PLEASE RETAIN
Stanley Aoife
Solid Fuel NB Stove
This appliance is hot while in operation and retains its heat for a long period of time after use.
Children, aged or infirm persons should be supervised at all times and should not be allowed to touch
the hot working surfaces while in use or until the appliance has thoroughly cooled.
When using the stove in situations where children, aged and/or infirm persons are present a fireguard
must be used to prevent accidental contact with the stove. The fireguard should be manufactured in
BS 8423:2010.
accordance with
INSTALLATION AND OPERATING INSTRUCTIONS

Advertisement

Table of Contents
loading

Related Manuals for Stanley Aoife

Summary of Contents for Stanley Aoife

  • Page 1 PLEASE RETAIN Stanley Aoife Solid Fuel NB Stove This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot working surfaces while in use or until the appliance has thoroughly cooled.

  • Page 2: Table Of Contents

    Stanley Solid Fuel Stove Warranty ........

  • Page 3: Stanley Solid Fuel Stove Warranty

    CONDITIONS OF WARRANTY Your Stanley Solid Fuel Stove is guaranteed against any part that fails (under normal operating conditions) as detailed in the following table with timelines specified from the date of installation of the appliance. If the unit is not installed within six months of date of purchase, the warranty will commence six months from the date of purchase.

  • Page 4: Installation Checklist

    INSTALLATION CHECK LIST Tick Flue System 1. Minimum Flue Height of 4.6 metres (15 feet). 2. Appliance should be connected to a 125mm (5”) flue pipe within a metre and then the flue size increased to a minimum of 150mm (6”) diameter. 3.

  • Page 5: Important Operation/ Maintenance Notes

    IMPORTANT OPERATION / MAINTENANCE NOTES Now that your Stanley solid fuel Stove is installed and no doubt you are looking forward to many comforts it will provide, we would like to give you some tips on how to get the best results from your stove.

  • Page 6: Installation & Operating Instructions

    In Clearance to Combustibles Section). case of contact with the skin wash immediately with plenty of water. Your Aoife stove is supplied with the following items: • Black Spring Handle Assembly (see fig. 1) Asbestos •...

  • Page 7: Flues

    150mm. CHIMNEY The Aoife is a radiant room heater and must be con- nected to a chimney of the proper size and type. The chimney must have a diameter of at least 150mm.

  • Page 8: Down Draughts

    DOWN DRAUGHTS The effective free area of any vent should be ascer- tained before installation. The effect of any grills However well designed constructed and positioned, should be allowed for when determining the effective the satisfactory performance of the flue can be free area of any vent.

  • Page 9: Location

    There are several conditions to be considered in connector is either listed for wall pass-through or is selecting a location for your Aoife Stove. routed through a device listed for a wall pass- through and is installed in accordance with the con- a.

  • Page 10: Stove Dimensions

    STOVE DIMENSIONS Fig.7 Note: Dimensions stated are in millimetres and may be subject to a slight +/- variation. COMMISSIONING & HANDOVER On completion of the installation allow a suitable period of time for any fire cement and mortar to dry out, when a small fire may be lit and checked to ensure the smoke and fumes are taken from the stove up the chimney and emitted safely to the atmosphere.

  • Page 11: Recommended Fuels

    HETAS Approval does not cover the use of other fuels either alone or mixed with the recommended fuels listed, nor does it cover instruc- tions for the use of other fuels. AOIFE - TECHNICAL DATA FUEL Coal...

  • Page 12: User Instructions

    USER INSTRUCTIONS Open the firebox door and remove all ash from the grate & ashpan. Open the primary air control (spin valve) by turning it fully anticlockwise (see Figure 10). Set the secondary air slider to the required position depending on the fuel being burned i.e. open when burning wood/coal and closed when burning anthracite (see Figure 11).

  • Page 13: De-Ashing

    DE-ASHING It is recommended that the rope seals on the stove are changed at least every two years or sooner if Never allow ashpan to over fill as it will cause dam- the seal loses its integrity. age to firebars. CHIMNEY CLEANING Open the fire door and remove ashpan using the The chimney should be cleaned twice annually or if...

  • Page 14: Fire Safety

    WARNING NOTE: Properly installed, operated and maintained this stove will not emit fumes into the dwelling. Occasional fumes from the de-ashing and re-fuelling may occur. However, persistent fume emission is potentially dangerous and must not be tolerated. If fume emission does persist, then the following immediate action should be taken: (a) Open doors and windows to ventilate room.

  • Page 15: Exploded View

    AOIFE SOLID FUEL STOVE EXPLODED VIEW BASE - AF0501 22. SPIGOT - I125 - AF0502 23. DOOR HINGE - CA1602 FRONT - AF0503 24. AIR WASH SHUTTER - CA1113-05 BACK - AF0504 25. RIDDLING ROD - CA1401-SM05 LH SIDE - AF0505 26.

  • Page 16: Fault Finding

    SYMPTOM POSSIBLE CAUSES REMEDY Stove Difficult To Light Air controls set incorrectly Air controls must be set to maximum settings on initial light-up Moisture content of fuel too high Ensure fuel is sufficiently dry Fire Burns Too Quickly Air controls set incorrectly Adjust Air controls Rope seals perished/worn Replace rope seals...

  • Page 17: Fault Finding

    SYMPTOM POSSIBLE CAUSES REMEDY Creosote/Tar Build-up in Firebox Insufficient flue draught Seek professional chimney advice and on Flue Pathways Moisture content of fuel too high Ensure fuel is sufficiently dry Fuel excessively dirty Use smokeless fuel Air controls set to minimum settings Constant low burning can produce excessive soot Smells From Stove/Installation...
  • Page 18 NOTES...
  • Page 19 NOTES...
  • Page 20 Manufactured by Waterford Stanley Ltd., Unit 401-403, IDA Industrial Estate, Cork Road, Waterford, Ireland. Tel: (051) 302300 Fax (051) 302315 YS 270117 N00577AXX...
