Available settings are explained as follows:
Item
Enable
Server IP Address
Destination Port
Shared Secret
Confirm Shared Secret
After finished the above settings, click OK button to save the settings.
4 . 9 . 5 U P n P
4 . 9 . 5 U P n P
The UPnP (Universal Plug and Play) protocol is supported to bring to network connected
devices the ease of installation and configuration which is already available for directly
connected PC peripherals with the existing Windows 'Plug and Play' system. For NAT routers,
the major feature of UPnP on the router is "NAT Traversal". This enables applications inside
the firewall to automatically open the ports that they need to pass through a router.
Note: UPnP is required for some applications such as PPS, Skype, eMule...and etc. If you
are not familiar with UPnP, it is suggested to turn off this function for security.
Description
Check to enable RADIUS client feature.
Type the IP address of RADIUS server
The UDP port number that the RADIUS server is using. The
default value is 1812, based on RFC 2138.
The RADIUS server and client share a secret that is used to
authenticate the messages sent between them. Both sides must
be configured to use the same shared secret.
Re-type the Shared Secret for confirmation.
257
Vigor2120 Series User's Guide
