Exploded View (Cabinet) Parts List - Roland CUBE-15XL Service Notes

Sep. 2010

Exploded View (Cabinet) Parts List

No. Part Code Part Name
1 SD000017 BADGE
2 5100016519 GRILLE
3 SD000950 SPEAKER
5100016544 CABINET ASSY
* This unit includes the following parts.
4 ******** CABINET
6 5100015010 CORNER PROTECTOR
7 5100015012 TRIM SASH
8 12359104 RUBBER FOOT
5 SD000035 HANDLE WITH ESCUTHEON
* This unit includes the following parts.
5100011381 HANDLE
5100011382 HANDLE PLATE
5100011383 HANDLE HOLDER
9 ******** CHASSIS ASSY
a 40230789 SCREW 3X10
b 40011689 SPEED NUT M3
c 40010367 SCREW M4X25
d SD000370 PLATE WASHER
e 40010689 SCREW 4X25
f SD000975 SCREW M4X35
g SD000430 PLANE WASHER
h 40564601 SCREW M5X35
i 40010667 SCREW 4X16
j 5100005098 SCREW 3X16
Description
(W0804-431A) 20CM/4OHM
G-5R
Refer to Exploded View (Chassis) (p. 6).
OVAL MACHINE BZC
F-TYPE
BINDING MACHINE BZC
4.2X10X0.5T FEBC
TRUSS TAPPING A FE BZC
ORIGINAL TRUSS BZC
D11 D4.1 T1 BLACK/323-BG-405LF
OVALHEAD MACHINE BZC
TRUSS TAPPING A FE BZC
TRUSS TAPPING A BZC
CUBE-15XL
Q'ty
1
1
1
1
1
4
1
4
1
1
1
2
1
2
2
4
4
7
4
4
2
24
4
5
