Location Of Controls; Location Of Controls Parts List - Roland CUBE-15XL Service Notes

Sep. 2010

Location of Controls

fig.panel-15XL.eps

Location of Controls Parts List

No. Part Code Part Name
1 5100016757 ROTARY POTENTIOMETER
* This unit includes the following parts.
17048630 VR ACCESSORY NUT M9
40452178 VR WASHER M9
1 5100004351 R-KNOB
2 5100016756 ROTARY POTENTIOMETER
* This unit includes the following parts.
17048630 VR ACCESSORY NUT M9
40452178 VR WASHER M9
2 5100004351 R-KNOB
3 5100016755 ROTARY POTENTIOMETER
* This unit includes the following parts.
17048630 VR ACCESSORY NUT M9
40452178 VR WASHER M9
3 5100004351 R-KNOB
4 02456390 3.5MM JACK
5 13449252 6.5MM JACK
22150756 JACK NUT 2
6 01348745 SWITCH (PUSH)
22497521R0 PUSH BUTTON
7 13449146 6.5MM JACK
22150756 JACK NUT 2
8 5100016754 ROTARY POTENTIOMETER
* This unit includes the following parts.
17048630 VR ACCESSORY NUT M9
40452178 VR WASHER M9
8 5100004351 R-KNOB
9 03349989 LED (GREEN)
10 03349978 LED (RED)
11 5100016825 SWITCH
* This unit includes the following parts.
40128923 HEX NUT M7
17048651 VR ACCESSORY WASHER M7
11 5100004351 R-KNOB
12 02897801 SEESAW SWITCH
1 2
7 8 9 6 10
Description
RD901F-20E1-15FWA250K-00
05800-515(SD000043)40A-KBG-10
RD901F-20E1-15FW1B20K-00
05800-515(SD000043)40A-KBG-10
RD901F-20E1-15FWB100K-00
05800-515(SD000043)40A-KBG-10
STEREO YKB21-5290
YKB21-5006 (STEREO W/SW)
PLASTIC/BLK
SPUP192700
BLACK #521(40A-1BBG-108)
YKB21-5012 (W/SW)
PLASTIC/BLK
RD901F-20E1-15FW1B10K-00DN6
05800-515(SD000043)40A-KBG-10
L-34GDSL-FPB
L-34HDSL-FPB
SRBM142300
M7X12X0.5 NO.476
05800-515(SD000043)40A-KBG-10
SDDJE13200 94V-0
3 4 5
11 1 8
Q'ty
2
2
2
2
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
2
2
2
2
1
1
1
1
1
1
1
CUBE-15XL
6
12
3
