OWNER'S MANUAL
Operating and Servicing Instructions
Find GENUINE Replacement Parts at
www.dirtdevil.com
• Please read these instructions
carefully before using your Upright.
• Let us help you put your vacuum
together or answer any questions,
call:
1-800-321-1134
(USA & Canada)
www.dirtdevil.com
WARNING:
Cleaner assembly may include small parts.
Small parts can present a choking hazard.
Warranty Registration
• Online at: www.dirtdevil.com
• Mail: Royal Appliance Mfg
7005 Cochran Rd.
Glenwillow, Ohio 44139
Español - página E1
BELT STYLE
This cleaner uses the
following parts:
BAG TYPE
For quick reference, please record your
vacuum information below.
Model #:
Mfg. Code:
(Mfg. code located on the lower backside of cleaner)
©2007 All rights reserved # 1-113085-000
5
U
7/07

Advertisement

Table of Contents
loading

Related Manuals for Dirt Devil M086035

Summary of Contents for Dirt Devil M086035

  • Page 1 OWNER’S MANUAL Operating and Servicing Instructions BELT STYLE Find GENUINE Replacement Parts at This cleaner uses the www.dirtdevil.com following parts: BAG TYPE • Please read these instructions carefully before using your Upright. • Let us help you put your vacuum together or answer any questions, call: 1-800-321-1134 (USA & Canada) www.dirtdevil.com WARNING:...

  • Page 2: Safety Instructions

    THIS VACUUM CLEANER IS INTENDED FOR HOUSEHOLD USE ONLY. IMPORTANT SAFETY INSTRUCTIONS When you use an appliance, basic precautions should always be followed, including the following: • READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. • ALWAYS FOLLOW THESE SAFETY INSTRUCTIONS. • BRING VACUUM CLEANER TO UPRIGHT POSITION WHEN USING THE HOSE AND ATTACHMENTS. • DO NOT LEAVE VACUUM CLEANER UNATTENDED WHEN PLUGGED IN. • REGULARLY CHECK THE FILTER TO CLEAN OR REPLACE. • WARNING: DO NOT USE SHARP OBJECTS TO CLEAN OUT THE HOSE SINCE THEY COULD CAUSE DAMAGE. • OCCASIONALLY REMOVE BRUSH AND CLEAN DEBRIS FROM END CAPS TO KEEP BRUSH ROTATING SMOOTHLY. • WARNING: THE CORDS, WIRES, AND/OR CABLES SUPPLIED WITH THIS PRODUCT CONTAINS CHEMICALS, INCLUDING LEAD OR LEAD COMPOUNDS, KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. WASH HANDS AFTER USING.
  • Page 3 • Do not use without dust bag and/or filters in place. • Turn off all controls before unplugging. • Use extra care when cleaning on stairs. • Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they may be present.

  • Page 4: Table Of Contents

    CONGRATULATIONS You are now the proud owner of a Dirt Devil . We trust your new purchase ® will bring you many years of satisfaction. Our company has designed and developed this product with you in mind. We are very proud of our products and hope that you are equally satisfied with their quality and performance. Thank you for your support of Dirt Devil products. ® Visit our website at www.dirtdevil.com TABLE OF CONTENTS Safety Instructions ........Page 2, 3 Features .

  • Page 5: Features

    FEATURES FRONT BACK FRONT BACK 1. Handle Grip 12. Hose Wrap/Carry Handle 2. Power Brush Tool 13. Dust Brush 3. Front Panel 14. Stretch Hose 4. Extension Wand 15. Automatic Cord Rewind 5. Brushroll Activation Pedal 16. Swivel Casters ™ 6. Headlight 17. Handle Release Pedal 7. Scuff Guard Bumper 18. O n/Off Pedal ™ 8. Brush View Window 19. Power Cord 9. Carpet Height Adjustment Knob 20. Cord Rewind Button...

  • Page 6: How To Assemble

    HOW TO ASSEMBLE TOOL REQUIRED: PHILLIPS SCREWDRIVER HANDLE ASSEMBLY HOSE ASSEMBLY Stand unit in upright Secure the handle by Place hose onto hose Insert the hose grip into position, align tabs on installing the three (3) wrap (located on back the side of the cleaner. either side on the handle screws provided into of handle) to secure.

  • Page 7: How To Operate

    HOW TO OPERATE WARNING: FULLY ASSEMBLE BEFORE OPERATING. NOTE: Cleaner must be in the upright position to lift the rotating brush off the carpet when cleaning above the floor. CARPET SETTINGS NOTE: The cleaner may be in the upright or operating position to adjust carpet setting. ADJUSTING IN THE UPRIGHT POSITION: Rotate the knob to the desired setting.

  • Page 8: Paper Bag: Removal & Replacement

    PAPER BAG: REMOVAL & REPLACEMENT WARNING: TO REDUCE THE RISK OF INJURY FROM MOVING PARTS - UNPLUG BEFORE SERVICING. NOTE: Unplug cleaner before changing paper bag. Cleaner must have paper bag in place at all times. You can tell your bag needs replacing when you experience less suction or when the Full Bag Indicator changes to yellow or red.

  • Page 9: Lightbulb: Removal & Replacement

    FILTER REMOVAL & REPLACEMENT: CONTINUED TOOL REQUIRED: PHILLIPS SCREWDRIVER WARNING: UNPLUG CLEANER BEFORE CHANGING FILTER. NOTE: Filter should be cleaned as needed. FILTER TYPE For F29 filter replacements, please visit our website at www.dirtdevil.com to buy online or call customer service at 1-800-321-1134. EXHAUST FILTER Located on the side of the cleaner. Lay cleaner flat. Lift cover Remove exhaust Reattach headlight Replace screw to Unscrew the one remove. filter from lens and lens panel.

  • Page 10: Belt Or Brushroll: Removal & Replacement

    BELT OR BRUSHROLL: REMOVAL & REPLACEMENT TOOL REQUIRED: PHILLIPS OR FLATHEAD SCREWDRIVER WARNING: TO REDUCE THE RISK OF INJURY FROM MOVING PARTS - UNPLUG BEFORE SERVICING. MODÈLE DE COURROIE For Belt Style 5 replacements, please visit our website at www.dirtdevil.com to buy online or call customer service at 1-800-321-1134. TO REMOVE OLD BELT Lay cleaner flat and flip cleaner to Rotate/pivot the nozzle guard and Lift and remove brushroll. expose nozzle base.

  • Page 11: General Maintenance

    GENERAL MAINTENANCE WARNING: TO REDUCE THE RISK OF INJURY FROM MOVING PARTS - UNPLUG BEFORE SERVICING. DEBRIS REMOVAL/ DEBRIS REMOVAL/HOSE NOZZLE GUARD 1. Check to see if bag is full; empty if needed. 2. Plug cleaner in and check to see if there is any suction at end of hose (Diagram 2). If there is suction at end of hose, move on to Diagram 3.

  • Page 12: Troubleshooting Guide

    TROUBLESHOOTING GUIDE WARNING: TO REDUCE RISK OF PERSONAL INJURY - UNPLUG CLEANER BEFORE SERVICING PROBLEM POSSIBLE REASON POSSIBLE SOLUTION Cleaner won’t run 1. Power cord not firmly plugged into 1. Plug unit in firmly. outlet. 2. Blown fuse or tripped breaker. 2. Check fuse or breaker in home. Replace fuse/reset breaker.
  • Page 13 GUIA DE SOLUCIÓN DE PROBLEMAS ADVERTENCIA: PARA REDUCIR EL RIESGO DE LESIONES PERSONALES, DESCONECTE ANTES DE DAR SERVICIO MANUAL DEL PROPIETARIO PROBLEMA POSIBLE CAUSA SOLUCIÓN POSIBLE La aspiradora no 1. El cordón eléctrico no está bien 1. Conecte el enchufe firmemente. Instrucciones de Funcionamiento conectado en la toma de corriente. funciona y Servicio 2.
  • Page 14 ESTA ASPIRADORA ESTÁ DISEÑADA PARA USO DOMÉSTICO SOLAMENTE MANTENIMIENTO GENERAL INSTRUCCIONES DE SEGURIDAD IMPORTANTES ADVERTENCIA: PARA REDUCIR EL RIESGO DE LESIONES PERSONALES - DESCONECTE LA ASPIRADORA ANTES Cuando use un electrodoméstico se deben seguir precauciones básicas, DE DARLE SERVICO. RETIRO DE LOS incluyendo las siguientes: DESECHOS / RETIRO DE LOS DESECHOS / PROTECCIÓN DE LA • LEA TODAS LAS INSTRUCCIONES ANTES DE USAR EL APARATO. MANGUERA BOQUILLA • SIEMPRE SIGA ESTAS INSTRUCCIONES DE SEGURIDAD. • PONGA LA ASPIRADORA EN POSICIÓN VERTICAL CUANDO USE LA MANGUERA Y LOS ACCESORIOS.
  • Page 15 • No aspire objetos que estén quemándose o emitiendo humo, tales como cigarrillos, BANDA Y CEPILLO: QUITAR Y REEMPLAZAR cerillos o cenizas calientes. HERRAMIENTA REQUERIDA: DESTORNILLADOR PHILLIPS O PLANO • No lo use sin tener en su sitio el recipiente de polvo y los filtros. ADVERTENCIA: PARA REDUCIR EL RIESGO DE LESIONES CAUSADAS POR LAS PARTES MÓVILES, DESCONECTE •...
  • Page 16 FILTRO: QUITAR Y REEMPLAZAR: CONTINUACIÓN FELICITACIONES HERRAMIENTA REQUERIDA: DESTORNILLADOR PHILLIPS O PLANO ADVERTENCIA: DESENCHUFE LA ASPIRADORA ANTES DE CAMBIAR EL FILTRO. Usted es ahora el orgulloso propietario de una Dirt Devil . Confiamos ® NOTA: El filtro debe limpiarse según sea necesario. en que su nueva adquisición le ofrecerá muchos años de satisfacción. TIPO DE FILTRO Para el filtro de reemplazo F29, por favor visite nuestro sitio Web en www.dirtdevil.com para comprar en línea o llame a servicios al cliente al 1-800-321-1134. Nuestra compañía diseñó y desarrolló este producto teniéndolo a usted en mente.
  • Page 17 BOLSA DE PAPEL: QUITAR Y REEMPLAZAR CARACTERÍSTICAS ADVERTENCIA: PARE REDUCIR EL RIESGO DE LESIONES CAUSADAS POR LAS PARTES MÓVILES, DESCONECTE PARTE FRONTAL PARTE POSTERIOR ANTES DE DAR SERVICIO. NOTA: Desenchufe la aspiradora antes de cambiar la bolsa de papel. La aspiradora debe tener la bolsa colocada en todo momento. Usted se da cuenta que necesita reemplazar la bolsa cuando nota una disminución en la succión o cuando la luz indicadora de bolsa llena se vuelve amarilla o roja.
  • Page 18 CÓMO ENSAMBLAR HERRAMIENTA NECESARIA: DESTORNILLADOR PHILLIPS ENSAMBLAJE DEL ASA ENSAMBLAJE DE MANGUERA Ponga la unidad en Asegure el asa al Coloque la manguera Inserte la empuñadura posición vertical, alinee insertar los tres (3) en la abrazadera de la de la manguera en el las lengüetas a ambos tornillos incluidos en manguera (localizada lado de la aspiradora.
