7. Have a second person hold the Upright (2)
near the Frame (1) as shown. Next, connect
the Upper Wire Harness (18) to the Lower
Wire Harness (38).
Attach the Upright (2) to the Frame (1) with
two M8 x 69mm Button Bolts (91), two M8
Split Washers (93), and two M8 Nylon
Locknuts (87). Be careful to avoid pinching
the wires.
8. Attach the Water Bottle Holder (17) to the
Upright (2) with two M4 x 22mm Screws (66).
7
2
87
8
2
9
Avoid pinching the
Wire Harnesses (18,
38) during this step
18
38
1
91
93
17
66
