USER INSTRUCTIONS AND SAFETY
Congratulations on your purchase of an N-Com product.
N-Com B901L was made using the most advanced technologies and the best
materials. Long-running tests and thorough system development have allowed
the highest audio quality to be achieved.
For additional information about B901L, and to download high-definition
instructions as well as the latest Firmware version, visit the website www.n-com.it
Firmware version: 1.1
REFERENCE STANDARDS
The products of the N-Com line are in compliance with standards as per the table below:
B901L
Battery
charger
Battery
The Declarations of Compliance can be downloaded from the website www.n-com.it (Download
section).
FCC ID: Y6MNCOM15
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth
SIG, Inc. and any use of such marks by N-Com is under license. Other trademarks and
trade names are those of their respective owners.
The Bluetooth system complies with the main safety requirements and
other applicable provisions of Directive 99/5/CE, Directive 2009/65/EC,
Directive 2011/65/CE, Directive 2012/19/EU
Directive 2006/95, 2004/108, 2009/65/EC, 2011/65/EC, 2012/19/EU,
2009/125/CE
Directive 2006/66/CE
IC: 9455A-NCOM15
R-NZ
B901L "R" - Fw 1.1x-1 - 06/10/2017
