Hitron HCG-N41K*F*W2 series User Manual And Instruction Manual

앞
뒤
전자
장경석
15-04-02
1 2
297(+/-5)mm
PRODUCTION RELEASE & REVISION
REV
DESCRIPT'N/BUYER
A
INITIAL
B
INITIAL
C
INITIAL
rev.B- 내용수정,재고없음,즉시적용
rev.C-rubber washer,Desi-Pack추가,재고소진적용
3
NOTES
1.MODEL:HCG(I)-N41KxFxW2xx(H)/ NoBrand
2.MATERIAL: 모조지
BIND : STAPLES -2
3.COLOR: BLACK
4.SIZE: 297(+/-5)mm x 210(+/-5)mm
5.LABEL: 50201270(81mm x 24mm)
6.ANY CHANGE OR ALTERNATION MUST BE
APPROVED BY HITRON DESIGN TEAM.
50303656
UNLESS OTHERWISE
SPECIFIED
ALL DIMENSIONS ARE IN MM.
- TOLERANCE
LABEL +/- 3
MANUAL +/-
5
GUIDE +/-
5
MATERIAL
2
COLOR
3
DWG No PARTS No. BY CHK
------------------- 50303656 J.Y.LIU M.J.KWON 11-12-M13
------------------- 50303656 J.Y.LIU M.J.KWON 04-03-M14
------------------- 50303656 J.Y.LIU M.J.KWON 15-04-02
WHITE
ITEM
DESCRIPTION/M ATERIAL
PARTS LIST
APPRO VALS DATE
TITLE
D.W.HWANG 15-04-02
MANUAL INSTRUCTION
CHKED
M.J.KWON
15-04-02
SIZE REV.
A4
DRAWN
J.Y.LIU
SCALE
15-04-02
DO NOT
DATE
QTY
C
SCALE
