Model No. PATL50707.0
Serial No.
Write the serial number in the space
above for future reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if any
parts are missing or damaged,
please see the dealer contact in-
formation on the back cover of
this manual or on the included
service card.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Advertisement
Table of Contents
Related Manuals for ProForm PATL50707.0
Summary of Contents for ProForm PATL50707.0
- Page 1 Model No. PATL50707.0 Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? If you have questions, or if any parts are missing or damaged, please see the dealer contact in- formation on the back cover of this manual or on the included service card.
-
Page 2: Table Of Contents
HOW TO FOLD AND MOVE THE TREADMILL ........ -
Page 3: Important Precautions
To reduce the risk of serious injury, read all important precautions and in- structions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product. - Page 4 Servicing other than the procedures in this manual should be performed by an authorized ser- vice representative only. 25. This treadmill is intended for in-home use only. Do not use this treadmill in a commer- cial, rental, or institutional setting.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the PROFORM treadmill. The STYLE 4500 treadmill combines ad- vanced technology with innovative design to let you enjoy an excellent form of cardiovascular exercise in the convenience and privacy of your home. And when you’re not exercising, the unique STYLE 4500 treadmill... -
Page 6: Assembly
During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. This does not affect treadmill performance. If there is lubricant 4” Bolt (120)–2 on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner. - Page 7 58mm Bolts (13), two M6 Washers (32), and two M6 Nuts (43). 4. Position the Base (52) as close to the front of the treadmill as possible, as shown. See the upper inset drawing. Wrap the wire tie in the Right Upright (54) around the end of the Wire Harness (39).
- Page 8 5. See the left inset drawing. Identify the two Frame Spacers (11). Open the included packet of grease, and apply grease to both sides of both Frame Spacers. Then, identify the outer side of each Frame Spacer. Hold a Frame Spacer (11) between the Right Upright (54) and the Lift Frame (23), with the outer side of the Frame Spacer facing the Right Upright.
- Page 9 7. Set the Console (91) face-down on a soft sur- face to avoid scratching the Console. Hold the Right Handrail (33), which has a large hole in the location shown, near the Console. Next, insert the console wire and tie into the hole in the side of the Right Handrail (33).
- Page 10 10. Have a second person raise and hold the tread- mill Frame (51). Identify the Gas Spring (98). Note that the Gas Spring has a cylinder end and a rod end. See the two small inset drawings. Locate the Spring Clip (96) in the rod end of the Gas Spring.
- Page 11 15. Make sure that all parts are properly tightened before you use the treadmill. Keep the included hex keys in a secure place. The hex key is used to adjust the walking belt (see page 20). To protect the floor or carpet, place a mat under the treadmill.
-
Page 12: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT Your treadmill features a walking belt coated with high-performance lubricant. IMPORTANT: Never apply sili- cone spray or other substances to the walking belt or the walking platform. Such substances will deterio- rate the walking belt and cause excessive wear. - Page 13 Switch the circuit breaker to the reset position. Next, stand on the foot rails of the treadmill. Find the clip attached to the key (see the drawing above) and slide the clip onto the waistband of your clothes. Then, insert the key into the console.
- Page 14 To restart the walking belt, press the Start button or the Speed increase button. 4. Change the incline of the treadmill as desired. To change the incline of the treadmill, hold down the Incline increase or decrease button until the desired incline level is reached.
- Page 15 Step onto the foot rails, press the Stop button, and adjust the incline of the treadmill to the lowest setting. The incline must be at the lowest setting when you fold the treadmill to the storage posi- tion, or you may damage the treadmill.
- Page 16 3. Press the Start button or the Speed increase button to start the workout. When you press either button, the treadmill will au- tomatically adjust to the speed setting that is pro- grammed for the first segment of the workout. Hold the handrails and begin walking.
-
Page 17: How To Fold And Move The Treadmill
1. Hold the handrails and place one foot against one of the wheels. Do not pull back on the frame. 2. Tilt the treadmill backward until it rolls freely on the wheels, and carefully move the treadmill to the desired location. - Page 18 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Next, lower the frame until it is past the latch pin.
-
Page 19: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a. - Page 20 Be careful to keep the walking belt centered. Then, plug in the power cord, insert the key, and run the treadmill for a few min- utes. Repeat until the walking belt is properly tight- ened.
-
Page 21: Exercise Guidelines
EXERCISE GUIDELINES WARNING: Before beginning any exercise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems. The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings. -
Page 22: Part List
PART LIST—Model No. PATL50707.0 To locate the parts listed below, see the EXPLODED DRAWING near the end of the manual. Key No. Qty. Description M10 x 60mm Patch Bolt M10 x 58mm Bolt M4.2 x 13mm Tek Screw M4.2 x 16mm Screw... - Page 23 Key No. Qty. Description Belt Guide 5mm Hex Key Frame Endcap Gas Spring Clip Kit Rear Foot, Right Gas Spring Receptical Incline Motor Wire Front Roller Washer Cage Nut Caution Decal Transformer Incline Motor Spacer Motor Isolator Motor Bushing M10 Lock Nut M4 x 10mm Screw Key No.
-
Page 24: Exploded Drawing
EXPLODED DRAWING A—Model No. PATL50707.0 R0907A... - Page 25 EXPLODED DRAWING B—Model No. PATL50707.0 R0907A 42 21...
- Page 26 EXPLODED DRAWING C—Model No. PATL50707.0 43 43 R0907A...
- Page 27 EXPLODED DRAWING D—Model No. PATL50707.0 R0907A...
-
Page 28: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the dealer contact information on this page or on the included service card. To help us assist you, be prepared to provide the following information when contacting us: • the model number and the serial number of the product (see the front cover of this manual) •...
