INSTRUCTION MANUAL
600TV Lines
High Resolution Day&Night Color Camera
Mobile IR Dome Camera
Please read this manual thoroughly before use, and keep it handy for future reference.
Design and specification are subject charge without notice.
105(+/-5)mm
NOTES
NOTES
1.MODEL:HCGI-E1NKF0W2A(H) / NO BRAND(N2040)
모조지100g/㎡, white
모조지100g/㎡, white
2.MATERIAL:
2.MATERIAL:
BIND : 접지
3.COLOR: BLACK
4.SIZE: 105(+/-5)mm x 148(+/-5)mm
5.LABEL: 50201270(81mm x 24mm)
6.ANY CHANGE OR ALTERNATION MUST BE
APPROVED BY HITRON DESIGN TEAM.
PRODUCTION RELEASE & REVISION
REV
DESCRIPT'N/BUYER
DWG No
PARTS No. BY
A
INITIAL
------------------- 50302919
B
7p Oring내용추가
------------------- 50302919
C
DesiPack내용추가
------------------- 50302919
50302919
ITEM
UNLESS OTHERWISE SPECIFIED
APPROVALS
DATE
ALL DIMENSIONS ARE IN MM.
- TOLERANCE
LABEL
+/- 3
MANUAL
+/- 5
K.H.JUNG
15-03-03
GUIDE
+/- 5
MATERIAL
CHKED
2
M.J.KWON
15-03-03
COLOR
DRAWN
3
J.Y.LIU
15-03-25
CHK
DATE
M.J.KWON K.H.JUNG 10-19-M12
J.Y.LIU
M.J.KWON 15-03-03
J.Y.LIU
M.J.KWON 15-03-25
DESCRIPTION/MATERIAL
QTY
PARTS LIST
TITLE
MANUAL INSTRUCTION
SIZE
REV.
C
A4
SCALE
DO NOT SCALE
Advertisement
Table of Contents
Related Manuals for Hitron HCGI-E1NKF0W2A
Summary of Contents for Hitron HCGI-E1NKF0W2A
- Page 1 Mobile IR Dome Camera Please read this manual thoroughly before use, and keep it handy for future reference. Design and specification are subject charge without notice. 105(+/-5)mm NOTES NOTES 1.MODEL:HCGI-E1NKF0W2A(H) / NO BRAND(N2040) 50302919 ITEM DESCRIPTION/MATERIAL 모조지100g/㎡, white 모조지100g/㎡, white 2.MATERIAL:...
- Page 2 INSTRUCTION MANUAL 600TV Lines High Resolution Day&Night Color Camera Mobile IR Dome Camera Please read this manual thoroughly before use, and keep it handy for future reference. Design and specification are subject charge without notice.
-
Page 3: Fcc Compliance Statement
FCC COMPLIANCE STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC INFORMATION : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. . Do not block any ventilat ion openings. Install in accord ance with the manufacturer`s instructions. 6. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. - Page 5 INTRODUCTION The camera provides high-quality images using Color CCD technology especially designed for closed-circuit television (CCTV) and security surveillance applications. Features: High resolution and high performance 1/3" Color CCD Technology Excellent picture quality 600 lines(Color) of resolution 0.1 lux(Color) , 0 lux(B/W ) @ F1.2 , 50IRE Sensitivity Auto electronic shutter [1/60(1/50) ~ 1/100,000] Auto White balance BLC (Back Light Compensation)
-
Page 6: Camera Connections
CAMERA CONNECTIONS REMINDER: Never aim the camera directly into the sun. BOTTOM 1. Lens : 2.5~12mm Fixed Lens F2.0 2. Power : DC12V input Red(+) or Center pin(+) Use Certified/Listed Class 2 power supply transformer only. *If using DC 12V power adaptor, Use a power supply capable of supplying 6 Watts. - Page 7 (Option) 5. Heater Kit HEATER (IF APPLICABLE) Power Supply 12V DC Power Consumption Power Cable Heater ON at 41 F (5 C) (DC 12V) Heater OFF at 59 F (15 C) HEATER 6. Rubber Washers(Waterproof) Mount position TOP CASE BOTTOM CASE Accessories: Torx wrench(4) M4x20 pan-head screws(4)
-
Page 8: External Dimension
EXTERNAL DIMENSION... -
Page 9: Specifications
SPECIFICATIONS / 0.25A COLOR CCD 811(H) X 507(V) 795(H) X 595(V) (non-condensing) 600TV Lines High Resolution Day&Night Color Camera 50302919C...
