Furuno TZTBB Installation Manual

Multi function display black box type
Hide thumbs Also See for TZTBB:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual
Installation Manual
Multi Function Display
Black Box Type
TZTBB
Model
SAFETY INSTRUCTIONS ................................................................................................ i
SYSTEM CONFIGURATION ........................................................................................... ii
EQUIPMENT LISTS........................................................................................................ iii
1. MOUNTING..............................................................................................................1-1
1.1 Mounting Considerations ...................................................................................................1-1
1.2 Processor Unit ...................................................................................................................1-1
1.3 Switch Box .........................................................................................................................1-2
2. WIRING....................................................................................................................2-1
2.1 Wiring Instructions .............................................................................................................2-1
2.2 CAN bus/NMEA0183 Data Conversion .............................................................................2-9
2.3 Example NavNet TZtouch System Configurations...........................................................2-12
3. SETTING UP THE EQUIPMENT .............................................................................3-1
3.1 How to Set Time Zone, Language and Units .....................................................................3-4
3.2 Menu Initial Setup ..............................................................................................................3-5
3.3 How to Set up the Radar....................................................................................................3-8
3.4 How to Set up the Sounder..............................................................................................3-11
3.5 Wireless LAN Setting .......................................................................................................3-12
4. HOW TO INSTALL THE HDD .................................................................................4-1
4.1 Hard Disk Drive (HDD).......................................................................................................4-1
PACKING LISTS ......................................................................................................... A-1
OUTLINE DRAWINGS ................................................................................................ D-1
INTERCONNECTION DIAGRAM ................................................................................ S-1
www.furuno.com
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.

Advertisement

Table of Contents
loading

Related Manuals for Furuno TZTBB

Summary of Contents for Furuno TZTBB

  • Page 1: Table Of Contents

    Installation Manual Multi Function Display Black Box Type TZTBB Model SAFETY INSTRUCTIONS ....................i SYSTEM CONFIGURATION ................... ii EQUIPMENT LISTS......................iii 1. MOUNTING......................1-1 1.1 Mounting Considerations ....................1-1 1.2 Processor Unit ........................1-1 1.3 Switch Box .........................1-2 2. WIRING........................2-1 2.1 Wiring Instructions ......................2-1 2.2 CAN bus/NMEA0183 Data Conversion ................2-9...
  • Page 2 Installation Manual This page is intentionally left blank.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS The installer must read the safety instructions before attempting to install the equipment. Indicates a potentially hazardous situation which, if not WARNING avoided, could result in death or serious injury. Indicates a potentially hazardous situation which, if not CAUTION avoided, may result in minor or moderate injury.

  • Page 4: System Configuration

    PSU-017: w/DRS2D/4D For details of the power supply unit, see the installation manual of the radar sensor (IME-35670). Note 1: Do not connect or disconnect the DVI cable between TZTBB and the touch monitor while TZTBB is powered. Note 2: When the two monitors are connected, the resolutions and the aspect ratio should match...

  • Page 5: Equipment Lists

    EQUIPMENT LISTS Standard supply Name Type Code No. Remarks Processor Unit MPU-002 Switch Box PSD-002 Installation Ma- CP19-01701 CP19-01700 000-022-530 terials Accessories FP19-01801 001-205-650 Spare Parts SP19-01401 001-205-630 Fuses Optional supply Name Type Code No. Remarks Joint Box TL-CAT-012 000-016-714-01 For LAN network Remote Control MCU-002...
  • Page 6 EQUIPMENT LISTS Name Type Code No. Remarks CAN bus SS-050505-FMF- Micro style: 3 000-168-603-10 Connector TS001 NC-050505-FMF- Mini style: 2, 000-160-807-10 TS001 micro style: 1 LTWMC-05BMMT- Micro style, male, 000-168-604-10 SL8001 termination resistor LTWMN-05AMMT- Mini style, male, 000-160-508-10 SL8001 termination resistor LTWMC-05BFFT- Micro style, female, 000-168-605-10...

  • Page 7: Mounting

    MOUNTING Mounting Considerations When selecting a mounting location for TZTBB, keep the following in mind: • The temperature at the mounting location shall be between -15°C and +55°C (wire- less LAN: 0°C and +55°C). • The humidity at the mounting location shall be 93% or less at 40°C.

  • Page 8: Switch Box

    1. MOUNTING Switch Box The switch box PSD-002 is designed to be flush mounted on a flat bulkhead. Refer to the outline drawing for mounting dimensions. Procedure 1. Make a cutout in the mounting location as shown below. 86±1 Cutout dimensions 2.

  • Page 9: Wiring

    2.1.1 NETWORK ports TZTBB uses a standard TCP/IP Ethernet to share radar/sounder images and other navigation information from devices connected to the network system. In any single NavNet TZtouch network, a combination of up to six TZT series devices may be con- nected to each other.
  • Page 10 CAN bus. This cable has an 18-pin connector. For example, a MOB contact closure input may be connected to pin 15 and 11*. *Note that any TZTBB interfaces to virtually any MOB system or event switch (point save) contact closure signal using these pins.
  • Page 11 CAN bus ports cannot be connected together. The TZTBB and DRS (radar sensor) use “Ethernet Bridging” to link the DRS CAN bus and the TZTBB CAN bus data. Refer to paragraph 2.2.1 for more information. Note that the TZTBB CAN bus port is not powered unless external power is applied to the FRUDD-18AFFM-L180 ca- ble of MULTI port and must be connected to a properly configured CAN bus network.
  • Page 12 2. WIRING NMEA0183 equipment To connect an NMEA0183 equipment to TZTBB, use the CAN bus network via the op- tional NMEA data converter IF-NMEA2K2 (or IF-NMEA2K1). This NMEA connection can accept a baud rate of 4800 or 38400. Heading input to TZTBB allows functions such as Radar Overlay and course stabili- zation (North up, Course up, etc.) in the radar operating modes.
  • Page 13 2. WIRING 2. Attach the DVI-D, Video composite and Audio cable connectors to their respective ports. DVI-D OUT0 Audio OUT Video IN 1/2 3. Set the waterproofing gasket to the boot cover then pass the cables through the boot cover. 4.
  • Page 14 2. WIRING 10. Fix the cables to the cable clamp with cable ties (2 pcs. each). Attach a cable tie at the base of waterproofing tube. Note: Cable ties are necessary for waterproofing. Do not fail to attach them. Cable ties for Cable ties for fixing waterproofing...
  • Page 15 2. WIRING 22. Peel off the seal from the slots to be used on the fixing plate2. Fixing plate2 Peel off the seal from the slots to be used 23. Attach the fixing plate2 to the entrance of the connector cover. 24.
  • Page 16 AXIS IP cameras. DVI-D (external monitor) A DVI monitor is required for the TZTBB. The plug is DVI-D format and only a DVI-D monitor with VESA DDC (Display Data Channel) can be connected. The TZTBB uses the monitor information (EDID) given via DDC to output the video data with the appro- priate resolution.

  • Page 17: Can Bus/Nmea0183 Data Conversion

    CAN bus cable up the mast. In this case, each separate CAN bus network (the DRS CAN bus and the ship CAN bus) will be “Bridged” together via the Ether Network. Note that the TZTBB and DRS CAN bus ports must not be connected together. Connection of multiple TZTBBs, no DRS radar sensor Connect multiple TZTBBs with Ethernet and CAN bus cables.
  • Page 18 2. WIRING 2.2.2 CAN bus (NMEA2000) input/output PGN Input PGN Description 059392 ISO Acknowledgement 059904 ISO Request 060928 ISO Address Claim NMEA-Request Group Function 126208 NMEA-Command Group Function NMEA-Acknowledge Group Function 126992 System Time 126996 Product Information 127237 Heading/Track Control 127245 Rudder 127250...
  • Page 19 The CAN bus output PGN setting (found under the [Initial Setup] menu) is global to the network. Note that only one TZTBB will output CAN bus data on the network at a time: the TZTBB which is powered ON first. If that display is turned OFF, another will take its place to output the data.

  • Page 20: Example Navnet Tztouch System Configurations

    The FURUNO GP-330B is connected to the CAN bus backbone cable, using the op- tional NMEA data converter IF-NMEA2K2 (or IF-NMEA2K1). The DFF1/3 network sounder is connected to the LAN port of the TZTBB using the standard supply cable MOD-WPAS0001-030+(3 m) and a junction box TL-CAT-012.

  • Page 21: Mod-Z072

    NMEA DATA CONVERTER 12/24 VDC IF-NMEA2K2 LAN cable 24 VDC MOD-WPAS0001-030+,3 m LAN cable A HUB-101 is required when four or more network (MOD-Z072) equipments are connected to TZTBB. DFF3 NETWORK SOUNDER ST-BY Network Sounder DFF3 12-24 VDC High Freq.
  • Page 22 2. WIRING This page is intentionally left blank. 2-14...

  • Page 23: Setting Up The Equipment

    SETTING UP THE EQUIPMENT This chapter shows you how to set up your system according to the equipment you have connected. You can do almost all operations on this equipment by just touching the display, following the instructions below. Touch control description The touch control depends on the screen type.
  • Page 24 3. SETTING UP THE EQUIPMENT About menu operations The following procedure shows how to use the menu system. 1. Press the key on the switch box to turn the power on. The chart plotter display appears after the start-up screen appears. 2.
  • Page 25 3. SETTING UP THE EQUIPMENT Icon Description This icon means that a menu item has some options. Touch it to show the option window (pull-down list). Touch the menu item with this icon to display the soft- ware keyboard, to enter alphanumeric data. For de- tails, see “How to use the software keyboard”...

  • Page 26: How To Set Time Zone, Language And Units

    3. SETTING UP THE EQUIPMENT How to Set Time Zone, Language and Units Before setting up your equipment, select the time zone, language and units to use on your equipment as shown below. 1. Tap the Home icon, then select [Menu] icon ( ) from the menu icon bar.

  • Page 27: Menu Initial Setup

    3. SETTING UP THE EQUIPMENT [Menu Units] sub menus Menu item Options [Bearing Display] [True], [Magnetic] [True Wind Calculation Ref- [Ground], [Surface] erence] [Position Format] [DDD°MM.mmmm’], [DDD°MM.mmm’], [DDD°MM.mm’], [DDD°MM’SS.ss”], [DDD.dddddd°], [Loran C], [MGRS] [Loran C Station & GRI] [GRI] Select GRI code. [Master] [First (Second) Slave] X: Upolu Point, Y: Kure Island...
  • Page 28 3. SETTING UP THE EQUIPMENT Menu Initial Setup Menu item Description Options (setting range) [Boat Length] Set the length of your boat. 5.0 to 9,999 ft Enter the GPS antenna positioning bow-stern (Longitudinal) [Longitudi- Origin and port-starboard (Lateral) position from the origin. nal GPS Position] [Lateral...
  • Page 29 Select the source for each data to input to the system. If two or more sources are connected for a data, select one using the pull-down dialog box. The Furuno products are shown at the upper part of the list. [Sensor List] Show the information for sensors connected to your equipment.

  • Page 30: How To Set Up The Radar

    3. SETTING UP THE EQUIPMENT Menu Initial Setup (Data Damping) Menu item Description Options (setting range) [COG & SOG] Set data damping time. The lower the set- 0 to 59 seconds ting the faster the response to change. [Heading] [Speed Through Water] [Wind Speed &...
  • Page 31 3. SETTING UP THE EQUIPMENT 2. Drag the [Menu Radar] sub menus to find the menu item [Radar Initial Setup]. Title Menu Radar (Radar Initial Setup) Menu item Description Options (setting range) [Antenna Rotation] Select the speed of antenna rotation. [Auto], [24 RPM], [48 RPM] [Antenna Heading See the topic of “How to align the antenna...
  • Page 32 3. SETTING UP THE EQUIPMENT How to align the antenna heading You have mounted the antenna unit facing straight ahead in the direction of the bow. Therefore, a small but conspicuous target dead ahead visually should ap- pear on the heading line (zero degrees). In practice, you will probably observe some small bearing error on the display be- cause of the difficulty in achieving accurate initial positioning of the antenna unit.

  • Page 33: How To Set Up The Sounder

    3. SETTING UP THE EQUIPMENT How to Set up the Sounder If you have a sounder (BBDS or DFF series), set up the sounder as shown in this sec- tion. Drag the main menu to select [Sounder]. You can confirm the actual sounder dis- play on the left-hand side of the screen while setting up.

  • Page 34: Wireless Lan Setting

    Wireless LAN Setting Note: Some TZTBBs are not equipped with the wireless LAN. The TZTBB can be configured to create a wireless network (“Ad Hoc”) or to connect to an existing wireless network. Connecting to an existing wireless network is very useful if you already have an Access Point setup on your boat, especially if you have Internet available.

  • Page 35: How To Install The Hdd

    HOW TO INSTALL THE HDD Hard Disk Drive (HDD) An HDD (local supply) can be installed inside the processor unit. The usable HDD size is 90 x 134 x 20 mm. Install the HDD inside the processor unit as follows. Procedure 1.
  • Page 36 4. HOW TO INSTALL THE HDD 3. Unfasten the binding screws (M4x8, 4 pcs.) to remove the lid of the HDD casing. Binding screw (4 pcs.) HDD casing 4. Set the HDD into the casing with correct orientation. 5. Fasten the lid to the HDD casing with four binding screws. 6.
