S
UPER
®
SC847BE1C/2C
CHASSIS SERIES
SC847BE1C-R1K28LPB
SC847BE2C-R1K28LPB
SC847BE1C-R1K28WB
SC847BE2C-R1K28WB
USER'S MANUAL
1.0a

Advertisement

Table of Contents
loading

Related Manuals for Supero SC847BE1C series

Summary of Contents for Supero SC847BE1C series

  • Page 1 UPER ® SC847BE1C/2C CHASSIS SERIES SC847BE1C-R1K28LPB SC847BE2C-R1K28LPB SC847BE1C-R1K28WB SC847BE2C-R1K28WB USER’S MANUAL 1.0a...
  • Page 2 SC847BE1C/2C Chassis Manual The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.

  • Page 3: Contacting Supermicro

    Preface Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...
  • Page 4 SC847BE1C/2C Chassis Manual Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SC847BEC1/C2 chassis. Installation and maintenance should be performed by experienced technicians only. This manual lists compatible parts available when this document was published.

  • Page 5: Manual Organization

    Preface Manual Organization Chapter 1: Introduction The irst chapter provides a checklist of the main components included with this chassis and describes the main features of the SC847BEC1/C2 chassis. This chapter also includes contact information. Chapter 2: Standardized Warning Statements for AC/DC Systems This chapter lists warnings, precautions, and system safety.
  • Page 6 SC847BE1C/2C Chassis Manual Appendix A: Cables and Hardware This section provides information on cabling, and other hardware which is compat- ible with your chassis. For complete information on supported cables and hardware, refer to the Supermico website at www.supermicro.com. Appendix B: Power Supply Speciications This chapter lists the speciications of the power supply provided with your chas- sis.

  • Page 7: Table Of Contents

    Preface Table of Contents Contacting Supermicro ..................iii Chapter 1 Introduction Overview ......................1-1 Shipping List ....................1-1 Where to get Replacement Components ............1-2 Returning Merchandise for Service..............1-3 Chapter 2 Standardized Warning Statements for AC/DC Systems About Standardized Warning Statements ............2-1 Warning Deinition ...................
  • Page 8 SC847BE1C/2C Chassis Manual Permanent and Optional Standoffs ..............4-8 Expansion Card Setup .................. 4-10 Installing Expansion Cards ................4-10 Removing and Installing the Backplanes ............4-11 Air Shroud Modiication and Installation ............4-15 Air Shroud Installation ................... 4-15 System Fans ....................4-18 4-10 Power Supply ....................

  • Page 9: Chapter 1 Introduction

    Chapter 1: Introduction Chapter 1 Introduction Overview Optimized for enterprise-level heavy-capacity storage applications, Supermicro's SC847BE1C/2C chassis features up to 36x (24 front + 12 rear) 3.5" hot-swap HDD bays SAS/SATA drive bays supporting SAS3/2 or SATA3 HDDs with 12 Gbps throughput.

  • Page 10: Where To Get Replacement Components

    SC847BE1C/2C Chassis Manual Where to get Replacement Components Though not frequently, you may need replacement parts for your system. To en- sure the highest level of professional service and technical support, we strongly recommend purchasing exclusively from our Supermicro Authorized Distributors/ System Integrators/Resellers.

  • Page 11: Returning Merchandise For Service

    Chapter 1: Introduction Returning Merchandise for Service A receipt or copy of your invoice marked with the date of purchase is required be- fore any warranty service will be rendered. You can obtain service by calling your vendor for a Returned Merchandise Authorization (RMA) number. When returning to the manufacturer, the RMA number should be prominently displayed on the outside of the shipping carton, and mailed prepaid or hand-carried.
  • Page 12 SC847BE1C/2C Chassis Manual Notes...

  • Page 13: Chapter 2 Standardized Warning Statements For Ac/Dc Systems

    Chapter 2: Warning Statements for AC/DC Systems Chapter 2 Standardized Warning Statements for AC/DC Systems About Standardized Warning Statements The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance.
  • Page 14 SC847BE1C/2C Chassis Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie beinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 15 Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬ ‫ل‬ ‫الىقائٍة‬...

  • Page 16: Installation Instructions

    SC847BE1C/2C Chassis Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 17: Circuit Breaker

    Chapter 2: Warning Statements for AC/DC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 60VDC, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が60VDC、...

  • Page 18: Power Disconnection Warning

    SC847BE1C/2C Chassis Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 60V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 60V, 20A.
  • Page 19 Chapter 2: Warning Statements for AC/DC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 20: Equipment Installation

    SC847BE1C/2C Chassis Manual Equipment Installation Warning! Only trained and qualiied personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualiiziertem Personal gestattet werden.

  • Page 21: Restricted Area

    Chapter 2: Warning Statements for AC/DC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwaliiceerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 22: Battery Handling

    SC847BE1C/2C Chassis Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خال استخذاو‬ ‫فقط‬ ‫محظورة‬...
  • Page 23 Chapter 2: Warning Statements for AC/DC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 24: Redundant Power Supplies

    SC847BE1C/2C Chassis Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 25: Backplane Voltage

    Chapter 2: Warning Statements for AC/DC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاات‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة ااتصاات‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 26: Comply With Local And National Electrical Codes

    SC847BE1C/2C Chassis Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬ 경고! 시스템이...

  • Page 27: Product Disposal

    Chapter 2: Warning Statements for AC/DC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬...

  • Page 28: Hot Swap Fan Warning

    SC847BE1C/2C Chassis Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 29 Chapter 2: Warning Statements for AC/DC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 30: Dc Power Supply

    SC847BE1C/2C Chassis Manual DC Power Supply Warning! When stranded wiring is required, use approved wiring terminations, such as closedloop or spade-type with upturned lugs. These terminations should be the appropriate size for the wires and should clamp both the insulation and conductor. 警告...
  • Page 31 Chapter 2: Warning Statements for AC/DC Systems Attention Quand des fils torsadés sont nécessaires, utiliser des douilles terminales homologuées telles que celles à circuit fermé ou du type à plage ouverte avec cosses rebroussées. Ces douilles terminales doivent être de la taille qui convient aux ils et doivent être refermées sur la gaine isolante et sur le conducteur.

  • Page 32: Dc Power Disconnection

    SC847BE1C/2C Chassis Manual DC Power Disconnection Warning! Before performing any of the following procedures, ensure that power is removed from the DC circuit. 警告 次の手順を開始する前に、 DC回路から電源が切断されているこ とを確認してく ださい。 警告 進行以下任一操作程序前，請確保直流電路已斷電。 警告 请在进行以下任一操作程序前，确保直流电路的电源已经断开。 Warnung Vor Ausführung der folgenden Vorgänge ist sicherzustellen, daß die Gleichstromschaltung keinen Strom erhält.

  • Page 33: Hazardous Voltage Or Energy Present On Dc Power Terminals

    Chapter 2: Warning Statements for AC/DC Systems 주의! 다음 절차들을 수행하기 전에, 전원이 DC회로로부터 제거되었는지를 확인해 주십시오. Waarshuwing Wanneer geslagen bedrading vereist is, dient u bedrading te gebruiken die voorzien is van goedgekeurde aansluitingspunten, zoals het gesloten-lus type of het grijperschop type waarbij de aansluitpunten omhoog wijzen.
  • Page 34 SC847BE1C/2C Chassis Manual ¡Advertencia! Puede haber energía o voltaje peligrosos en los terminales eléctricos de CC. Reemplace siempre la cubierta cuando no estén utilizándose los terminales. Asegúrese de que no haya acceso a conductores descubiertos cuando la cubierta esté colocada. Attention Le voltage ou l'énergie électrique des terminaux à...

  • Page 35: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of speciic components.

  • Page 36: Control Panel Buttons

    SC847E1C/2C JBOD Chassis Manual Control Panel Buttons There are two push-buttons located on the left handle of the chassis. These are (in order from top to bottom) a power on/off button and a reset button. Power: The main power button is used to apply or remove power from the power supply to the server system.
  • Page 37 Chapter 3: System Interface NIC1: Indicates network activity on GLAN1 when lashing. NIC2: Indicates network activity on GLAN2 when lashing. Overheat/Fan Fail: When this LED lashes, it indicates a fan failure. When con- tinuously on (not lashing) it indicates an overheat condition, which may be caused by cables obstructing the airlow in the system or the ambient room temperature being too warm.

  • Page 38: Drive Carrier Leds

    SC847E1C/2C JBOD Chassis Manual Drive Carrier LEDs Your chassis uses SAS/SATA. SAS/SATA Drives Each SAS/SATA drive carrier has two LEDs. • Blue: Solid on = Drive is present and available. Blinking = Drive is actively being accessed. Each Serial ATA drive carrier has a blue LED. When illuminated in a solid on state, this blue LED (on the front of the SAS/SATA drive carrier) indicates drive activity.

  • Page 39: Chapter 4 Chassis Setup And Maintenance

    Chapter 4: Chassis Setup and Maintenance Chapter 4 Chassis Setup and Maintenance Overview This chapter covers the steps required to install components and perform mainte- nance on the chassis. The only tool you will need to install components and perform maintenance is a Phillips screwdriver.

  • Page 40: Removing The Chassis Cover

    SC847BE1C/2C Chassis Manual Removing the Chassis Cover Figure 4-1: Removing the Chassis Cover Removing the Chassis Cover 1. Power down the system and remove the power cords from the rear of the power supplies. 2. Remove the screws securing the cover to the chassis. 3.

  • Page 41: Hard Drives

    Chapter 4: Chassis Setup and Maintenance 3.5" Hard Drives Figure 4-2: Removing a Hard Drive Carrier The SC847BE1C/2C chassis has hot-swappable 3.5" hard drives which may be removed from the chassis without powering down the system. Removing Hard Drive Carriers from the Chassis 1.
  • Page 42 SC847BE1C/2C Chassis Manual Dummy Drive Drive Carrier Figure 4-3: Chassis Drive Carrier The drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help to promote proper airlow for the drive bays. Warning: Except for short periods of time (while swapping hard drives), do not operate the server with the drives removed from the chassis drive bays.
  • Page 43 Chapter 4: Chassis Setup and Maintenance 3.5" SAS/SATA Hard Drive Drive Carrier Figure 4-5: Installing the Hard Drive into the Carrier 2. Slide the hard drive into the carrier with the printed circuit board side facing down. 3. Carefully align the mounting holes in both the drive carrier and the hard drive. 4.

  • Page 44: Hard Drives And The Rear Hard Drive Cage

    SC847BE1C/2C Chassis Manual 2.5" Hard Drives and the Rear Hard Drive Cage SC847BE1C/2C-R1K28LPB SC847BE1C/2C-R1K28WB Figure 4-7: Installing the 2.5" Hard Drive Cage The SC847BE1C/2C chassis comes with a rear hard drive cage which supports two 2.5" hard drives. The 2.5" hard drives are hot-swappable and may be removed from the chassis without powering down the system.
  • Page 45 Chapter 4: Chassis Setup and Maintenance Dummy Drive Drive Carrier Figure 4-9: Removing a Dummy Drive From a Carrier Installing 2.5" Hard Drives into Carriers 1. Remove the four screws securing the dummy drive from the drive carrier and set them aside for later use. 2.

  • Page 46: Installing The Motherboard

    SC847BE1C/2C Chassis Manual Installing the Motherboard Permanent and Optional Standoffs Standoffs prevent short circuits by securing space between the motherboard and the chassis surface. The SC847 chassis includes permanent standoffs in locations used by most motherboards. These standoffs accept the rounded Phillips head screws included in the SC847 accessories packaging.
  • Page 47 Chapter 4: Chassis Setup and Maintenance Figure 4-12: Installing the Motherboard 4. Lay the motherboard on the tray aligning the permanent and optional stand- offs. 5. Secure the motherboard to the tray using the rounded, Phillips head screws. Do not exceed eight inch-pounds of torque. 6.

  • Page 48: Expansion Card Setup

    SC847BE1C/2C Chassis Manual Expansion Card Setup The chassis includes PCI slots for expansion cards. The SC847BE1C/2C features seven low-proile PCI slots. PCI Slots Figure 4-13: Removing the PCI Slot Cover Installing Expansion Cards Installing Expansion Cards into the Chassis 1. Power down the system as described in Section 4-2, lay the chassis on a lat surface, and open the chassis cover.

  • Page 49: Removing And Installing The Backplanes

    Chapter 4: Chassis Setup and Maintenance Removing and Installing the Backplanes The SC847BE1C/2C chassis comes equipped with a BPN-SAS3-846EL1/EL2 front backplane and a BPN-SAS3-826EL1/EL2 rear backplane. For detailed infomation and instructions on how to change the backplane settings, see Appendices C, D and E of this manual.
  • Page 50 SC847BE1C/2C Chassis Manual Removing the Rear Backplane 1. Power down the system and remove the power cords from the rear of the power supplies. Remove the chassis cover as described in Section 4-2. 2. Remove the two side screws (one on each side of the chassis) which secure the rear tray to the chassis.
  • Page 51 Chapter 4: Chassis Setup and Maintenance Installing the Front Backplane 1. Conirm that the power cords are still disconnected from the power supplies. 2. Place the front backplane in the chassis. SC847BE1C/2C-R1K28LPB SC847BE1C/2C-R1K28WB Figure 4-15: Installing the Front Backplane 3. Install the two side screws to secure the front backplane to the chassis. 4.
  • Page 52 SC847BE1C/2C Chassis Manual Installing the Rear Backplane 1. Conirm that the power cords are still disconnected from the power supplies. 2. Slide the rear tray out of the back of the chassis. SC847BE1C/2C-R1K28LPB SC847BE1C/2C-R1K28WB Figure 4-17: Installing the Rear Backplane 3.

  • Page 53: Air Shroud Modiication And Installation

    Chapter 4: Chassis Setup and Maintenance Air Shroud Modiication and Installation Air Shroud Installation The SC847BE1C/2C chassis comes with an air shroud which may be modiied to it over the top of a number of different motherboards. Use the chart and illustration below to set up the air shroud for your particular motherboard.
  • Page 54 SC847BE1C/2C Chassis Manual Figure 4-20: Installing the Air Shroud Air shrouds concentrate airlow to maximize fan effectiveness. The SC847 chas- sis air shroud does not require screws for its installation. The SC847 air shroud is designed with removeable break-away tabs that allow the air shroud to be adjusted to it a variety of motherboards.
  • Page 55 Chapter 4: Chassis Setup and Maintenance Checking the Airlow • Make sure there are no objects to obstruct airlow in and out of the server. In addition, if you are using a front bezel, make sure the bezel's ilter is replaced periodically.

  • Page 56: System Fans

    SC847BE1C/2C Chassis Manual System Fans Seven hot-swappable, heavy-duty fans provide cooling for the chassis. These fans circulate air through the chassis thereby lowering the chassis internal tempera- ture. Release Tab Air Direction Indicator Figure 4-21: System Fan Replacing a System Fan 1.
  • Page 57 Chapter 4: Chassis Setup and Maintenance Figure 4-22: Placing the System Fan 4-19...

  • Page 58: 4-10 Power Supply

    SC847BE1C/2C Chassis Manual 4-10 Power Supply The SC847BE1C/2C chassis has a 1280 Watt high-eficiency redundant power sup- ply. This power supply is auto-switching capable. This enables it to automatically sense and operate at a 100v to 240v input voltage. An amber light will be illuminated on the power supply when the power is off.
  • Page 59 Chapter 4: Chassis Setup and Maintenance Figure 4-24: Power Supply Release Tab 4. Replace the failed power module with the same model. 5. Push the new power supply module into the power bay until you hear a click. 6. If using only one power supply, plug the AC power cord back into the module and power up the server.
  • Page 60 SC847BE1C/2C Chassis Manual Notes 4-22...

  • Page 61: Chapter 5 Rack Installation

    Chapter 5: Rack Installation Chapter 5 Rack Installation Overview This chapter provides a quick setup checklist to get your chassis up and running. Following these steps in the order given should enable you to have the system operational within a minimal amount of time. Unpacking the System You should inspect the box which the chassis was shipped in and note if it was damaged in any way.

  • Page 62: Warnings And Precautions

    SC847BE1C/2C Chassis Manual Warnings and Precautions Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are fully extended to the loor with the full weight of the rack resting on them. • In single rack installations, stabilizers should be attached to the rack. •...

  • Page 63: Rack Mounting Considerations

    Chapter 5: Rack Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (TMRA).

  • Page 64: Rack Mounting Instructions

    SC847BE1C/2C Chassis Manual Rack Mounting Instructions This section provides information on installing the chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean that the assembly procedure will differ slightly from the instructions provided. You should also refer to the installation instructions that came with the rack unit you are using.

  • Page 65: Locking Tabs

    Chapter 5: Rack Installation Locking Tabs Each inner rail has a locking tab. This tab locks the chassis into place when installed and pushed fully into the rack. These tabs also lock the chassis in place when fully extended from the rack. This prevents the server from coming completely out of the rack when when the chassis is pulled out for servicing.

  • Page 66: Installing The Inner Rails On The Chassis

    SC847BE1C/2C Chassis Manual Inner Rails Figure 5-3: Installing the Inner Rails Figure 5-4: Inner Rails Installed on the Chassis Installing The Inner Rails on the Chassis Installing the Inner Rails 1. Conirm that the left and right inner rails have been correctly identiied. Place the inner rail irmly against the side of the chassis, aligning the hooks on the side of the chassis with the holes in the inner rail.

  • Page 67: Installing The Outer Rails On The Rack

    Chapter 5: Rack Installation Figure 5-5: Extending and Releasing the Outer Rails Installing the Outer Rails on the Rack Installing the Outer Rails 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3.

  • Page 68: Standard Chassis Installation

    SC847BE1C/2C Chassis Manual Ball-Bearing Shuttle Figure 5-6: Installing into a Rack Note: igures are for illustrative purposes only. Always install servers into racks from the bottom up. Standard Chassis Installation Installing the Chassis into a Rack 1. Conirm that the inner rails are properly installed on the chassis. 2.

  • Page 69: Optional Quick Installation Method

    Chapter 5: Rack Installation Optional Quick Installation Method The following quick installation method may be used to install the chassis onto a rack. Installing the Chassis into a Rack 1. Install the whole rail assembly onto the rack as described on page X-7. 2.
  • Page 70 SC847BE1C/2C Chassis Manual Notes 5-10...

  • Page 71: Appendix A Sc847Be1C/2C Cables And Hardware

    Appendix A: Chassis Cables Appendix A SC847BE1C/2C Cables and Hardware A-1 Overview This appendix lists supported cables for your chassis system. It only includes the most commonly used components and conigurations. For more compatible cables, refer to the manufacturer of the motherboard you are using and our Web site at: www.supermicro.com.
  • Page 72 SC847BE1C/2C Chassis Manual A-3 Compatible Cables These cables are compatible with the SC847E1C/2C JBOD chassis. Alternate SAS/SATA Cables Some compatible motherboards have different connectors. If your motherboard has only one SAS connector that the SAS/SATA cables must share, use one of the following cables.

  • Page 73: Extending Power Cables

    Appendix A: Chassis Cables Extending Power Cables Although Supermicro chassis are designed with to be eficient and cost-effective, some compatible motherboards have power connectors located in different areas. To use these motherboards you may have to extend the power cables to the mother boards.
  • Page 74 SC847BE1C/2C Chassis Manual A-4 Chassis Screws The accessory box includes all the screws needed to set up your chassis. This section lists and describes the most common screws used. Your chassis may not require all the parts listed. HARD DRIVE Flat head Pan head 6-32 x 5 mm...

  • Page 75: Appendix B Sc847Be1C/2C Power Supply Speciications

    Appendix B: Power Supply Speciications Appendix B SC847BE1C/2C Power Supply Speciications This appendix lists power supply speciications for your chassis system. SC847BE1C/2C-R1K28LPB, SC847BE1C/2C-R1K28WB, 1280W MFR Part # PWS-1K28P-SQ 1000W Output @ 100-140V, 12-8A, 50-60Hz AC Input 1280W Output @ 180-240V, 8-6A, 50-60Hz 1000W: +12V/83A;...
  • Page 76 SC847BE1C/2C Chassis Manual Notes...

  • Page 77: Appendix C Bpn-Sas3-846El Front Backplane Speciications

    Appendix C: BPN-SAS3-846EL Backplane Speciications Appendix C BPN-SAS3-846EL Front Backplane Speciications To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. C-1 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system, it is important to handle it very carefully.
  • Page 78 SC947BE1C/2C Chassis Manual C-3 An Important Note to Users All images and layouts shown in this user's guide are based upon the latest back- plane revision available at the time of publishing. The card you have received may or may not look exactly the same as the graphics shown in this manual. C-4 Introduction to the BPN-SAS3-846EL Backplane The BPN-SAS3-846EL backplane has been designed to utilize the most up-to-date technology available, providing your system with reliable, high-quality performance.
  • Page 79 Appendix C: BPN-SAS3-846EL Backplane Speciications C-6 Front Connectors MH14 MH15 Q866 EXP I2C4 Q872 EXP I2C0 MH13 Q871 MH16 Q870 LED Testing Only ACTLED 12V_LED1 P_UART Q873 S_SDB BC57 Q867 BC29 Q869 C177 BC10 P_MDIO P_SDB MH17 S_MDIO C165 C107 OVERHEATFAIL1 C233 C236 C206...
  • Page 80 SC847BE1C/2C Chassis Manual C-7 Front Connector and Pin Deinitions 1. - 2. Primary and Secondary Expander Chips The primary and secondary expander chips allow the backplane to support dual port, cas- cading, and failover conigurations. 3. Backplane Power Connectors Backplane Main Power The 4-pin connectors, designated PWR1 - 4-Pin Connector...
  • Page 81 Appendix C: BPN-SAS3-846EL Backplane Speciications C-8 Front Jumper Locations and Settings LED Testing Only ACTLED MH14 MH15 Q866 EXP I2C4 Q872 EXP I2C0 MH13 Q871 LED Testing Only MH16 Q870 ACTLED 12V_LED1 P_UART Q873 S_SDB BC29 BC57 Q867 Q869 C177 BC10 P_MDIO P_SDB...
  • Page 82 SC847BE1C/2C Chassis Manual C-9 Front LED Indicators 12V_LED1 MH14 MH15 Q866 EXP I2C4 MH13 Q872 MH16 EXP I2C0 Q871 LED Testing Only Q870 ACTLED 12V_LED1 P_UART Q873 S_SDB 5V_LED2 Q867 BC29 BC57 Q869 C177 BC10 P_MDIO P_SDB 12V_LED2 MH17 S_MDIO C165 C107 OVERHEATFAIL1 C233 C236...
  • Page 83 Appendix C: BPN-SAS3-846EL Backplane Speciications C-10 Rear Connectors and LED Indicators ACT23 ACT5 ACT17 ACT11 ACT23 FAIL5 FAIL23 FAIL17 FAIL11 SAS #11 SAS #5 SAS #23 SAS #17 ACT22 ACT4 ACT16 ACT10 FAIL4 FAIL22 FAIL16 FAIL10 SAS #10 SAS #22 SAS #4 SAS #16 ACT3...
  • Page 84 SC847BE1C/2C Chassis Manual Rear LED Indicators Rear LED Hard Drive Activity Failure LED SAS #0 ACT0 FAIL0 SAS #1 ACT1 FAIL1 SAS #2 ACT 2 FAIL2 SAS #3 ACT3 FAIL3 SAS #4 ACT4 FAIL4 SAS #5 ACT5 FAIL5 SAS #6 ACT6 FAIL6 SAS #7...
  • Page 85 Appendix C: BPN-SAS3-846EL Backplane Speciications C-11 Single and Dual Port Expanders SAS primary connectors J49 to J50 and secondary connectors J51 to J52 are bidirectional and can be treated as input or output. Single Ports BPN-SAS3-846EL1 backplanes have a single port expander that accesses all of the drives and supports cascading.
  • Page 86 SC847BE1C/2C Chassis Manual C-12 Failover The BPN-SAS3-846EL2 model backplane has two expanders which enable effec- tive failover and recovery. Single Host Bus Adapter In a single host bus coniguration, the backplane connects to one host bus adapter. SAS HBA MH14 MH15 Q866 EXP I2C4...
  • Page 87 Appendix C: BPN-SAS3-846EL Backplane Speciications C-13 Failover with RAID Cards and Multiple HBAs The BPN-SAS3-846EL backplane may be conigured for failover with multiple HBAs using either RAID controllers or HBAs to acheive failover protection. RAID Controllers: If RAID controllers are used, then the failover is accomplished through port failover on the same RAID card.
  • Page 88 SC847BE1C/2C Chassis Manual C-14 Connecting HBAs to the Backplane Connecting an Internal HBA to the Backplane The following section lists the most common cables used to connect the HBA to the backplane. MH14 MH15 Q866 EXP I2C4 Q872 EXP I2C0 MH13 Q871 LED Testing Only...
  • Page 89 Appendix C: BPN-SAS3-846EL Backplane Speciications Cable Name: Internal iPass (Mini-SAS) to HD (Mini-SAS) Part #: CBL-SAST-0508-01 Length: 50 cm (19 inches) Part #: CBL-SAST-0507-01 Length: 80 cm (31 inches) Description: This cable has an iPass (SFF-8087/Mini-SAS) connector (36-pin) at one end and a Mini-SAS HD (SFF-8643) connector at the other end.
  • Page 90 SC847BE1C/2C Chassis Manual Connecting an External HBA to the Backplane This backplane supports external host bus adapters. In this coniguration, the HBA and the backplane are in different physical chassis. This allows a JBOD (Just a Bunch Of Drives) coniguration from an existing system. Single External Host Bus Adapter MH14 MH15...
  • Page 91 Appendix C: BPN-SAS3-846EL Backplane Speciications Connecting Multiple Backplanes in a Single Channel Environment This section describes the cables used when cascading from a single HBA. These connections use CBL-SAST-0531 internal cables and CBL-SAST-0573 external cables. CBL-SAST-0531 Internal Cable MH14 MH15 Q866 EXP I2C4 EXP I2C0...
  • Page 92 SC847BE1C/2C Chassis Manual Single HBA Coniguration Cables Figure C-15: External Mini-SAS HD to External Mini-SAS HD Cable Cable Name: 1 Meter External Mini-SAS HD to External Mini-SAS HD Cable Part #: CBL-SAST-0573 Ports: Single Placement: External Cable Description: External cascading cable, connects ports between servers and JBODs. Figure C-16: Mini-SAS HD Internal to External Adapter Cable Name: 16-port Mini-SAS HD Internal to External Cable Adapter with LP Bracket...
  • Page 93 Appendix C: BPN-SAS3-846EL Backplane Speciications Connecting Multiple Backplanes in a Dual Channel Environment This section describes the cables used when cascading from dual HBAs. These con- nections use CBL-SAST-0531 internal cables and CBL-SAST-0573 external cables. MH14 MH15 Q866 EXP I2C4 Q872 EXP I2C0 MH13...
  • Page 94 SC847BE1C/2C Chassis Manual Disclaimer (cont.) The products sold by Supermicro are not intended for and will not be used in life sup- port systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to per- form be reasonably expected to result in signiicant injury or loss of life or catastrophic property damage.

  • Page 95: Appendix D Bpn-Sas3-826El Backplane Speciications

    Appendix D: BPN-SAS3-826EL Backplane Speciications Appendix D BPN-SAS3-826EL Backplane Speciications To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. D-1 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system, it is important to handle it very carefully.
  • Page 96 SC847BE1C/2C Chassis Manual D-3 An Important Note to Users All images and layouts shown in this user's guide are based upon the latest back- plane revision available at the time of publishing. The card you have received may or may not look exactly the same as the graphics shown in this manual. D-4 Introduction to the BPN-SAS3-826EL Backplane The BPN-SAS3-826EL backplane has been designed to utilize the most up-to-date technology available, providing your system with reliable, high-quality performance.
  • Page 97 Appendix D: BPN-SAS3-826EL Backplane Speciications D-6 Front Connectors LED28 HB-LED PRI-SDB LED29 C502 I2C#4 I2C#0 DESIGNED IN USA LED25 LED26 BPN-SAS3-826EL1 SEC-UART PRI-UART C496 C497 SAS CODE SEC-SDB REV:1.00 SAS CODE C501 C495 ACT-LED SECONDARY EXPANDER C494 C492 C498 TEST C499 PRIMARY EXPANDER JPW3...
  • Page 98 SC847BE1C/2C Chassis Manual D-7 Front Connector and Pin Deinitions 1. - 2. Primary and Secondary Expander Chips The primary and secondary expander chips allow the backplane to support dual port, cas- cading, and failover conigurations. 3. Backplane Main Power Connectors Backplane Main Power The 4-pin connectors, designated JPW1,...
  • Page 99 Appendix D: BPN-SAS3-826EL Backplane Speciications D-8 Front Jumper Location and Settings LED28 HB-LED PRI-SDB LED29 C502 I2C#4 DESIGNED IN USA I2C#0 LED25 LED26 BPN-SAS3-826EL1 SEC-UART PRI-UART C496 C497 SAS CODE SEC-SDB REV:1.00 SAS CODE C501 C495 ACT-LED SECONDARY EXPANDER C494 C492 C498 TEST...
  • Page 100 SC847BE1C/2C Chassis Manual D-9 Front LED Indicators HB-LED HB-LED (J28) LED27 (J29) LED28 HB-LED PRI-SDB LED29 C502 I2C#4 DESIGNED IN USA I2C#0 LED25 LED26 BPN-SAS3-826EL1 SEC-UART PRI-UART C496 C497 SAS CODE SEC-SDB REV:1.00 SAS CODE C501 C495 ACT-LED SECONDARY EXPANDER C494 C492 C498...
  • Page 101 Appendix D: BPN-SAS3-826EL Backplane Speciications D-10 Rear Connectors and LED Indicators LED3 LED6 LED9 LED12 LED15 LED18 LED21 LED24 C581 DRV#12 DRV#6 DRV#9 DRV#3 DRV#12 DRV#6 DRV#3 DRV#9 C173 C172 C171 C170 LED5 LED8 LED2 LED11 C158 C159 C161 C160 LED17 LED14 C157...
  • Page 102 SC847BE1C/2C Chassis Manual Notes...
  • Page 103 Appendix D: BPN-SAS3-826EL Backplane Speciications D-11 Single and Dual Port Expanders SAS connectors PRI-J1 to J4 and SED-J1 to J4 are bidirectional and can be treated as input or output. Single Ports BPN-SAS3-826EL1 backplanes have a single port expander that accesses all of the drives and supports cascading.
  • Page 104 SC847BE1C/2C Chassis Manual D-12 Failover The BPN-SAS3-826EL2 model backplane has two expanders which enable effec- tive failover and recovery. Single Host Bus Adapter In a single host bus coniguration, the SAS HBA backplane connects to one host bus adapter. LED28 HB-LED LED29 PRI-SDB...
  • Page 105 Appendix D: BPN-SAS3-826EL Backplane Speciications D-13 Failover with RAID Cards and Multiple HBAs The BPN-SAS3-826EL backplane may be conigured for failover with multiple HBAs using either RAID controllers or HBAs to acheive failover protection. RAID Controllers: If RAID controllers are used, then the failover is accomplished through port failover on the same RAID card.
  • Page 106 SC847BE1C/2C Chassis Manual D-14 Connecting HBAs to the Backplane Connecting an Internal HBA to the Backplane The following section lists the most common cables used to connect the HBA to the backplane. LED28 HB-LED LED29 PRI-SDB C502 I2C#4 I2C#0 DESIGNED IN USA LED25 LED26 BPN-SAS3-826EL1...
  • Page 107 Appendix D: BPN-SAS3-826EL Backplane Speciications Cable Name: Internal iPass (Mini-SAS) to HD (Mini-SAS) Part #: CBL-SAST-0508-01 Length: 50 cm (19 inches) Part #: CBL-SAST-0507-01 Length: 80 cm (31 inches) Description: This cable has an iPass (SFF-8087/Mini-SAS) connector (36-pin) at one end and a Mini-SAS HD (SFF-8643) connector at the other end.
  • Page 108 SC847BE1C/2C Chassis Manual Connecting an External HBA to the Backplane This backplane supports external host bus adapters. In this coniguration, the HBA and the backplane are in different physical chassis. This allows a JBOD (Just a Bunch Of Drives) coniguration from an existing system. Single External Host Bus Adapter LED28 HB-LED...
  • Page 109 Appendix D: BPN-SAS3-826EL Backplane Speciications Connecting Multiple Backplanes in a Single Channel Environment This section describes the cables used when cascading from a single HBA. These connections use CBL-SAST-0531 internal cables and CBL-SAST-0573 external cables. CBL-SAST-0531 (Internal Cable) LED28 HB-LED LED29 PRI-SDB C502...
  • Page 110 SC847BE1C/2C Chassis Manual Single HBA Coniguration Cables Figure D-15: External Mini-SAS HD to External Mini-SAS HD Cable Cable Name: 1 Meter External Mini-SAS HD to External Mini-SAS HD Cable Part #: CBL-SAST-0573 Ports: Single Placement: External Cable Description: External cascading cable, connects ports between servers and JBODs. Figure D-16: Mini-SAS HD Internal to External Adapter Cable Name: 16-port Mini-SAS HD Internal to External Cable Adapter with LP Bracket...
  • Page 111 Appendix D: BPN-SAS3-826EL Backplane Speciications Connecting Multiple Backplanes in a Dual Channel Environment This section describes the cables used when cascading from dual HBAs. These con- nections use CBL-SAST-0531 internal cables and CBL-SAST-0573 external cables. Port A Expander 1 Port B Expander 2 LED28 HB-LED LED29...
  • Page 112 SC847BE1C/2C Chassis Manual Notes D-18...

  • Page 113: Appendix E Front And Rear Backplane Cascading

    Appendix E: Front and Rear Backplane Cascading Appendix E Front and Rear Backplane Cascading To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic com ponents.
  • Page 114 SC847BE1C/2C Chassis Manual An Important Note to Users All images and layouts shown in this user's guide are based upon the latest back- plane revision available at the time of publishing. The card you have received may or may not look exactly the same as the graphics shown in this manual. The BPN-SAS3-846EL Front Backplane The BPN-SAS3-846EL backplane has been designed to utilize the most up-to-date technology available, providing your system with reliable, high-quality performance.
  • Page 115 Appendix E: Front and Rear Backplane Cascading Connecting the Front and Rear Backplanes This section describes the cables used when cascading from the front backplane to the rear backplane from multiple HBAs. These connections use CBL-SAST-0531 internal cables and CBL-SAST-0573 external cables. MH14 MH15 Q866...
  • Page 116 SC847BE1C/2C Chassis Manual Disclaimer (cont.) The products sold by Supermicro are not intended for and will not be used in life sup- port systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to per- form be reasonably expected to result in signiicant injury or loss of life or catastrophic property damage.
