placed in rooms where the temperature
is less than 5°C or greater than 40°C. Damp
basement should also be avoided.
Routine care
 Wipe the outer surface of the product with a
soft moist cloth.
 Do not use benzine, thinner, or any abrasive
powder.
Notice for product disposal, transfer, or
return
 This product can store your private/confi dential
information. To protect your privacy/confi dentiality,
we recommend that you erase the information
such as one-touch dialer from the memory before
you dispose of, transfer, or return the product.
From telephone line
Approx. 95 mm  190 mm  196 mm
Approx. 518 g
5°C–40°C, 20 %–80 % relative air humidity (dry)
