- Page 1 PRODUCTION RELEASE & REVISION DESCRIPT'N/BUYER DWG No PARTS No. BY DATE INITIAL ------------------- 50303866 J.Y.LIU M.J.KWON 15-04-13 WDR Super High Resolution Day & Night Camera 3-AXIS INFRARED - LED PLASTIC DOME CAMERA NOTES 1.MODEL:HCGI-P61DN(P)FxW2/ NO BRNAD 모조지100g/m WHITE 2.MATERIAL: 3.COLOR: BLACK 4.SIZE:105(+/-5)mm x 148(+/-5)mm 5.LABEL: ------------- 105(+/-5)mm...
- Page 2 WDR Super High Resolution Day & Night Camera 3-AXIS INFRARED - LED PLASTIC DOME CAMERA...
-
Page 3: Fcc Compliance Statement
FCC COMPLIANCE STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC INFORMATION : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. . Do not block any ventilat ion openings. Install in accord ance with the manufacturer`s instructions. 6. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 5: Table Of Contents
TABLE OF CONTENTS INTRODUCTION CONNECTIONS Heater/RubberWashers/Desi-Pack SETUP MENU ADVANCED MENU VIDEO OUT CHECK SWITCHS SETTING SPECIFICATIONS EXTERNAL DIMENSION... -
Page 6: Introduction
The camera provides a high-quality image using SONY Wide Dynamic 1/3” Super-HADII PS 960H CCD and digital signal processing LSI chips. 1/3" Super-HADII PS 960H CCD Super high-resolution of 720TV lines Wide Dynamic Range (~x512) -Double shutter+ATR-EX2 Digital Noise Reduction- 2D,3D Day &... -
Page 7: Connections
REMINDER: Never aim the camera directly into the sun. BOTTOM 1. Lens : 2.5 ~ 12mm 2. Power : DC12V input: Red (+) * If using DC 12V power, use a power supply capable of supplying 5 Watts. 3. Video: BNC (Yellow) connector 4. -
Page 8: Heater/Rubberwashers/Desi-Pack
(Option) Heater Kit HEATER (IF APPLICABLE) Power Supply 12V DC Power Consumption Power Cable Heater ON at 41 F (5 C) (DC 12V) Heater OFF at 59 F (15 C) HEATER Rubber Washers(Waterproof) Mount position TOP CASE BOTTOM CASE Accessories: Torx wrench(4) M4x20 pan-head screws(4) Rubber washers(4) -
Page 9: Setup Menu
<SETUP MENU> 1. Scene Select function The six modes can be selected. CUSTOM /FULL AUTO / INDOOR / OUTDOOR / BACK LIGHT / ITS CUSTOM This mode turns off the auto scene recognition. All functions can be set and adjusted manually FULL AUTO This mode supports various shooting scenes. - Page 10 5. PRIVACY MASK The mask function hides one or more areas which the user does not want to be displayed on the screen. This SET is capable of outputting 15 masks to the display. Each of these 15 masks can be set with its own display area, color, darkness and mosaic processing.
- Page 11 CAMERA ID SETUP 7-4. CAMERA ID CAMERA ID Sets the camera ID to ON or OFF. the CAMERA ID SETUP screen can be displayed. ABCDEFGHIJKLMNOPQRSTUV A title of 64 characters per line can be configured. W X Y Z 0 1 2 3 4 5 6 7 8 9 ! ” # $ % & ( )_’,￥...
-
Page 12: Advanced Menu
MANUAL - REGISTRATION Manual white pixel defect information registration 1) Press the Enter button to turn White pixel compensation position marker display. 2) Use the Arrow buttons align the marker with the position of the white pixel. 3) Press the Enter button to exit and Press the EXIT button to save. Note : In manual detection mode, the detection data is always treated as a very large white pixel. - Page 13 13. FLK LESS Select Flickerless function to be AUTO/ON/OFF. MODE-When AUTO or ON selected: GAIN CNTL Selects gain modulation ON. SHUTTER FIX Selects flickerless shutter fix ON. 14. WHITE BAL Compensates for deviations in the white color caused by changes in the color temperature of the light source so that the colors are reproduced correctly.
- Page 14 16.WDR/ATR-EX CONTRAST(LOW/MID/HIGH) Contrast adjustment gain CLEAR FACE(OFF/ LOW/MID/HIGH) High-frequency component adjustment gain ATR-EX(Extended) The ATR function provides gradation compensation with the aim of improving visibility. It compensates to the optimum gradation on the basis of the luminance information. This function compresses the dynamic range while storing the contrast component of the subject. WDR(Wide Dynamic Range)-Option When users shoot subjects which exceed the dynamic range of the CCD image sensor, parts of the subjects suffer from loss of dark detail (blocked up shadows) or overexposure (blown out...
-
Page 15: Video Out Check
20. DEFOG Defoging function ON/OFF selection. The defog function raises the contrast to improve visibility. For example, in foggy conditions, contrast is reduced and visibility drops. In such cases, enabling the defog function prevents a drop in contrast. In addition to compensating for contrast, compensation is also made for the saturation, edges, and 3D-NR moving body identification threshold. -
Page 16: Switchs Setting
Switch Settings LEFT RIGHT SWITCH SETTING POSITION POSITION (Recommended) Mirror(Horizental) Image inversion MIRROR-Option STANDARD (No OSD Model only NOTE: Mirror function is used corresponds) for back up camera position IR LED AUTO Light HIGH NOTE: Low setting provides IR on @ 5Lux IR on @ 10 Lux less “wash-out”... -
Page 17: Specifications
SPECIFICATIONS MODEL NTSC Power source Power Power consumption 2.8 Watts / 0.23A (IR LED ON) Image sensor 1/3" SONY CCD Total number of pixels 1028(H)x508(V) 1028(H)x596(V) 15.625KHz(H) 15.734KHz(H) Scanning frequency 50Hz(V) 59.94Hz(V) Sync. system Internal Resolution 720 TVL Min. illumination 0.8 Lux(Color), 0 lux(B/W at IR ON) @ F1.2, 50 IRE IR LED 11EA(850nm) IR LED / SENSOR... - Page 21 50303866A...
