Model PSM 200 User Guide
®
PSM
200
Personal Monitor System User Guide
Guide de l'utilisateur du système de retour personnel
Bedienungsanleitung für das In–Ear–Abhörsystem
Guía del usuario del sistema de monitoreo personal
Guida all'uso del sistema di monitoraggio personale
Manual do Usuário do Sistema de Monitoração Pessoal
>>E2
>>P2R
>>P2T
© 2002, Shure Incorporated
27a8792 (BA)
Printed in U.S.A.

Advertisement

Table of Contents
loading

Related Manuals for Shure PSM 200

Summary of Contents for Shure PSM 200

  • Page 1 Model PSM 200 User Guide ® Personal Monitor System User Guide Guide de l’utilisateur du système de retour personnel Bedienungsanleitung für das In–Ear–Abhörsystem Guía del usuario del sistema de monitoreo personal Guida all'uso del sistema di monitoraggio personale Manual do Usuário do Sistema de Monitoração Pessoal >>E2...

  • Page 2: Declaration Of Conformity

    At the test location of L. S. Compliance, Inc. W66 N220 Commerce Ct. Cedarburg, Wisconsin 53012, U.S.A. Shure Incorporated., Manufacturer. Signed: Date: March 04, 2002 Name, Title: Craig Kozokar, EMC Project Engineer Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of FCC Rules.
  • Page 3 LICENSING INFORMATION Changes or modifications not expressly approved by Shure Incorporated could void your authority to operate the equipment. Licensing of Shure wireless microphone equipment is the user’s responsibility, and licensability depends on the user’s classification and application, and on the selected frequency.

  • Page 4: Table Of Contents

    ENGLISH TABLE OF CONTENTS QUICK SET-UP GUIDES ..................PSM200 Wireless System .

  • Page 5: Quick Set-Up Guides

    ENGLISH QUICK SET-UP GUIDES 200 Wireless System The following set-up illustration is for the complete PSM200 Wireless System, which includes the P2T TransMixer, the P2R Receiver, and the E2 Earphones. If you have purchased the P2R as a stand-alone wired personal monitor, see page 6.

  • Page 6: P2R Receiver Quick Set-Up Guide

    ENGLISH P2R Receiver Quick Set-Up Guide: When Used as a Wired Stand-Alone Personal Monitor Mixing Console Insert a 9 Volt battery into the P2R Receiver, Connect an audio source to the -inch MIX IN jack observing proper polarity. on the side of the P2R. Turn the P2R volume knob on (past the click).

  • Page 7: Introduction

    ENGLISH INTRODUCTION Thank you for buying the PSM200. Like all Shure PSM personal monitoring products, the PSM200 provides the many advantages of in-ear monitoring including: Improved Sound Quality —high fidelity without the risk of feedback, Increased Mobility —your mix moves with you, Personal Control —create a personal mix, and control your own levels.

  • Page 8: The P2T Transmixer

    ENGLISH THE P2T TRANSMIXER Controls and Features FRONT PANEL: BACK PANEL: MIC/LINE INPUT Jacks: Electronically balanced inputs SELECT Button: Press to select a frequency channel. that accommodate both XLR and -inch connectors at Antenna: Permanently mounted, break–resistent anten- mic or line levels. na transmits the mix to the P2R Receiver.

  • Page 9: P2R Receiver

    ENGLISH P2R RECEIVER Controls and Features POWER LED: Lights to indicate the unit is powered on SELECT Button: Press to increment the frequency and blinks to indicate low battery. When this LED starts channel or set to “A” for wired mode. blinking, you have approximately 15 minutes of battery MIX IN Jack: Connect a inch line-level input to this...

  • Page 10: Wireless Mode

    Shure E2 earphones. The LIM LED on the top of the unit lights up when the limiter is on. If the LIM LED blinks occasionally, turn down the volume of the receiver.* If the LED is on and you haven’t reached a high enough listening level, try re-inserting the earphones for a better seal,...

  • Page 11: Set-Up

    ENGLISH SET-UP Wireless System Set-Up To configure the P2T TransMixer and P2R Receiver for wireless operation: Plug the power supply into the DC INPUT connector on the To pass audio signal directly through the TransMixer, use rear panel of the P2T, then plug it into a power outlet. the corresponding SPLIT OUT connector on the rear panel of the device.

  • Page 12: System Applications

    ENGLISH SYSTEM APPLICATIONS This section presents three typical applications for the PSM200. For more ideas, visit Shure’s website at www.shure.com. APPLICATION ONE: Wireless Set-Up for a Vocalist This is the basic wireless configuration of the PSM200 system for a single user, either instrumental or vocal: Connect the vocal mic to INPUT 1 of the P2T TransMixer.

  • Page 13: Application Three: Two Psm200 Wireless Systems Used Simultaneously

    ENGLISH APPLICATION THREE: Two PSM200 Wireless Systems Used Simultaneously* The following configuration uses two PSM200 systems simultaneously, and utilizes the SPLIT OUT feature of the TransMixer. In this exam- ple, the musicians keep the TranMixers on stage with them, in order to control their personal mixes independent of the house engineer. Connect the vocal mic to INPUT 1 of the Vocal Mix TransMixer and connect SPLIT OUT 1 (the vocals) to the Mixing Console.

  • Page 14: Troubleshooting

    Optional Equipment AuxPander: AP200: The Shure AuxPander auxiliary expander extends the capabili- You can use the AP200 adaptor to connect a lavalier micro- ties of a standard mixing console by providing eight additional phone to the MIX IN jack on the P2R Receiver. The AP200 auxiliary sends.

  • Page 15: P2T Transmixer Specifications

    P2T TransMixer. For more information on which frequencies can be used in your area, call our Applications Group at 847–866–2525, or visit the Technical Support section at www.shure.com. (518–554)MHz (800–814)MHz...

  • Page 16: Certifications

    Shure’s instruction, or unauthorized re- date of purchase for all transmitter parts. At its option Shure will pair. All implied WARRANTIES OF MERCHANTABILITY or...
  • Page 17 SHURE Incorporated Web Address: http://www.shure.com SHURE Incorporated Web Address: http://www.shure.com 222 Hartrey Avenue, Evanston, IL 60202-3696, U.S.A. 222 Hartrey Avenue, Evanston, IL 60202-3696, U.S.A. Phone: 847-866-2200 Fax: 847-866-2279 Phone: 847-866-2200 Fax: 847-866-2279 In Europe, Phone: 49-7131-72140 Fax: 49-7131-721414 In Europe, Phone: 49-7131-72140 Fax: 49-7131-721414...
