I.2.1 Operational Case Examples
IMPORTANT
Make sure to set the data rate to 512 Kbps initially. This data rate is applicable to all modes of
operation.
I.2.1.1

Case 1: IDR 8.448 Mbps, 3/4 Rate Viterbi

Start with the Data Rate = 512 Kbps
Modulator:
Method 1 -
Under Interface Menu:
Set Interface type
Set Tx clock selection
Set mode to IDR
Under Mod Data Menu:
Under Mod IF Menu:
Method 2 -
Under Interface Menu:
Set Interface type
Set Tx clock selection
Set Mod strap code to: 128
Under Mod IF Menu:
MN-DMD2050E Revision 2
Set code rate to 3/4 VIT
Set data rate for 8448000
Set desired Tx frequency and power level
Turn IF ON
