1 Overview

This Administrator Guide is for the SIP 1.4.0 software release, and the bootROM 2.6.0
release.
SoundPoint
nications terminals for Ethernet TCP/IP networks. They are designed to facilitate
high-quality audio and text message communications. These phones are endpoints in
the overall network topology designed to interoperate with other compatible equip-
ment including application servers, media servers, internetworking gateways, voice
bridges, and other endpoints.
10/100
Ethernet
Switch
PC
PC
The phones connect physically to a standard office twisted-pair (IEEE 802.3) 10/100
