PART LIST—Model No. PFIVEL87513.0
Item Description
1 Main frame
2 Cap nut M8
3 Arc washer Φ20×d8.5×R30
4 End cap of rear stabilizer
5 Rear stabilizer
6 Carriage bolt M8×74
7 Bushing
8 Pedal tube link
9 Tension cable
10 Nylon nut M10X1.25
11 Cap S17
12 Computer
13 Big washer Φ8.2×Φ32×2
14 Flat washer φ10.5Xφ20X2
15 Square cap
16 Pedal support tube
17 Allen bolt M10X50
18 Pedal
19 Allen bolt M10x45
20 Nylon nut M8
21 Crank
22 Protective guard
23 Hex bolt M8x50
24 Swing tube
25 Nylon nut M10
26 Cap S14
27 Allen bolt M8X15
28 Handrail
29 Carriage bolt M8×45
30 Foam grip of handrail
31 Mushroom end cap
32 Foam grip of handlebar
33 Handlebar
34 Pulse wire
35 End cap
36 Spacer Φ32×59
37 Vertical tube cover
38 Vertical tube
39 Hex pan head screw M8x20
40 Upper sensor wire
41 Sensor wire
42 Cross tapping screw ST4.2X18
43 Front stabilizer
44 End cap of front stabilizer
45 Flat washer Φ10.5×Φ32×2
46 Flat washer D5
Qty. Item Description
1 47 Cross pan head screw M4X12
12 48 Cross pan head screw M8x38
10 49 Arc washer Φ20×d8.5×R12.5
2 50 Cross pan head screw M5X55
1 51 Arc washer D5
4 52 Tension controller
8 53 Wave washer
2 54 Bushing
2 55 Conical surface spacer
2 56 U shape washer
6 57 Hex nut M6
1 58 Hex bolt M5x60
2 59 Hex nut M5
8 60 Sensor
4 61 Cap
2 62 Cross tapping screw ST2.9X12
2 63 Spacer Φ21×Φ25×4
1 64 Allen bolt M6X16
4 65 Spring washer D6
2 66 Spring washer D12
2 67 Magnet board axle
2 68 Magnet board
2 69 Tension spring
1 70 Magnet
7 71 Bearing 6904RS
4 72 Chain cover
2 73 Spring washer D20
1 74 Belt pulley
4 75 Middle axle
2 76 Flywheel spacer
2 77 Nylon nut M6
1 78 Conical surface nut M10X1.25
1 79 Flange nut M10X1.25
2 80 Allen bolt M10X40
2 81 Flat washer D6
2 82 Idler wheel
1 83 Belt
1 84 Disk cover
6 85 Flange nut M10X1.0
1 86 Adjustable screw
1 87 Nut M10X1.0
35 88 Bearing 6001Z
1 89 Flywheel
2 90 Conical surface spacer
2 91 Flywheel axle
2 92 Disk
93 SpacerΦ32×Φ26
15
Qty.
2
4
12
1
1
2
2
2
1
2
2
1
2
1
1
2
1
6
6
2
1
1
1
5
2
1
1
1
1
1
4
1
2
1
2
1
1
2
2
2
2
2
1
1
1
2
