Roland CUBE-30 Owner's Manual

Roland cube-30: owners manual
Hide thumbs Also See for CUBE-30:

Advertisement

Table of Contents

Owner's Manual
Thank you, and congratulations on your choice of the Roland CUBE-30 Guitar Amplifier.
Before using this unit, carefully read the sections entitled:
• IMPORTANT SAFETY INSTRUCTIONS (p. 2)
• USING THE UNIT SAFELY (p. 3–4)
• IMPORTANT NOTES (p. 4)
These sections provide important information concerning the proper operation of the
unit. Additionally, in order to feel assured that you have gained a good grasp of every
feature provided by your new unit, Owner's manual should be read in its entirety. The
manual should be saved and kept on hand as a convenient reference.

Main Features

• 30-watt output, high-performance, DSP guitar amp with built-in 25 cm (10-inch)
speaker
• Offers eight different COSM amp types
Amps included:
JC CLEAN, ACOUSTIC, BLACK PANEL, BRITISH COMBO,
TWEED, CLASSIC STACK, METAL STACK,
and R-FIER STACK
Composite Object Sound Modeling (COSM) is Roland's innovative and powerful
sound modeling technology. COSM analyzes the many factors that make up the
original sound, such as the electrical and physical characteristics of the original,
and then produces a digital model that can reproduce the same sound.
• Channel can be switched between "CLEAN" and "LEAD." Channel switching can
be done via foot switch.
• Includes easy-to-use, three-band equalizer (Bass/Middle/Treble)
• Onboard EFX section includes 4 types of digital effect, chorus, flanger, phaser and
tremolo; foot switch (optional) can be used to switch EFX on and off
• Separate "Delay" and "Reverb" effects provided in addition to the EFX
• Equipped with "RECORDING OUT jack" convenient for use in recording and for
use as headphone out
• External input jack allows you to connect a CD player or other backing device
Copyright © 2002 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form
without the written permission of ROLAND CORPORATION.

Advertisement

Table of Contents
loading

Related Manuals for Roland CUBE-30

Summary of Contents for Roland CUBE-30

  • Page 1: Main Features

    Owner’s Manual Thank you, and congratulations on your choice of the Roland CUBE-30 Guitar Amplifier. Before using this unit, carefully read the sections entitled: • IMPORTANT SAFETY INSTRUCTIONS (p. 2) • USING THE UNIT SAFELY (p. 3–4) • IMPORTANT NOTES (p. 4) These sections provide important information concerning the proper operation of the unit.

  • Page 2: Instructions Pertaining To A Risk Of Fire, Electric Shock, Or Injury To Persons

    CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN ATTENTION : RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS.
  • Page 3 • Do not attempt to repair the unit, or replace parts within it (except when this manual provides specific instructions directing you to do so). Refer all servicing to your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” page.

  • Page 4: Important Notes

    (including padding) that it came in, if possible. Otherwise, you will need to use equivalent packaging materials. • Use a cable from Roland to make the connection. If using some other make of connection cable, please note the following precautions.

  • Page 5: Names Of Things And What They Do

    The channel can be switched using the optional BOSS FS-5U foot switch. JC CLEAN Channel This is a model of Roland’s famous JC-120 Jazz Chorus guitar amplifier. The ultra-clean, ultra-flat sound offers a smooth. This becomes more effective when used in combination with a multi effector.

  • Page 6: Power Switch

    Names of Things and What They Do EFX (Effects) 10 . EFX (Effects) Knob Turn this knob to chorus, flanger, phaser, or tremolo to select the corresponding effect. Turn the knob to adjust the amount of effect applied. The ON indicator lights up when EFX is turned on, and goes out when EFX is turned off.

  • Page 7: Main Specifications

    Main Specifications Rated Power Output 30 W Nominal Input Level (@1kHz) INPUT (JC CLEAN channel): -10 dBu/1 MΩ AUX IN: -10 dBu Speaker 25 cm (10 inch) Controls POWER Switch SELECT Switch <JC CLEAN Channel> VOLUME Knob <LEAD Channel> TYPE Switch TYPE (ACOUSTIC, BLACK PANEL, BRIT COMBO, TWEED, CLASSIC STACK, METAL STACK, R-FIER STACK) GAIN Knob VOLUME Knob...

  • Page 8: Australia/New Zealand

    Information When you need repair service, call your nearest Roland Service Center or authorized Roland distributor in your country as shown below. MALAYSIA AFRICA AFRICA BENTLEY MUSIC SDN BHD 140 & 142, Jalan Bukit Bintang EGYPT 55100 Kuala Lumpur, MALAYSIA...
