Texas Instruments MSP430F663x Manual

www.ti.com
FEATURES
1
• Low Supply Voltage Range: 1.8 V to 3.6 V
2
• Ultralow Power Consumption
– Active Mode (AM):
All System Clocks Active:
270 µA/MHz at 8 MHz, 3.0 V, Flash Program
Execution (Typical)
– Standby Mode (LPM3):
Watchdog With Crystal, and Supply
Supervisor Operational, Full RAM
Retention, Fast Wake-Up:
1.8 µA at 2.2 V, 2.1 µA at 3.0 V (Typical)
– Shutdown RTC Mode (LPM3.5):
Shutdown Mode, Active Real-Time Clock
With Crystal:
1.1 µA at 3.0 V (Typical)
– Shutdown Mode (LPM4.5):
0.3 µA at 3.0 V (Typical)
• Wake-Up From Standby Mode in 3 µs (Typical)
• 16-Bit RISC Architecture, Extended Memory,
up to 20-MHz System Clock
• Flexible Power Management System
– Fully Integrated LDO With Programmable
Regulated Core Supply Voltage
– Supply Voltage Supervision, Monitoring,
and Brownout
• Unified Clock System
– FLL Control Loop for Frequency
Stabilization
– Low-Power Low-Frequency Internal Clock
Source (VLO)
– Low-Frequency Trimmed Internal Reference
Source (REFO)
– 32-kHz Crystals (XT1)
– High-Frequency Crystals Up to 32 MHz
(XT2)
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
All trademarks are the property of their respective owners.
2
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
MIXED SIGNAL MICROCONTROLLER
SLAS566C – JUNE 2010 – REVISED AUGUST 2012
• Four 16-Bit Timer With 3, 5, or 7
Capture/Compare Registers
• Two Universal Serial Communication
Interfaces
– USCI_A0 and USCI_A1 Each Support:
– Enhanced UART Supports Auto-
Baudrate Detection
– IrDA Encoder and Decoder
– Synchronous SPI
– USCI_B0 and USCI_B1 Each Support:
2 TM
– I C
– Synchronous SPI
• Full-Speed Universal Serial Bus (USB)
– Integrated USB-PHY
– Integrated 3.3-V and 1.8-V USB Power
System
– Integrated USB-PLL
– Eight Input and Eight Output Endpoints
• 12-Bit Analog-to-Digital (A/D) Converter With
Internal Shared Reference, Sample-and-Hold,
and Autoscan Feature
• Dual 12-Bit Digital-to-Analog (D/A) Converters
With Synchronization
• Voltage Comparator
• Integrated LCD Driver With Contrast Control
for up to 160 Segments
• Hardware Multiplier Supporting 32-Bit
Operations
• Serial Onboard Programming, No External
Programming Voltage Needed
• Six-Channel Internal DMA
• Real-Time Clock Module With Supply Voltage
Backup Switch
• Family Members are Summarized in
• For Complete Module Descriptions, See the
MSP430x5xx and MSP430x6xx Family User's
Guide (SLAU208)
Copyright © 2010–2012, Texas Instruments Incorporated
MSP430F663x
Table 1
