Connecting the PC to Your MERLIN
Communications System
Use the following directions to connect the PC to your
MERLIN communications system.
Note
For more efficient call handling, it is recommended that you
connect both the CU 1 and CU 2 jacks to attendant ports on
the MERLIN control unit. However, if you have only one
attendant port available, connect that port to CU 1.
Turn your PC so you can see the three jacks in the expansion
1
card.
Plug one of the 14-foot station cables provided in the CMS
2
hardware package to the expansion card's middle jack, labeled
CU 1.
Plug the loose end of this cable to an attendant port.
3
Do not use jack 10.
If you plan to use a second attendant station, both station
jacks must be connected to attendant ports on the same
line card. So, be sure to attach the CU 1 jack to an
attendant port that has a second port available below it.
Then go on to steps 4 and 5.
Plug the loose end of the second 14-foot station cable
4
provided in the CMS hardware package to the CMS
expansion card's lower jack, labeled CU 2.
Plug the other end of this cable into an attendant port on the
5
same card as the attendant port you connected in step 3.
18
Call Management System Installation Guide
