目录 Important Safety Information..............2 Finding information about the printer..........7 Setting up the printer.................11 检查包装箱内容........................11 安装其他语言的操作面板......................12 Getting the printer ready to fax....................12 Learning about the printer..............21 了解打印机的部件........................21 Using the control panel buttons and menus................22 Learning about the software.............32 使用打印机软件........................32 使用影像工作室........................32 Using the All-In-One Center.....................34 使用解决方案中心........................36 Using Print Properties.......................38 使用照片编辑器........................39...
Page 4
先打印最后一页(倒序打印)....................51 打印透明胶片..........................51 打印信封...........................51 打印卡片...........................52 将多页文档打印到一张纸上......................52 Working with photos................54 Retrieving and managing photos....................54 Printing photos using the control panel..................57 Printing photos using the computer..................60 Copying....................63 进行复印...........................63 复印照片...........................63 逐份复印...........................64 在一页纸上复制图像.........................64 放大或缩小图像........................65 Scanning.....................66 扫描文档...........................66 使用计算机定制扫描设置......................66 扫描文档或图像,并通过电子邮件发送出去................67 扫描文档并编辑其中的文本......................68 扫描图像并进行编辑.........................68 从杂志或报纸中扫描清晰的图像....................68 通过网络扫描至您的计算机......................69 Faxing....................70 Sending a fax..........................71 Receiving a fax.........................73 转发传真...........................74 打印传真活动报告........................75...
Learning about the software This chapter tells how to use the printer with Windows operating systems. If you are using a Macintosh operating system, see the Mac Help: 在 Finder 桌面上双击 Lexmark 5400 Series 文件夹。 Double-click the printer Help icon. 使用打印机软件...
将文档原件放置在扫描仪玻璃上 您可以复印、扫描和打印照片、文本文档、杂志文章、报纸以及其他的印刷品。您也可以扫描文档并发送传 真。 注意:请将明信片、照片、较小的物体、透明胶片、照片纸或较薄的介质(例如杂志剪辑)放置在扫描仪玻璃 上,而不要装入自动文档传送器(ADF)内。 请确认打印机的电源已打开。 打开顶盖。 将文档原件或物体正面朝下放置在扫描仪玻璃的左上角。 注意:照片应该如图所示放置。 关闭顶盖,以避免扫描结果中出现黑边。 Loading paper and original documents...
Copying Scanner glass Use the ADF for multiple-page A4, letter or legal size documents. Use the scanner glass for single pages, small items (such as postcards or photos), transparencies, photo paper, or thin media (such as magazine clippings). 注意:If you want to customize copy settings, see 第 25 页“使用“复印”菜单”. 进行复印...
Scanning Scanner glass Use the ADF for multiple-page A4, letter, or legal size documents. Use the scanner glass for single pages, small items (such as postcards or photos), transparencies, photo paper, or thin media (such as magazine clippings). 注意:If you want to customize scan settings, see 第 26 页“使用“扫描”菜单”. 扫描文档...
Faxing Scanner glass Use the ADF for: • Multiple-page A4 or letter-size documents. • Legal-size documents. Use the scanner glass for single pages, small items (such as postcards or photos), transparencies, photo paper, or thin media (such as magazine clippings). 注意:If you want to customize fax settings: Using the control panel, see 第...
注意:You can also set up a wireless network using a Lexmark print server. If your printer came with a Lexmark N4050e print server, follow the steps on the Setup Sheet that came with your product to set it up.
高容量彩色打印墨盒 35 照片打印墨盒 Ordering paper and other supplies To order paper and other supplies or to locate a dealer near you, visit our Web site at www.lexmark.com. 注意: • For best results when printing photos or other high-quality images, use Lexmark Premium Photo Paper or Lexmark Photo Paper.
Page 95
电源指示灯不亮 检查电源连接 从电源插座和打印机上断开电源线。 将电源线的一端完全插入打印机的电源插口中。 将电源线的另一端连接在一个其他电子设备使用过的电源插座上。 如果 指示灯没有变亮,请按 按钮。 软件不能安装 检查您的操作系统 您的打印机支持以下的操作系统:Windows 98/Me、Windows 2000、 Windows XP 和 Mac OS X(英文版)。 检查您的系统需求 请确认您的计算机满足打印机包装箱上列出的最小系统需求。 USB 电缆可能没有连接 检查 USB 电缆是否有明显的损坏。 将 USB 电缆上较方的一端牢固地插入打印机后面的 USB 插口中。 将 USB 电缆上扁平的一端牢固地插入计算机的 USB 插口中。 USB 插口旁边标记有 USB 符号 。...
检查 USB 连接 如果您使用了 USB 电缆: 检查 USB 电缆是否有明显的损坏。 将 USB 电缆上扁平的一端牢固地插入计算机的 USB 插口中。 USB 插口旁边标记有 USB 符号 。 将 USB 电缆上较方的一端牢固地插入打印机后面的 USB 插口中。 参阅打印服务器文档 如果出现以下的情况,请参阅打印服务器的说明文档获取安装指导: 打印服务器的指示灯不亮。 • USB 电缆没有连接在打印服务器上。 • 打印服务器没有接通电源。 • 软件可能没有正确安装 如果以上方法没有解决您的问题,请反安装打印机软件,然后重新安装。请参阅第 97 页“软件可能没有正确安装”获取更多的信息。 无法打印到网络打印机 参阅打印服务器文档 如果出现以下的情况,请参阅打印服务器的说明文档获取安装指导: 打印服务器的指示灯不亮。...
存储卡无法插入 检查存储卡类型 请确认您使用的存储卡是打印机所支持的类型。请参阅第 54 页“插入存储卡”获取更多的 信息。 检查存储卡位置 请参阅第 54 页“插入存储卡”确定哪一个插槽适用于您的存储卡,并获取有关插入存储卡 的指导。 插入存储卡后没有任何反应 检查存储卡位置 请参阅第 54 页“插入存储卡”确定哪一个插槽适用于您的存储卡,并获取有关插 入存储卡的指导。 检查存储卡类型 请确认您使用的存储卡是打印机所支持的类型。请参阅第 54 页“插入存储卡”获 取更多的信息。 存储卡可能损坏了 检查存储卡是否有明显的损坏。 可能连接了数码相机 将 PictBridge 兼容数码相机从打印机上断开。 USB 电缆可能没有连接 检查 USB 电缆是否有明显的损坏。 将 USB 电缆上较方的一端牢固地插入打印机后面的 USB 插口中。 将 USB 电缆上扁平的一端牢固地插入计算机的 USB 插口中。 USB 插口旁边标记有...
Page 112
Black Cartridge replacement A new cartridge needs to be installed. required / Color Cartridge If available, click the Continue button on your computer replacement required / Color and screen to print using the remaining print cartridge. (The Black Cartridge replacement Continue button is available only at the beginning of a print required job.)
Page 113
Clear Carrier Jam Raise the scanner unit. (remove obstructions) Remove any objects blocking the path of the cartridge carrier. Make sure the cartridge carrier lids are closed. Close the scanner unit. Press . Clear Carrier Jam Press to turn the printer off. (remove cartridges) Disconnect the power cord from the wall outlet.
Page 114
Computer not connected Make sure your computer is connected and turned on. Check the USB cable for any obvious damage. Firmly plug the square end of the USB cable into the USB port on the back of the printer. Firmly plug the rectangular end of the USB cable into the USB port of the computer.
Page 115
Fax Error The fax machines have stopped communicating. Resend the fax. There may have been a problem with the quality of the telephone line connection. Fax Mode Unsupported The receiving fax machine does not support the type of fax you attempted to send. If it does not support: •...
Page 116
Memory Full From the desktop, double-click the Imaging Studio icon. (lower the fax resolution) Click Fax. Click Manage fax history or All-In-One fax settings. Click the Dialing and Sending tab. From the “Send fax with this print quality” area, select a lower print quality.
Page 117
Phone Line Busy The printer automatically redials three times at 3-minute intervals. You can change the default settings to redial up to (change redial settings) five times at intervals up to 8 minutes. To change the redial settings: From the control panel, press Fax Mode. Press Press repeatedly until Fax Setup appears.
Page 118
Phone Line Error If the telephone line is being used by another device, wait until the other device is finished before sending the fax. (check phone line and cable connections) Make sure cable connections for the following hardware are secure, if applicable: •...
Remote Fax Error From the control panel, press Fax Mode. (lower the transmission speed) Press Press repeatedly until Fax Setup appears. Press . Press repeatedly until Dialing and Sending appears. Press . Press repeatedly until Max Send Speed appears. Press . Press repeatedly until a lower speed appears.
Page 125
索引 Photo Card 23 memory 54 Power 23 printing 52 adding text captions 62 Resize 23 carrier jam error 111 ADF (Automatic Document Right arrow 24 cartridge error 111 Feeder) Scan Mode 23 cartridge missing error 111 loading documents 46 Select 24 cartridges, print paper capacity 47...
Page 126
poor copy quality 100 printing 51 scanner unit does not error 1104 111 factory default settings, resetting close 100 error messages to 120 copying 63 alignment problem 111 failed to connect error cloning an image 64 carrier jam 111 message 111 collating copies 64 cartridge error 111 Fast Pics 41...
Page 127
sending a broadcast fax using 32 language immediately 71 Web site 33 changing 94 sending while behind a PBX 78 Imaging Studio, using 32 last page first 51 setting number of rings before improving print quality 89 layout, selecting 39 automatic answering 78 incorrect language appears on left cartridge error 111...
Page 128
paper guide 21 Photo Editor, using 39 paper jam photo paper, loading 43 network name does not appear in in Automatic Document Feeder photos list 108 (ADF) 109 adding text captions 62 network printer in paper support 109 album page 61 configuring 85 in printer 109 copying photos 63...
Page 129
Preview Now printer to be configured does not recycling when using Automatic appear in list of printers found on Lexmark products 93 Document Feeder 35 network 107 WEEE statement 122 previewing photos printing reducing an image 65 from the computer 35...
Page 130
from magazines and setting up individual fax load paper 111 newspapers 68 numbers 75 memory full 111 over a network 69 using 71 no images have been saving scanned image 66 using the Phone Book 76 selected 111 to computer 69 no photo files found 111 to e-mail 67 no photo/paper size selection...
Page 131
troubleshooting, network finding 7 cannot print to network printer 108 network name does not appear in list 108 printer to be configured does not appear in list of printers found on network 107 troubleshooting, print improving print quality 97 partial document or photo prints 99 poor quality at the edges of the page 99...
