INSTALLATION MANUAL
AIR CONDITIONER
• Please read this installation manual completely before installing the product.
• Installation work must be performed in accordance with the national wiring
standards by authorized personnel only.
• Please retain this installation manual for future reference after reading it
thoroughly.
TYPE : Refrigerant Leak Detector
MODEL : PLD-RNV0S
P/NO : MFL68102202
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG PLD-RNV0S
Summary of Contents for LG PLD-RNV0S
-
Page 1: Installation Manual
• Installation work must be performed in accordance with the national wiring standards by authorized personnel only. • Please retain this installation manual for future reference after reading it thoroughly. TYPE : Refrigerant Leak Detector MODEL : PLD-RNV0S www.lg.com P/NO : MFL68102202... -
Page 2: Table Of Contents
Refrigerant Leak Detector Installation Manual TABLE OF CONTENTS 1. Safety Precautions ......................3 2. Components........................5 3. Part Functions.........................6 4. Part Specification ......................7 5. Refrigerant Leak Detector....................8 Main Features........................8 Detector Alarm........................9 6. How to Install ........................10 7. Installation Order ......................11 8. Test Run.........................14 Pre-check ........................14 Checking the refrigerant leak detector setting - Wired Remote Control ......14 Checking the refrigerant leak detector setting - Wireless Remote Control.....15... -
Page 3: Safety Precautions
Safety Precautions 1. Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. n Be sure to read before installing the unit. n Be sure to observe the cautions specified here as they include important items related to safety. - Page 4 Safety Precautions Do not put a sharp and Do not create an impact Do not touch with a wet pointed object, etc. into a with a sharp and pointed hand or pull a connecting crack or gap. object, etc. cable. •...
-
Page 5: Components
Components 2. Components User/Installation Manual 6 Set Screws Connecting Cable Sensor Protective Cover Sensor Installation Manual 5... -
Page 6: Part Functions
Part Functions 3. Part Functions Sensor - LED: Displays the state of the sensor. Detecting Part - Detecting Part : Detects the concentration of refrigerant R410A in the air. Connecting Cable - Connecting Cable Mating Section : Mating Section Combines a cable connected to an indoor unit. -
Page 7: Part Specification
Part Specification 4. Part Specification Sensor Item Unit Spec. Rated Voltage DC 5.0 ± 5 % Dimension (WⅹHⅹD) 31 x 44 x 20 Weight Refrigerant R410A Detected Concentration 0/6000, Alarm off/on Operating Temperature Range °C -10 ~ 50 Preserved Temperature Range °C -40 ~ 60 Average Power Consumption... -
Page 8: Refrigerant Leak Detector
Refrigerant Leak Detector 5. Refrigerant Leak Detector Main Features 1. The refrigerant leak detector detects the concentration of refrigerant (R410A) in the air. 2. If the concentration of the refrigerant in the air exceeds 6000 ppm, the indoor unit buzzer, the error indicator on the wired remote control, and the sensor alarm go off to alert the user of a refrigerant leak. -
Page 9: Detector Alarm
Refrigerant Leak Detector Detector Alarm 1. Indoor Unit Alarm - If the concentration of the refrigerant in the air exceeds 6000 ppm, the indoor unit buzzer goes off to alert the user. * Release conditions: If the concentration of the refrigerant is 6000 ppm or less by ventilating the immediate vicinity, or the power button of the wired remote control, wireless remote con- trol, and central control is pressed. -
Page 10: How To Install
How to Install 6. How to Install 1. Installation Place to Improve Detection Performance - Installation Place by Refrigerant Characteristics Because R410A is heavier than air, the refrigerant leak detector must be installed near the floor. Install at a height of 300-500 mm off the ground (generally lower than the height of a bed). •... -
Page 11: Installation Order
Installation Order 7. Installation Order 1. Affix the sensor protective case (backplate) firmly by using the set screws at a height of 300- 500 m from the floor. 300 ~ 500 mm <How to Fix Screws> <Installation Place> Do not install around the window or door. When it is installed, the refrigerant leak detector may fail to detect gases. - Page 12 Installation Order 3. The connecting cable may be installed in four directions. Install by adjusting in the proper direction depending on the installation environment. - Installation Direction: Wall embedded, upper, right, and bottom - When installing the connecting cable to the upper, right, or bottom surface, remove the guide grooves from the connecting cable.
- Page 13 Installation Order 5. Affix the upper part of the sensor protective cover (front plate) to the sensor protective case (backplate) that is attached to the wall as shown in the figure to the right. Press to combine with the bottom part. Wall Wall - Assemble all four sides of the sensor protec-...
-
Page 14: Test Run
Test Run 8. Test Run Pre-check This is a step to check whether the refrigerant leak detector is properly installed for the test run. 1. Check whether the power is connected. 2. After connecting the power, 7 seconds is the initial sensor startup time. 3. -
Page 15: Checking The Refrigerant Leak Detector Setting - Wireless Remote Control
Test Run Checking the refrigerant leak detector setting - Wireless Remote Control The installer setting mode is a mode for setting the detailed features of the indoor unit. If the installer setting mode is set incorrectly, a product defect, user injury, or property damage may occur. -
Page 16: Leak Check For Refrigerant Leak Detector
Test Run Leak Check for Refrigerant Leak Detector 1. Have gas enter through the opening of the sensor protective case by using the gas Part from a gas lighter. exposed (Proceed when the sensor protective case to gas has been assembled.) - Until the sensor detects the gas lighter, continue to open the valve of the gas lighter. - Page 17 Test Run * Refrigerant leak detector: The green and red LED lights blink simultaneously. (Check through the opening of the sensor protective case.) * Indoor unit: Buzzer alarm * Wired remote control: CH230 displayed When a leak is not detected or the sensor is out of order, the following alerts appear: * When a leak is not detected: The green LED always turns on.
-
Page 18: Checkup Before Reporting Trouble
Checkup before Reporting Trouble 9. Checkup before Reporting Trouble If there is any problem with the product, check the following before inquiring with the service cen- ter: Symptom Checkup Action • Check the circuit breaker. • Is the air conditioner powered •... -
Page 19: Troubleshooting
Checkup before Reporting Trouble Error Number Error Description Meaning Main Cause 1. Incorrect setting for the refrigerant leak detector 2. Short failure of the refrigerant leak detector Refrigerant leak Error with detecting terminal detection and sensor refrigerant leak 3. Wrong connection of the refrigerant leak failure error detector 4. - Page 20 Refrigerant Leak Detector...
