Exploded View (Chassis) Parts List - Roland CUBE-15XL Service Notes

Sep. 2010

Exploded View (Chassis) Parts List

No. Part Code Part Name
1 SD000177 AC CORD PSE
SD000912 AC CORD ASSY
5100012741 AC CORD
SD000913 AC CORD ASSY
SD000914 AC CORD ASSY
SD000915 AC CORD ASSY
SD001068 AC CORD ASSY
5100005807 AC CORD ASSY
2 5100015015 CHASSIS
3 5100004359 CORD HOOK
4 5100004351 R-KNOB
5 22497521R0 PUSH BUTTON
6 12369410 CORD BAND
5100010992 CORD COVER
7 5100016555 MAIN BOARD ASSY
* This unit includes the following parts.
******** MAIN BOARD
******** PRE BOARD
******** PS1 BOARD
******** POWER SQUEEZER BOARD
8 SD000967 TRANSFORMER
SD000968 TRANSFORMER
9 02897801 SEESAW SWITCH
10 SD000053 PCB SPACER
11 SD000026 HEATSINK
12 5100016776 FUSE
03903834 FUSE
a 22150518 STANDOFF
b 40237101 SCREW M3X8
c 40012878 SCREW M3X10
d 40013067 SCREW M3X8
e 40128923 HEX NUT M7
f 17048651 VR ACCESSORY WASHER M7
g 17048630 VR ACCESSORY NUT M9
h 40452178 VR WASHER M9
j 40011889 EXTERNAL TOOTH WASHER M4
k 22150756 JACK NUT 2
l 40565489 SCREW M4X25
m 40011756 FLANGE HEX NUT M3
n 40230245 SCREW M4X12
o 40011767 FLANGE HEX NUT M4
p 40010301 SCREW M3X20
q 40347534 WASHER M4
* Attach the No. 10 PCB Spacer from the circuit-board side using KONISHI BOND CYEREX 100 (#40231345).
* Apply KS-64 SILICON GREASE (#40347934) to the No. 11 heat sink and power IC.
Description
SP-18A WITH TERMINAL 100V
SP-20 117V(2P)
181-BG429-BL 117VBL 2.5M
SP-026A 230V(2P)
SP-61 230VE(2P)
SP-501 240V(2P)
SP-18B 115V(2P)
181-BG429-CNLF-220VCN 2.5M
05800-515(SD000043)40A-KBG-10
BLACK #521(40A-1BBG-108)
1702B
40285-021 (only for 220VCN)
100/117V
100/117V (Change a fuse for high voltage.)
PT BG433L 100V/117V
PT BG433H 230V/240V
SDDJE13200 94V-0
SCC-6 94V-0
5ST 500-R 500MA/250V (for low voltage)
5ST 250 (for high voltage)
HEX.BOSS 5.5X15 M3
PAN MACHINE W/SW+SMALL PW BZC
PAN MACHINE W/SW+PW ZC
PAN MACHINE W/SW+SMALL PW ZC
M7X12X0.5 NO.476
FECM
PLASTIC/BLK
PAN MACHINE W/SW BZC
ZC (except for 220VCN)
PAN MACHINE W/SW+PW BZC
FE ZC
BINDING MACHINE BZC
SPRING BZC
CUBE-15XL
