TVM-2002 model
TVM-2202/2212 models
TVM-2402/2702 models
TVM-3202/4002 models
Attaching the monitor
mount
Tighten the screws at the locations indicated
by the arrows shown in the following
illustration.
4
The monitor's installation surface is
compatible with other types of VESA standard
stands.
Hole spacing: 100 x 100 mm
Screw length: 8 to12 mm

Connections

1. AC Input
2. AUDIO IN
Audio signal input.
3. CAM IN (not available on TVM-2212)
Composite signal input.
4. CAM OUT (not available on TVM-2212)
Composite signal output.
5. HDMI
HDMI signal input.
6. VGA
RGB signal input.
TruVision Monitor User Manual
